Information for Lot 9 of ErP (Ecodesign)

This addendum addresses European Union (EU) Ecodesign requirements for servers and storage

products. All data and ratings within this addendum are in reference only to the Supermicro product(s) in

the manual. The below information conforms to requirements laid down in Annex II of the Commission

Regulation 2019/424.

3(1)(a): See Section 1.1 of the system manual for the product type.

3(1)(b): See the title page and preface of the system manual for the trademark and

manufacturer’s address.

3(1)(c): See the title page of the system manual for product model number(s).

3(1)(d): See the serial number on the physical system to determine the year of manufacture.

3(1)(e-j): PSU Efficiency and Power Factor Value (Table) (From 80 Plus report)

PSU Model #: PWS-1K22A-1R

Watts: 1200W

PSU Efficiency

Power Factor

% of Rated Load

10 % 20 % 50 % 100 %

50 %

Single Output (AC-DC)

90.70%

95.20%

96.01%

93.74%

0.99

System (EUT) Efficiency in Idle State Power (Table)

Representative

Configurations

Measured Idle State

Power (W)

Calculated Idle Power

Allowance (W)

High-End Performance

Configuration

242.9

499.03

Typical Configuration

N/A

Low-End Performance

Configuration

121.6

309.43

System (EUT) Efficiency in Active State Power (Table)

Representative

Configurations

Active State

Efficiency Score

(Effserver)

Minimum Active State

Efficiency for 2-Socket

Server

High-End Performance

Configuration

56.9

Typical Configuration

N/A

9.5

Low-End Performance

Configuration

37.8

3(1)(k): The operating condition class is A2.

Dry bulb temp °C

Humidity range, non-condensing

Operati

conditi

Allowab

range

Reco

m

mend

Allowable range

Recommended

range

Max

dew

point (°

Maximu

m rate

change

15- 32

18-27

–

12 °C Dew Point (DP)

and

8 % relative

humidity (RH) to

17 °C DP and 80 % RH

–

9 °C DP to

15 °C DP

and

60 %

5/20

10-35

18-27

–

12 °C DP and 8 % RH

21 °C DP and 80 %

Same as A1

5/20

5-40

18-27

–

12 °C DP and 8 % RH

24 °C DP and 85 %

Same as A1

5/20

5-45

18-27

–

12 °C DP and 8 % RH

24 °C DP and 90 %

Same as A1

5/20

3(1)(l): The idle state power at the higher boundary temperature of the operating conditions

class is 286.62W.

3(1)(m): The active state efficiency and performance is

56.9.

3(1)(n): There are two methods by which a user can securely delete data from this system. The

user performing secure data deletion should be an IT professional.

The first is with a Unified Extensible Firmware Interface (UEFI) shell utility. This utility

works on X10/X11/H11/H12/M11 motherboard series with onboard SATA/NVMe devices.

Any user may access and download this utility through following link:

https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wftp/utility/Lot9_Secure

_Data_Deletion_Utility/

Download the shell utility package and extract it to a USB flash drive, then plug the drive

into the server for which secure data deletion is necessary. Then turn the system on.

Navigate to the BIOS setup menu, then place the server system into the UEFI shell

environment. Follow the instructions in the README file to invoke the utility and

complete the deletion.

The second method is through the secure data deletion tool provided by the original

manufacturer of the hard drive. This should be used in a scenario where the shell utility

is not applicable. Each manufacturer should have the tool available on their website. If

needed, please look on the hard drive label for the name of the manufacturer and model

information.

3(1)(o): List of recommended combinations of blade servers with chassis: N/A.

3(1)(p): List of all current SKUs within this product family: N/A.

3(3)(a): There is no use of cobalt in batteries in this product.

Produkt Specifikationer

Mærke:	Supermicro
Kategori:	Server
Model:	AS-1124US-TNRP
Bredde:	73.5 mm
Dybde:	203 mm
Højde:	40 mm
Vægt:	21800 g
Produktfarve:	Sort
Pakkedybde:	943.102 mm
Pakkebredde:	600.964 mm
Pakkehøjde:	198.12 mm
Wi-Fi:	Ingen
Opbevaringstemperatur (T-T):	-40 - 70 °C
Relativ luftfugtighed ved drift (H-H):	8 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Ethernet LAN-porte (RJ-45):	1
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	4
Ethernet LAN:	Ja
Driftstemperatur (T-T):	10 - 35 °C
Intern hukommelse:	- GB
Operativsystem installeret:	Ingen
Certificering:	80 PLUS Titanium Level
Harmoniseret systemkode (HS):	84714100
Processorfrekvens:	- GHz
Processorserie:	AMD EPYC
Intern hukommelsestype:	DDR4-SDRAM
Hukommelsesur hastighed:	3200 MHz
Maksimal intern hukommelse:	8000 GB
Samlet lagringskapacitet:	- GB
On-board grafikkort, model:	Aspeed AST2500
On-board grafikkort:	Ja
Hukommelsesstik:	32
Processorproducent:	AMD
Processormodel:	7000
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	10 Gigabit Ethernet
SSD-grænsefladetype:	NVMe, Serial Attached SCSI (SAS), SATA III
Optisk drevtype:	Ingen
Trusted Platform Module (TPM):	Ja
NVMe:	Ja
Stativ-montering:	Ja
Kabinettype:	Stativ (1U)
Strømforsyning:	1200 W
Understøtter RAID:	Ingen
Maksimal lagerkapacitet:	- TB
Fejlkorrigerende kode:	Ja
PCI Express x16 slots:	4
Redundant strømforsyning:	Ja
LAN Kontroller:	Intel X710-AT2
BIOS-type:	EEPROM
Hot-swap:	Ja
Trusted Platform Module (TPM) version:	2.0
Understøttelse af Intelligent Platform Management Interface (IPMI):	Ja
Understøttede SSD-størrelser:	2.5"
Antal understøttede SSD'er:	12
SSD-størrelse:	2.5"
