ContaCt nformatIon I
• Manuals: http://www.supermicro.com/support/manuals
• Drivers & Utilities: https://www.supermicro.com/wdl/driver/
• Safety: http://www.supermicro.com/about/policies/safety_information.cfm
© 2022 Supermicro Computer Inc. All rights reserved. Reproduction of this document whether in part or in whole is strictly prohibited without Supermicro's written
consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.
P CaCkage ontents
Q r g 1.00uICk eferenCe uIDe
• One Supermicro Motherboard
• One Quick Reference Guide
• Website: www.supermicro.com
• General Information: marketing@supermicro.com
• Technical Support: support@supermicro.com
• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
f or your system to work ProPerly Please DownloaD aPProPrIate,
DrIvers Images user s manual from the lInks below/ / ' :
MNL-2483-QRG-100
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
Connectors
Memory Support
CPU Installation
LED Indicators
PRESS FITPRESS FIT
1
1
1
R12SPD-A
REV:2.00A
DESIGNED IN USA
DIMMH2
DIMMH1
DIMMG2
DIMMG1
DIMMF2
DIMMF1
DIMME2
DIMME1
DIMMA1
DIMMA2
DIMMB1
DIMMB2
DIMMC1
DIMMC2
DIMMD1
DIMMD2
IPMI CODE
BAR CODE
MAC CODE
BIOS
LICENSE
MH3
CPU
LED3
MH6
NVMe5NVMe4
NVMe3NVMe2
MH4
FAN6 FAN5
FAN3
FAN4
MH7
FAN2 FAN1
MH5
JPWR2
JPWR4
MH8
JF1
JP2
JPI2C1USB4/5JTPM1USB0/1
MH2
JL1
COM1
MH12
JPF1
BT1
JMD1
JMD1_SRW1
2280
JMD1_SRW2
22110
J7
MH14
LED2
VGA
JPL1
J8
MH13
USB2/3
IPMI_LAN
LED_L2
LED_L1
LAN2 LAN1
LED1
UID
MH1
MH9
JFP1
CPU AIOM PCIe 4.0 x16
CPU SLOT9 PCIe 4.0 x16
CPU SLOT6 PCIe 4.0 x16
CPU SLOT5 PCIe 4.0 x16
LEDM1
AST2600
25G LAN
CX-4
CPLD
NVMe0
NVMe1
JPWR6JPWR7JPWR5
JPWR1
JIPMB1
Jumpers, Connectors, and LED Indicators
Motherboard Layout and Features
Jumpers
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this
guide.
Note: Refer to Chapter 2 of the User Manual for detailed information on jumpers, connectors,
and LED indicators.
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
The R12SPD-A supports up to 4TB of ECC and Non-ECC UDIMM/LRDIMM/
RDIMM/3DS RDIMM memory with speeds of up to 3200MT/s in 16 memory slots.
= mounting hole
Front Control Panel (JF1) Front Panel (JFP1)
The R12SPD-A motherboard supports the Ampere® Altra™ 80-core and Altra Max™
128-core processors with a TDP of up to 250W in an LGA 4926 socket.
Use a screwdriver with a Torx T20 screw head bit to unscrew the socket force frame.
Unscrew counterclockwise in the sequence 5-4-3-2-1. Align CPU pad cutout to the
respective cutout on the LGA 4926 socket.
Use a torque screwdriver set to 16.1 kgf-cm (14 lbf-in) with a Torx T20 screw head
bit to screw in the socket force frame. Screw in clockwise in the sequence 1-2-3-4-5.
Align the heatsink to the socket. Starting with two screws on opposite corners, use
a Phillips #1 screwdriver to screw in the heatsink.
