Board Layout

SuperServer 1028UX Series Quick Reference Guide

Rear View

CPU Installation

Beep Codes

Front View & Interface



Heatsink Installation

1. Place the heatsink on top of the installed CPU.

2. Align the four screws to the socket.

3. Holding the heatsink in place, screw down as shown

(cross pattern, in order: A, C, B, D).

4. Note: Only use 6-8 lb/f of torque; otherwise, hand-tighten

each screw to avoid damaging the CPU.

Memory

Caution

Align CPU to socket;

install CPU straight down

NOTE:

Do not bend pin inside socket



SAFETY INFORMATION

IMPORTANT: See installation instructions and safety warning

before connecting system to power supply.

http://www.supermicro.com/about/policies/safety_information.cfm

WARNING:

To reduce risk of electric shock/damage to equipment,

disconnect power from server by disconnecting all power

cords from electrical outlets.

If any CPU socket empty, install protective plastic CPU cap

CAUTION:

Always be sure all power supplies for this system have

the same power output. If mixed power supplies are

installed, the system will not operate.

For more information go to :

http://www.supermicro.com/support



Power LED

Device Activity LED

LAN1 LED & LAN2 LED

Universal Information LED

Power Button

UID Button

Hard Drive Signal

Hard Drive Fail

Descrip iot nNo.

HDD 1

(S A3)AT

HDD 3

(S A3)AT

HDD 5

(S A3)AT

HDD 0

(S A3)AT

HDD 2

(S A3)AT

HDD 4

(S A3)AT

HDD 6

(S A3)AT

HDD 8

(S A3)AT

(S A3/AT

NVMe)*

Descrip iot n

No.

SXB1_1/1_2/1_3: PCI-E 3.0 (x16 + x16) Left Riser Card Slot

SXB2: PCI-E 3.0 (x8) Center Riser Card Slot

JBT1: CMOS Clear

S-SATA0~3: SATA 3.0 Ports (Intel SCU)

I-SATA0~5: SATA 3.0 Ports (Intel PCH)

JSD1/JSD2: SATA DOM (Device_on_Module) Power Connectors

SXB3_1/3_2/3_3: PCI-E 3.0 (x8 internal) Right Ultra Riser Card Slot

P1-DIMMA1(Blue)/P1-DIMMA2 slot

P1-DIMMB1(Blue)/P1-DIMMB2 slot

CPU1 (Install CPU1 first)

P1-DIMMD1(Blue)/P1-DIMMD2 slot

P1-DIMMC1(Blue)/P1-DIMMC2 slot

P2-DIMME1(Blue)/P2-DIMME2 slot

P2-DIMMF1(Blue)/P2-DIMMF2 slot

CPU2

P2-DIMMH1(Blue)/P2-DIMMH2 slot

P2-DIMMG1(Blue)/P2-DIMMG2 slot

HDD 7

(S A3)AT

HDD 9

(S A3)AT

(S A3/AT

NVMe)*

2 14 3

Descrip iot n

No.

19 3

28 67 4

2 PCI-E 3.0 p1-x16 (CPU1/CPU2) Expansion Slots

(Full-height 4.2”, Length 10.5”)

PCI-E 3.0 p1-x8 (CPU2) Expansion Slot

( Low Profile (2.536”), Half Length (6.6”))

VGA Port

UID Button (Unit Identifier Button)

COM Port

Dedicated LAN for IPMI

USB 3.0 Ports

LAN Ports (4)

Redundant Power Supply Module

Screw #B Screw #A

Screw #C Screw #D

* r N M els Fo od

X10DRU-X

I-SGPIO2

JF1

JL1

DESIGNED IN USA

JUSBA1

JBAT1

JBT1

JSD 2

JSD1

SP1

LED_H1

LED_G2

LED_G1

LED_H2

LED_F2

LED_E1

LED_E2

LED_F1

LED_C2

LED_C1

LED_D1

LED_B2

LED_A1

LED_A2

JIPMB1

FAN8

FAN7

FAN6

FAN5 FAN4 FAN3 FAN2 FAN1

JVRM2

JVRM1

JWD2

JPG1

JPB1

LED1

JUIDB2

SXB3_2

PSU2 PSU1

JGPW2

JGPW3

JGPW1

JPW22JPW23

JPW21

JGPW4

JPW19

JTPM1

SXB1_3

SXB3_3

SXB1_1

SXB3_1

P2-DIMMG2

P2-DIMMG1

P2-DIMMH1

P2-DIMMH2

CPU2

SXB1B

SXB1C

SXB1A

CPU1_PORT3CPU2_PORT2 USB3/4 (3.0)

