SUPERMICR R

ContaCt nformatIon I

• Manuals: http://www.supermicro.com/support/manuals

• Drivers & Utilities: https://www.supermicro.com/wdl/driver/

• Safety: http://www.supermicro.com/about/policies/safety_information.cfm

consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.

P CaCkage ontents

X12sDV-4C/8C/10C-sPt4f

Q r g 1.0uICk eferenCe uIDe a

• One Supermicro Motherboard

• One Quick Reference Guide

• One I/O Shield

• One COM Port Cable

• Website: www.supermicro.com

• General Information: marketing@supermicro.com

• Technical Support: support@supermicro.com

• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008

f or your system to work ProPerly Please DownloaD aPProPrIate,

DrIVers Images user s manual from the lInks below/ / ' :

MNL-2478-QRG-10a

WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproductive harm. For more information, go

to www.P65Warnings.ca.gov.

• One OCuLink to U.2 Cable

• One ATX Power Signal Cable

• One OCuLink to four SATA

Cables

M-KEY

2-3:POWER FORCE ON

1-2:NORMAL

JPF1:

1-2 OPEN:ENABLE

1-2 SHORT:DISABLE

JBM1:IPMI Share LAN

JPI2C1:PWR I2C

:1-4 SPEAKER

IPMI_LAN

:SMBus1

USB 0/1

USB 2/3(3.0)

2-3:ME MANUFACTURING MODE

1-2:NORMAL

JPME2:

JRK1:RAID KEY-1

PWR

RST

CPU SLOT7 PCIe 4.0 X8

JMD1:M.2-HC PCIe 4.0 X4/SATA 3.0

TPM/PORT80

NIC2

JF1:

1-2:ENABLE

2-3:DISABLE

JPT1:TPM

NIC1

JWD1:WATCH DOG

LED LED

HDD PWR

2-3:NMI

1-2:RST

2-3:DISABLE

JPG1:VGA

1-2:ENABLE

VGA

CPU

LAN3/4

CHASSIS INTRUSION

LAN1/2

: CMOS Clear

DIMMB1

DIMMA1

JPTG1:10Gb LAN

1-2:ENABLE

2-3:DISABLE

X12SDV-4C-SPT4F

REV:1.00

PRESS FIT

BAR CODE

DESIGNED IN USA

JMD1

MH2

MH4 MH3

MH1

JPCIe7

LEDT4

LEDT2

JGP1

P1_NVME0

JSMB1

JMD1_SRW1

JIPMB1

JD1

JUIDB1

JRK1

JTPM1

FANA

FAN2

FAN1

COM1

JVRM1

JPTG1

JPME2

JWD1

JPG1

JPF1

JPT1

JBT1

JPI2C1

JL1

JBM1

LEDT3

LEDT1

LEDM1

BT1

JPH1

LED2

LED3

LED1

JPV1

JF1

PJ1

Jumpers and Connectors

CPU and Memory Support

Motherboard Layout and Features

Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this guide. Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors,

and LED indicators.

Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/

motherboard installation instructions.

= mounting hole

Jumper Description Default Setting

JBM1 IPMI Shared LAN Enable/Disable Open (Enabled)

JBT1 CMOS Clear Open (Normal)

JPG1 VGA Enable/Disable Pins 1-2 (Enabled)

JPME2 ME Manufacturing Mode Pins 1-2 (Normal)

JPT1 Onboard TPM 2.0 Enable/Disable Pins 1-2 (Enabled)

JPTG1 LAN1/2 Enable/Disable Pins 1-2 (Enabled)

JWD1 Watchdog Timer Pins 1-2 (Reset)

LED Description Status

LED1 Power LED Solid Green: Power On

LED2 UID LED Solid Blue: Unit Identied

LED3 Overheat/PWR Fail/

Fan Fail

Solid Red: Overheat

Blinking Red: PWR Fail or Fan

Fail

LEDM1 BMC Heartbeat LED Blinking Green: BMC Normal

Connector Description

BT1 Onboard Battery

COM1 COM Header

FAN1-FAN2, FANA CPU/System Fan Headers

IPMI LAN Dedicated IPMI LAN Port

JD1 Internal Speaker Header (Pins 1-4: Speaker)

JF1 Front Control Panel Header

JGP1 General Purpose I/O Header

JIPMB1 4-pin BMC External I²C Header

JL1 Chassis Intrusion Header

JMD1 M.2 M-Key 2280 (PCIe 4.0 x4/SATA 3.0) Slot

JMD1_SRW1 M.2 Mounting Hole

JPH1 4-pin HDD Power Connector

JPI2C1 Power System Management Bus I

2C Header

JPV1 8-pin 12V DC Power Input (Required for 12V only or 24-pin

ATX Power)

JRK1 Intel® RAID Key Header

JSMB1 System Management Bus Header

JTPM1 Trusted Platform Module/Port 80 Connector

JUIDB1 Unit Identier Switch

LAN1/2 10GbE Base-T RJ45 LAN Ports

LAN3/4 25GbE SFP28 LAN Ports

P1_NVME0 PCIe 3.0 p1-x4 OCuLink Connectors (Support PCIex4 or 4xSATA)

PJ1 ATX Power Signal Header (Supermicro P/N for cable: CBL-

PWEX-1063)

SLOT7 PCIe 4.0 p1-x8 Slot

USB0/1 USB 2.0 Header

USB2/3 Back Panel USB 3.0 Ports

VGA VGA Port

Front Control Panel

LED Indicators

Power Button

OH/Fan Fail LED

NIC1 Activity LED

Reset Button

HDD LED

PWR LED

Reset

PWR

3.3V Stby

Ground

3.3V Stby

1 2

Ground

NIC2 Activity LED

PWR Fail LED

UID

3.3V

3.3V Stby

The X12SDV-4C/8C/10C-SPT4F motherboard supports the Intel Xeon D-1700

processor series with up to 10 cores and a thermal design power (TDP) of up

to 90W.

The motherboard supports up to 128GB of ECC and Non-ECC RDIMM/UDIMM

DDR4 memory with speeds of up to 2933MT/s in two memory slots.

Connectors

Jumpers

Back Panel I/O Connectors

# # #Description Description Description

1. IPMI_LAN 5. LAN1 9. UID Switch

2. USB3 6. LAN4

3. USB2 7. LAN3

4. LAN2 8. VGA

298

DIMM Memory Installation

When installing memory modules, the DIMM slots should be populated in the fol-

lowing order: DIMMA1, DIMMB1.

• It is recommended to use DDR4 memory of the same type, size, and speed.

• Mixed DIMM speeds can be installed. However, all DIMMs will run at the

speed of the slowest DIMM.

• The motherboard will support odd-numbered modules (one installed).

However, to achieve the best memory performance, a balanced memory

population is recommended.

Type Ranks Per DIMM

and Data Width

DIMM Capacity (GB) Speed (MT/s); Voltage (V);

Slot Per Channel (SPC) and

DIMM Per Channel (DPC)

8Gb 16 Gb 1DPC

RDIMM

SRx8 (RC D) 8GB 16GB

2933

SRx4 (RC C) 16GB 32GB

DRx8 (RC E) 16GB 32GB

DRx4 (RC A) 32GB 64GB

ECC UDIMM SRx8 8GB 16GB

Non-ECC

UDIMM DRx8 16GB 32GB
