FatTwin®
F628R3-RC1B+
F628R3-RC1BPT+
USER’S MANUAL
Revision 1.0a
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and
documentation, is the property of Supermicro and/or its licensors, and is supplied only under a
license. Any use or reproduction of this product is not allowed, except as expressly permitted by
the terms of said license.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Manual Revision 1.0a
Release Date: July 22, 2016
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2016 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians.
It provides information for the installation and use of the FatTwin™
F628R3-RC1B+/RC1BPT+. Installation and maintenance should be performed
by experienced technicians only.
The FatTwin F628R3-RC1B+/RC1BPT+ is a high-end server based on the
F424AS-R1K28BP 4U rackmount chassis and the dual processor X10DRFR-N/NT
serverboard. All models have an IPMI LAN port and four serverboard nodes with
eight hot-swap 3.5" SAS/SATA/NVMe Hard Disk Drives (HDD) per node.
The difference between the FatTwin F628R3-RC1B+ and FatTwin F628R3-RC1BPT+
is that the F628R3-RC1BPT+ has 10-Gigabit LAN ports and the F628R3-RC1B+
has only 1-Gigabit LAN ports.
Manual Organization
Chapter 1: Introduction
The fi rst chapter provides a checklist of the main components included with the
server system and describes the main features of the X10DRFR-N/NT serverboard
and the F424AS-R1K28BP chassis.
Chapter 2: Server Installation
This chap ter desc ribes the steps n ecessary to install the FatTwin
F628R3-RC1B+/RC1BPT+ into a rack and check out the server confi guration
prior to powering up the system. If your server was ordered without processor and
memory components, this chapter will refer you to the appropriate sections of the
manual for their installation.
Chapter 3: System Interface
Refer here for details on the system interface, which includes the functions and
information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview of
safety precautions that should be followed when installing and servicing the FatTwin
F628R3-RC1B+/RC1BPT+.
FatTwin F628R3-RC1B+/RC1BPT+ User's Manual
iv
Chapter 5: Advanced Serverboard Setup
Chapter 5 provides detailed information on the X10DRFR-N/NT serverboard,
including the locations and functions of connections, headers and jumpers. Refer
to this chapter when adding or removing processors or main memory and when
reconfi guring the serverboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the F424AS-R1K28BP server chassis.
You should follow the procedures given in this chapter when installing, removing or
reconfi guring SATA or peripheral drives and when replacing system power supply
units and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed information
on running the CMOS Setup Utility.
Appendix A: System Specifi cations
v
FatTwin F628R3-RC1B+/RC1BPT+ User's Manual
Notes
vi
Table of Contents
Chapter 1 Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Serverboard Features ..................................................................................... 1-2
Processors ...................................................................................................... 1-2
Memory ........................................................................................................... 1-2
Serial ATA ....................................................................................................... 1-3
SAS ................................................................................................................. 1-3
Expansion Slots .............................................................................................. 1-3
Onboard Controllers/Ports .............................................................................. 1-4
Graphics Controller ......................................................................................... 1-4
Aspeed AST2400 Controller .......................................................................... 1-4
Other Features Supported by the Aspeed AST2400 Controller ................ 1-4
Power Cable .................................................................................................... 1-5
Super I/O ......................................................................................................... 1-5
1-3 Server Chassis Features ................................................................................ 1-5
System Power ................................................................................................. 1-5
SAS/SATA/NVMe Subsystem ......................................................................... 1-6
Front Control Panel ......................................................................................... 1-6
I/O Ports .......................................................................................................... 1-6
Cooling System ............................................................................................... 1-6
Air Shrouds ..................................................................................................... 1-6
Mounting Rails ................................................................................................ 1-6
NVMe .............................................................................................................. 1-7
1-4 Advanced Power Management ....................................................................... 1-7
Intel® Intelligent Power Node Manager (NM) ................................................. 1-7
Manageability Engine (ME) ............................................................................. 1-7
1-5 Contacting Supermicro .................................................................................... 1-9
1-6 Fat Twin: System Notes ................................................................................ 1-10
Nodes ............................................................................................................ 1-10