Connector Description
BT1 Onboard CMOS Battery
COM1 Micro-USB COM Port
CPU AIOM PCIe 4.0 x16 PCIe 4.0 p1-x16 AIOM Slot
FAN1 – FAN5 CPU/System Fan Headers (FAN1: CPU Fan)
FAN6 AUX Fan Header
IPMI_LAN Dedicated IPMI LAN Port
JF1 Front Control Panel Header
JFP1 Front Panel Header
JIPMB1
4-pin External I
2
C Header for an IPMI card
JL1 Chassis Intrusion Header
JMD1 M.2 M-Key PCIe 4.0 Connector (2280/22110)
JPI2C1
Power Supply SMBus I
2
C Header
JPWR1 Proprietary PSU 14-Pin Power Connector
JPWR2 Proprietary PSU 8-Pin Power Connector
JPWR4 5V/12V Power Connector for Special Riser Card
JPWR5 ATX PSU 24-Pin Power Connector
JPWR6, JPWR7 ATX PSU 8-Pin Power Connector
JTPM1 Trusted Platform Module (TPM) 2.0
LAN1, LAN2 SFP28 10G/25G LAN Ports
NVMe0 p1-x8 – NVMe5 x8 PCIe 4.0 p1-x8 SlimSAS NVMe Connectors
UID Unit Identier Button
USB0/1 Front-Accessible USB 2.0 Header
USB2/3 USB 3.0 Type-A Ports on the Rear I/O Panel
USB4/5 Front-Accessible USB 3.0 Header
VGA VGA Port
Jumper Description Default Setting
J8 CPU UART/BMC Debug Pins 1-2 Closed (CPU UART)
JPL1 LAN1/2 Enable/Disable Pins 1-2 (Enabled)
LED Description Status
LED1 Unit Identier LED Solid Blue: Unit Identied
LED2 Power LED Solid Green: Power On
LED3 System Status LED Solid Red: CPU Fault
LED_L1 SFP28 LAN Status for LAN2
Top LED Yellow: 10G Link
Top LED Green: 25G Link
Bottom LED Green: Port Activity
LED_L2 SFP28 LAN Status for LAN1
Top LED Yellow: 10G Link
Top LED Green: 25G Link
Bottom LED Green: Port Activity
LEDM1 BMC Heartbeat LED Blinking Green: BMC Normal
Memory and CPU Support
Rear I/O Panel Connectors
# # #Description Description Description
1. 6.Micro-USB COM Port SFP28 Tra󰀩c LED 11. SFP28 Link Speed LED
2. USB 3.0 Type-A 7. 12.SFP28 Link Speed LED UID LED
3. USB 3.0 Type-A 8. 13.SFP28 Port UID Button
4. VGA Port SFP28 Port9.
5. 10.RJ45 IPMI LAN Port SFP28 Tra󰀩c LED
1
98
7
654
3
2
1
2
3
Screw #2
Screw #3
Screw #1
Screw #5
Screw #4
Screw #2
Force Frame
Screw #3
Screw #1
Screw #5
Screw #4
North of socket
North of heatsink
10 12
13
11
2019
NIC2 Activity LED
ID_UID/3.3V Stby
Power Button
Reset Button
Reset
PWR
Ground
Ground
1 2
PS FAIL
Red+
(Blue LED_Cathode_UID)
Blue+
(Red OH/Fan Fail/PWR Fail)
3.3V
3.3V
Key
X
Key
FP PWR LED
HDD LED
NIC1 Activity LED
Ground
3.3V Stby
3.3V Stby
JF1
Power Button
HDD Activity LED
Fail LED_N (OH/FF/PF)
1
2
Reset/UID Button
P3V3_STBY
Standby LED_N
LAN1 Activity LED (Aggregate all LAN)
UID LED_N
LAN2 Activity LED
Power LED_N
3
4
5
6
7
8
9
10
Ground
Ground
P5V_USB
I2C Clock
19
Ground20
Power Fail LED_N
Power Fail LED_P
I2C Data
P5V_USB
P5V_USB
11
12
13
14
15
16
17
18
JFP1
