X10SDV

Mini-ITX Series

USER’S MANUAL

1.0c

The information in this user’s manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

and makes no commitment to update or to keep current the information in this manual, or to notify

any person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and docu-

mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.

Any use or reproduction of this product is not allowed, except as expressly permitted by the terms

of said license.

IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,

SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE

USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF

THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.

SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED

WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,

INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between the manufacturer and the customer shall be governed by the laws of

Santa Clara County in the State of California, USA. The State of California, County of Santa Clara

shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for

all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class

A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the manufacturer’s instruction manual, may cause harmful

interference with radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference, in which case you will be required to correct the interference at your

own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Manual Revision: 1.0c

Release Date: February 12, 2020

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

Produkt Specifikationer

Mærke:	Supermicro
Kategori:	Bundkort
Model:	X10SDV-12C-TLN4F+
Bredde:	170 mm
Dybde:	170 mm
Ethernet LAN-porte (RJ-45):	5
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Ethernet LAN:	Ja
Processorkerner:	12
Driftstemperatur (T-T):	0 - 60 °C
Lyd-output kanaler:	- kanaler
Strømkilde type:	ATX
Harmoniseret systemkode (HS):	84733020
Processorfrekvens:	1.5 GHz
Medfølgende software:	Intel Node Manager\nIPMI 2.0\nKVM with dedicated LAN\nNMI\nSUM\nSuperDoctor 5
Processorproducent:	Intel
Processormodel:	D-1557
Antal VGA-porte (D-sub):	1
Processor sokkel:	BGA 1667
Thermal Design Power (TDP):	45 W
Kompatibel processor serie:	Intel® Xeon®
Understøttede hukommelsestyper:	DDR4-SDRAM
Antal hukommelsesstik:	4
Hukommelses slots type:	DIMM
Understøttede hukommelsesclock-hastigheder:	1600,1866,2133 MHz
Antal M.2 (M) slots:	1
Antal SATA III-stik:	6
LAN Kontroller:	Intel I350-AM2, Realtek RTL8201N
USB 2.0-stik:	2
Antal COM-stik:	1
ATX strømstrik (24 stikben):	Ja
Motherboard form faktor:	mini ITX
BIOS-type:	AMI
BIOS-hukommelsesstørrelse:	128 Mbit
ACPI-version:	5.0
RAID-niveauer:	0, 1,5, 10
Hukommelsesspænding:	1.2 V
PCI Ekspres x16 (Gen 3.x) slots:	1
TPM-stik:	Ja
PC sundhedsovervågning:	FAN, LED, Power supply, Temperature, Voltage
System Management BIOS (SMBIOS) version:	2.8
Maksimal RDIMM hukommelse:	128 GB
Maksimal UDIMM hukommelse:	64 GB
Watch Dog funktion:	Ja
Realtidsur (RTC):	Ja
UEFI-version:	2.4