System Power ............................................................................................... 1-10
SAS/SATA Backplane/Drives ........................................................................ 1-10
Chapter 2 Server Installation
2-1 Overview ......................................................................................................... 2-1
2-2 Unpacking the System .................................................................................... 2-1
2-3 Preparing for Setup ......................................................................................... 2-1
2-4 Cautions! ......................................................................................................... 2-2
FatTwin F628R3-RC1B+/RC1BPT+ User's Manual
vii
Choosing a Setup Location ............................................................................. 2-2
Rack Precautions ............................................................................................ 2-2
Server Precautions .......................................................................................... 2-2
Rack Mounting Considerations ....................................................................... 2-3
Ambient Operating Temperature ................................................................ 2-3
Reduced Airfl ow ......................................................................................... 2-3
Mechanical Loading ................................................................................... 2-3
Circuit Overloading ..................................................................................... 2-3
Reliable Ground ......................................................................................... 2-4
2-5 Rack Mounting Instructions ............................................................................. 2-4
Identifying the Sections of the Rack Rails ...................................................... 2-4
Adjusting the Rails .......................................................................................... 2-5
Installing the Rails on a Rack ......................................................................... 2-6
Chassis Installation ......................................................................................... 2-7
2-6 Checking the Serverboard Setup .................................................................... 2-8
2-7 Checking the Drive Bay Setup ........................................................................ 2-9
Chapter 3 System Interface
3-1 Overview ......................................................................................................... 3-1
3-2 Control Panel Buttons ..................................................................................... 3-2
3-3 Control Panel LEDs ........................................................................................ 3-3
Information LED .............................................................................................. 3-3
3-4 Drive Carrier LEDs .......................................................................................... 3-4
Chapter 4 Standardized Warning Statements for AC Systems
4-1 About Standardized Warning Statements ....................................................... 4-1
Warning Defi nition ........................................................................................... 4-1
Installation Instructions .................................................................................... 4-4
Circuit Breaker ................................................................................................ 4-5
Power Disconnection Warning ........................................................................ 4-6
Equipment Installation ..................................................................................... 4-8
Restricted Area ................................................................................................ 4-9
Battery Handling ............................................................................................ 4-10
Redundant Power Supplies .......................................................................... 4-12
Backplane Voltage ........................................................................................ 4-13
Comply with Local and National Electrical Codes ........................................ 4-14
Product Disposal ........................................................................................... 4-15
Hot Swap Fan Warning ................................................................................. 4-16
Power Cable and AC Adapter ...................................................................... 4-18
Table of Contents
viii
Chapter 5 Advanced Serverboard Setup
5-1 Handling the Serverboard ............................................................................... 5-1
Precautions ..................................................................................................... 5-1
Unpacking ....................................................................................................... 5-1
5-2 Connecting Cables .......................................................................................... 5-2
Connecting Data Cables ................................................................................. 5-2
5-3 Control Panel Connectors and I/O Ports ........................................................ 5-2
5-4 Processor and Heatsink Installation................................................................ 5-3
Installing a Passive Heatsink .......................................................................... 5-7
Removing the Passive Heatsink ..................................................................... 5-8
5-5 Installing Memory ............................................................................................ 5-9
Removing Memory Modules ........................................................................... 5-9
Memory Support ............................................................................................ 5-10
