Side 1/73

USER'S MANUAL

Revision 1.0

SuperServer

1019P-WTR

The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes

no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update

or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:

For the most up-to-date version of this manual, please see our website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual

at any time and without notice. This product, including software and documentation, is the property of Supermicro and/

or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except

as expressly permitted by the terms of said license.

IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT

OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER

MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED

OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,

INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the

State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution

of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,

may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference, in which case you will be required to correct the interference at your own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only

to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.

See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this product may expose you to lead, a

chemical known to the State of California to cause birth defects and other reproductive harm.

The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,

nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical

systems whose failure to perform be reasonably expected to result in signicant injury or loss of life or catastrophic

property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products

for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully

indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and

proceedings of any kind arising out of or related to such ultra-hazardous use or sale.

Manual Revision 1.0

Release Date: July 27, 2017

Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this

document. Information in this document is subject to change without notice. Other products and companies referred

to herein are trademarks or registered trademarks of their respective companies or mark holders.

Printed in the United States of America

PrefaceSuperServer 1019P-WTR User's Manual

Preface

About this Manual

This manual is written for professional system integrators and PC technicians. It provides

information for the installation and use of the SuperServer 1019P-WTR. Installation and

maintenance should be performed by experienced technicians only.

Please refer to the 1019P-WTR server specications page on our website for updates on

supported memory, processors and operating systems (http://www.supermicro.com).

Notes

For your system to work properly, please follow the links below to download all necessary

drivers/utilities and the user’s manual for your server.

• Supermicro product manuals: http://www.supermicro.com/support/manuals/

• Product drivers and utilities: ftp://ftp.supermicro.com

• Product safety info: http://www.supermicro.com/about/policies/safety_information.cfm

If you have any questions, please contact our support team at:

support@supermicro.com

This manual may be periodically updated without notice. Please check the Supermicro website

for possible updates to the manual revision level.

Warnings

Special attention should be given to the following symbols used in this manual.

Warning! Indicates high voltage may be encountered when performing a procedure.

Warning! Indicates important information given to prevent equipment/property damage

or personal injury.

Contents

Chapter 1 Introduction

1.1 Overview ...............................................................................................................................8

1.2 Unpacking the System .........................................................................................................8

1.3 System Features ..................................................................................................................9

1.4 Server Chassis Features ....................................................................................................10

Control Panel ....................................................................................................................10

Front Features ...................................................................................................................12

Rear Features ...................................................................................................................12

1.5 Motherboard Layout ...........................................................................................................13

Quick Reference Table ......................................................................................................14

Chapter 2 Server Installation

2.1 Overview .............................................................................................................................17

2.2 Preparing for Setup ............................................................................................................17

Choosing a Setup Location ...............................................................................................17

Rack Precautions ..............................................................................................................17

Server Precautions ............................................................................................................18

Rack Mounting Considerations .........................................................................................18

Ambient Operating Temperature ....................................................................................18

Airow ............................................................................................................................18

Mechanical Loading .......................................................................................................18

Circuit Overloading ........................................................................................................19

Reliable Ground .............................................................................................................19

2.3 Installing the Rails ..............................................................................................................20

Identifying the Sections of the Rack Rails ........................................................................20

Assembling the Outer Rails ..............................................................................................20

Installing the Outer Rails onto the Rack ...........................................................................21

2.4 Installing the Server into a Rack ........................................................................................22

Installing the Chassis into a Telco Rack ...........................................................................23

Chapter 3 Maintenance and Component Installation

3.1 Removing Power ................................................................................................................24

3.2 Accessing the System ........................................................................................................24

Produkt Specifikationer

Mærke:	Supermicro
Kategori:	Server
Model:	SuperServer 1019P-WTR
Bredde:	437 mm
Dybde:	597 mm
Højde:	43 mm
Vægt:	7030 g
Produktfarve:	Sort
Pakkevægt:	12250 g
Opbevaringstemperatur (T-T):	-40 - 60 °C
Relativ luftfugtighed ved drift (H-H):	8 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	2
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Ethernet LAN:	Ja
Driftstemperatur (T-T):	10 - 35 °C
Ethernet LAN-datahastigheder:	10000 Mbit/s
Harmoniseret systemkode (HS):	84714100
Processorserie:	Intel® Xeon®
Maksimal intern hukommelse:	768 GB
On-board grafikkort, model:	Aspeed AST2500
Medfølgende software:	Intel® Node Manager\nIPMI 2.0\nKVM w/ dedicated LAN\nNMI\nSPM, SUM\nSuperDoctor® 5\nWatch Dog
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	10 Gigabit Ethernet
Indbygget processer:	Ingen
Kobber ethernet kabelteknologi:	10GBASE-T
Antal understøttede lagerdiske:	10
Antal serielle porte:	2
Kabinettype:	Stativ (1U)
Strømforsyning:	500 W
Processor sokkel:	LGA 3647 (Socket P)
PCI Express slots version:	3.0
Fejlkorrigerende kode:	Ja
PCI Ekspres x8 slots:	1
PCI Express x16 slots:	2
Redundant strømforsyning:	Ja
Kompatibel processor serie:	Intel® Xeon®
Bundkort chipsæt:	Intel C622
Understøttede hukommelsestyper:	DDR4-SDRAM
Antal SATA III-stik:	10
LAN Kontroller:	Intel X557, Intel X772
Understøttede lagerdrev brugerflader:	Serial ATA III
BIOS-type:	AMI
BIOS-hukommelsesstørrelse:	32 Mbit
RAID-niveauer:	0, 1,5, 10
Antal understøttede processorer:	1
Understøttede lagerdisk størrelser:	2.5 "
Hot-swap HDD båse:	Ja
Antal DIMM-slots:	6
Understøttet RDIMM-clockhastigheder:	2133,2400,2666 MHz
Antal installerede strømforsyninger:	1
IPMI LAN (RJ-45) port:	Ja
Maksimal RDIMM hukommelse:	192 GB
System bustype:	HyperTransport