JPME2

GPU PWR3GPU PWR2

CPU2_PORT1

SXB2

VGA

P2-DIMMF2

P2-DIMMF1

GPU PWR4

I-SATA4

P2-DIMME2

P2-DIMME1

I-SATA5

S-SATA0~3

COM1

I-SATA0~3

IPMI_LAN

USB 0/1(3.0)

CPU1_PORT2

P1-DIMMC1

P1-DIMMC2

P1-DIMMD2

P1-DIMMD1

CPU2_PORT3CPU1_PORT1

CPU1

P1-DIMMB2

P1-DIMMB1

P1-DIMMA2

GPU PWR1

P1-DIMMA1

BP PWR2 BP PWR1

CLOSE 1st

OPEN 1st

CLOSE 1st

OPEN 1st

SXB1_2

PLD1

C612

LED_D2

LED2HDD_LED1

LED_B1

BMC

BMC_HB_LED1

JA1

910

1215 13

12 3 46 75

For memory to work properly, follow the tables below for memory installation.

Pro sors and their Co s ng mory M les ces rre pondi Me odu

CPU# Corresponding DIMM Modules

CPU 1 P1-DIMMA1 P1-DIMMB1 P1-DIMMC1 P1-DIMMD1

CPU2 P2-DIMME1 P2-DIMMF1 P2-DIMMG1 P2-DIMMH1

Pro sor and mory M le lat n for Optimal P fo anceces Me odu Popu io er rm

Number of

CPUs+DIMMs

1 CPU &

2 DIMMs

CPU1

P1-DIMMA1/P1-DIMMB1

1 CPU &

4 DIMMs

CPU1

P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1

2 CPUs &

4 DIMMs

CPU1 + CPU2

P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1

2 CPUs &

6 DIMMs

CPU1 + CPU2

P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1

2 CPUs &

8 DIMMs*

CPU1 + CPU2

P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-DIMMG1

/P2-DIMMH1

2 CPUs &

10~16 DIMMs

CPU1 + CPU2

P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-DIMMG1

/P2-DIMMH1 + Any memory pairs in P1, P2 DIMM slots

2 CPUs &

16 DIMMs

CPU1 + CPU2

P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-DIMMG1

/P2-DIMMH1, P1-DIMMA2/P1-DIMMB2/P1-DIMMC2/P1-DIMMD2, P2-DIMME2/P2-DIMMF2

/P2-DIMMG2/P2-DIMMH2

Beep Code/LED Error Message Description

1 beep Refresh Ready to boot

5 short beeps + 1 long beep Memory error No memory detected in the system

5 beeps No Con-In or No

Con-Out devices

Con-In: USB or PS/2 keyboard, PCI or Serial

Console Redirection, IPMI, KVM or SOL

Con-Out: Video Controller, PCI or Serial

Console Redirection, IPMI, SOL

1 beep per device Refresh 1 beep for each USB device

Rev 1.0a

Note:

1028UX-LL1 includes 2643 v3/v4, 1028UX-LL2 includes 2687W v3/v4 and 1028UX-LL3 includes 2689 v4

Pre-populated with 8 * 8GB memory DIMMs.

By default BIOS is set to force memory to highest frequency 2133/2400 (v3/v4) whether its 1DPC or 2DPC

CPU and Memory Population Configuration Table

(For memory to work properly, follow the instructions below)

Populating RDIMM/LRDIMM DDR4 Memory Modules

Type

Ranks

Per DIMM

and Data

Width

DIMM Capacity

(GB)

Speed (MT/s); Voltage (V); Slots per Channel (SPC) and

DIMMs per Channel (DPC)

2 Slots per Channel

1 DPC 2 DPC

E5-2600 V3 E5-2600 V4 E5-2600 V3 E5-2600 V4

4 GB 8 GB 1.2 V 1.2 V 1.2 V 1.2 V

RDIMM SRx4 8 GB 16 GB 2133 2400 1866 2133

RDIMM SRx8 4 GB 8 GB 2133 2400 1866 2133

RDIMM DRx8 8 GB 16 GB 2133 2400 1866 2133

RDIMM DRx4 16 GB 32 GB 2133 2400 1866 2133

LRDIMM QRx4 32 GB 64 GB 2133 2400 2133 2400

LRDIMM 3DS 8Rx4 64 GB 128 GB 2133 2400 2133 2400