5-6 Adding PCI Expansion Cards ....................................................................... 5-12
5-7 Serverboard Details ...................................................................................... 5-13
5-8 Connector Defi nitions .................................................................................... 5-16
5-9 Jumper Settings ............................................................................................ 5-19
Explanation of Jumpers ................................................................................ 5-19
5-10 Onboard Indicators ........................................................................................ 5-22
5-11 PCI-Express and Serial ATA Connections .................................................... 5-24
5-12 Installing Drivers ............................................................................................ 5-25
SuperDoctor 5 ............................................................................................... 5-26
5-13 Serverboard Battery ...................................................................................... 5-28
Chapter 6 Advanced Chassis Setup
6-1 Static-Sensitive Devices .................................................................................. 6-1
Precautions ..................................................................................................... 6-1
Unpacking ....................................................................................................... 6-1
6-2 Control Panel .................................................................................................. 6-2
6-3 Removing the Power Cord .............................................................................. 6-3
6-4 Removing Nodes from the Chassis ................................................................ 6-3
6-5 Installing and Removing Hard Drives ............................................................. 6-4
6-6 Removing the Node Cover.............................................................................. 6-9
6-7 Node Confi guration ....................................................................................... 6-10
Overview of the Node ................................................................................... 6-10
6-8 Removing and Installing the Backplane .........................................................6-11
Removing the Backplane ...............................................................................6-11
Installing the Backplane ................................................................................ 6-13
6-9 Adapter Card Replacement........................................................................... 6-14
FatTwin F628R3-RC1B+/RC1BPT+ User's Manual
Chapter 1
Introduction
1-1 Overview
The FatTwin F628R3-RC1B+/RC1BPT+ is a high-end server comprised of two main
subsystems: the F424AS-R1K28BP 4U server chassis and the X10DRFR-N/NT
dual processor serverboard in four hot-swap nodes. Please refer to our web site for
information on operating systems that have been certifi ed for use with the system
(www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have
been included with the FatTwin F628R3-RC1B+/RC1BPT+ server, as listed below:
• Heat Sinks
• Four (4) 2U passive CPU heat sinks for rear CPU (SNK-P0048P)
• Four (4) 2U passive CPU heat sinks for front CPU (SNK-P0048PS)
• Four (4) Plastic air shrouds (MCP-310-42403-0N)
• Eight (8) 80x80x38-mm chassis middle cooling fans (FAN-0129L4)
• Four (4) power distribution boards (BPN-ADP-F418LS)
• SATA backplanes and accessories:
• Four (4) LSI 3108 adapter cards for eight (8) SAS3 ports via two mini-SAS
HD connectors (BPN-ADP-8S3108-1UF)
• Four (4) Backplanes for two (2) 3.5" HDD (BPN-SAS3-F424-A2N2)
• Four (4) Backplanes for six (6) 3.5" HDD (BPN-SAS3-F424-A6)
• Thirty-two (32) hot-swap 3.5" HDD trays (MCP-220-00094-0B)
• Four (4) 40-cm 18AWG 4-pin to 4-pin PDB to MB power cables (CBL-0480L)
• Four (4) 7.5-cm 28AWG 20-pin to 20-pin cables (CBL-OTHR-0022L)
• Four (4) 25-cm 30AWG internal mini-SAS to mini-SAS HD cables (CBL-
SAST-0550)
• Four (4) 15/59-cm 30AWG internal RA reverse mini-SAS HD to 2x mini-SAS
HD Y-splitter cables (CBL-SAST-0691)
• Eight (8) 15-cm 18AWG 2x2 to 2x2 power cables (CBL-0486L)
• One (1) F418/F424 Rail set (MCP-290-41803-0N)
Chapter 1: Introduction
1-1
1-2
FatTwin F628R3-RC1B+/RC1BPT+ User's Manual
Note: For your system to work properly, please follow the links below to download
all necessary drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety information:
http://www.supermicro.com/about/policies/safety_information.cfm
• If you have any questions, please contact our support team at:
support@supermicro.com
1-2 Serverboard Features
A t t h e h e a r t o f t h e F a t Tw i n F 6 2 8 R 3 - R C 1 B +/ RC 1 B P T + l i e s t h e
X10DRFR-N/NT, a dual processor serverboard based on the Intel®
C612 chipset and designed to provide maximum performance. Four of these
serverboards can be mounted in the F424AS-R1K28BP chassis.
The sections below cover the main features of the X10DRFR-N/NT serverboard
(see Figure 1-1 for a block diagram of the chipset).
Processors
The X10DRFR-N/NT supports single or dual Intel® Xeon® E5-2600 v3/v4 series
processors (Socket R3 LGA 2011). Each processor supports four full-width Intel
QuickPath Interconnect (QPI) links, with support of up to 25.6 GT/s per QPI link
and with Data Transfer Rate of up to 9.6 GT/s per direction. Please refer to the
serverboard description pages on our web site for a complete listing of supported
processors (www.supermicro.com).
Memory
Each X10DRFR-N/NT serverboard node has sixteen (16) DIMM slots of
4-channel 240-pin memory supporting up to 2 TB of 3DS LRDIMM ECC,
1 TB of RDIMM registered ECC DDR4-2400/2133/1866/1600 MHz SDRAM in
64GB or 128 GB (3DS LRDIMM only) size at 1.2V voltage. See Chapter 5 for
details.
Note: For the latest CPU/memory updates, please refer to our website at
http://www.supermicro.com/products/serverboard.
1-4
FatTwin F628R3-RC1B+/RC1BPT+ User's Manual
Onboard Controllers/Ports
One Fast UART 16550 serial port is located on the serverboard. The color-coded
I/O ports include a VGA (monitor) port, two USB 3.0 ports, an IPMI dedicated LAN
port and two Gigabit or 10GBased-T Ethernet ports.
Note: For IPMI Confi guration Instructions, please refer to the Embedded IPMI
Configuration User's Guide available @ http://www.supermicro.com/support/
manuals/.
Graphics Controller
The X10DRFR-N/NT features an integrated Aspeed AST2400 BMC Controller for
onboard graphics capability.
Aspeed AST2400 Controller
Note: The term "IPMI controller" and the term "BMC controller" can be used
interchangeably in this section.
The Aspeed AST2400 Controller, a Baseboard Management Controller (BMC),
supports 2D/VGA-compatible Graphic Cores with PCI interface, creating multi-media
virtualization via Keyboard/Video/Mouse Redirection (KVMR). The WPCM450R
Controller is ideal for remote system management.
The Aspeed AST2400 Controller interfaces with the host system via PCI connections
to communicate with the graphics cores. It supports USB 3.0 and 2.0 for remote
keyboard/mouse/virtual media emulation. It also provides LPC interface support to
control Super IO functions. The Aspeed AST2400 is connected to the network via
an external Ethernet PHY module or shared NCSI connections.
The Aspeed AST2400 communicates with onboard components via six SMBus
interfaces, PECI (Platform Environment Control Interface) buses, and General
Purpose I/O ports.
Other Features Supported by the Aspeed AST2400 Controller
The Aspeed AST2400 supports the following features:
• IPMI 2.0
• Serial over LAN
• KVM over LAN
• LAN Alerting-SNMP Trap
• Event Log
• X-Bus parallel interface for I/O expansion
1-5
Chapter 1: Introduction
• Multiple ADC inputs, Analog and Digital Video outputs
• SPI Flash Host BIOS and fi rmware bootstrap program supported
• Reduced Media Independent Interface (RMII)
• OS (Operating System) Independency
• Provides remote Hardware Health Monitoring via IPMI. Key features
• Provides Network Management Security via remote access/console redirection.
• Supports the following Management tools: IPMIView, CLI (Command Line
Interface)
• RMCP+ protocol supported
Note: For more information on IPMI confi guration, please refer to the IPMI User's
Guide posted on our website at http://www.supermicro.com/support/manuals/.
Power Cable
The power cables are wired on the power adapter card (BPN-ADP-F418LS). Please
connect the onboard power cable to the serverboard to provide power to the system.
Super I/O
The Super I/O provides functions that comply with ACPI (Advanced Confi guration
and Power Interface), which includes support of legacy and ACPI power
management through an SMI or SCI function pin. It also features auto power
management to reduce power consumption.
1-3 Server Chassis Features
The following is a general outline of the main features of the F424AS server chassis.
System Power
Each F424AS chassis model includes four high-effi ciency 95%+ Platinum certifi ed
redundant power supplies, each rated at 1280 W. In the unlikely event your power
supply fails, replacement is simple and can be accomplished without tools.
2-2
FatTwin F628R3-RC1B+/RC1BPT+ User's Manual
2-4 Cautions!
Choosing a Setup Location
• Leave enough clearance in front of the rack to enable you to open the front door
completely (~25 inches) and approximately 30 inches of clearance in the back
of the rack to allow for suf cient air ow and ease in servicing.
• This product is for installation only in a Restricted Access Location (dedicated
equipment rooms, service closets and the like).
• This product is not suitable for use with visual display work place devices
according to §2 of the German Ordinance for Work with Visual Display Units.
Rack Precautions
• Ensure that the leveling jacks on the bottom of the rack are fully extended to
the oor with the full weight of the rack resting on them.
• In single rack installation, stabilizers should be attached to the rack. In multiple
rack installations, the racks should be coupled together.
• Always make sure the rack is stable before extending a component from the
rack.
• You should extend only one component at a time - extending two or more
simultaneously may cause the rack to become unstable.
Server Precautions
• Review the electrical and general safety precautions in Chapter 4.
• Determine the placement of each component in the rack before you install the
rails.
• Install the heaviest server components on the bottom of the rack rst, and then
work up.
• Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a
power failure.
• Allow any hot plug drives and power supply modules to cool before touching
them.
• Always keep the rack's front door and all panels and components on the servers
closed when not servicing to maintain proper cooling.
