SUPERMICR R

ContaCt nformatIon I

• Manuals: http://www.supermicro.com/support/manuals

• Drivers & Utilities: https://www.supermicro.com/wdl/driver/

• Safety: http://www.supermicro.com/about/policies/safety_information.cfm

consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.

P cackage ontents

X12SPO-NTF/-F

Quick Reference Guide Rev. 1.0c

• One Supermicro Motherboard

• Two SATA Cables

• One I/O Shield

• One Quick Reference Guide

• Website: www.supermicro.com

• General Information: marketing@supermicro.com

• Technical Support: support@supermicro.com

• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008

F or your system to work ProPerly Please download aPProPriate,

drivers images user s manual From the links below/ / ' :

MNL-2226-QRG-10c

WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproductive harm. For more information, go

to www.P65Warnings.ca.gov.

Connectors

Jumpers and Connectors

Back Panel I/O Connectors

Memory Support

Motherboard Layout and Features

Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this

guide.

Note: Refer to Chapter 2 of the User Manual for detailed information on jumpers, connectors,

and LED indicators.

Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/

motherboard installation instructions.

CPU Support

The X12SPO-NTF/-F motherboard supports a 3rd generation Intel® Xeon Scalable

Processors (Socket P+ (LGA4189)) processors with up to 40 cores and a thermal

design power (TDP) of up to 270W.

Jumper Description Default Setting

JBT1 CMOS Clear Open (Normal)

JPL1 LAN1/LAN2 Enable Pins 1-2 (Enabled)

Pins 2-3 (Disabled)

JPME2 ME Manufacturing Mode Pins 1-2 (Normal)

JWD1 Watch Dog Timer Pins 1-2 (Reset)

Pins 2-3 (NMI)

Connector Description

BT1 Onboard CMOS Battery (To Clear CMOS, remove the battery,

short pins 1-2 for more than 10 seconds and install the battery.)

COM1/COM2 COM Port/COM Header

FAN1 - FAN5, FANA, FANB CPU/System Fan Headers

I-SATA0 - I-SATA7 Intel® PCH SATA 3.0 Ports (with RAID 0, 1, 5, 10)

IPMI_LAN Dedicated IPMI LAN Port

JD1 Power LED/Speaker (Pins 1-4: Speaker)

JF1 Front Control Panel Header

JIPMB1 4-pin BMC External I2C Header (for an IPMI card)

JL1 Chassis Intrusion Header

JNCSI1 NC-SI Header for IPMI Support

JNVI2C1 NVMe I²C Header

JPI2

C1 Power Supply SMBus I2C Header

JPWR1 24-pin ATX Power Connector

JPWR2 8-pin Power Connector

JPWR3 4-pin Power Connector

JRK1 Intel RAID Key Header

JSD1, JSD2 SATA DOM Power Connectors

JSEN1 System Front Inlet Temperature Sensor Header

JSTBY1 Standby Power Header

JTPM1 Trusted Platform Module/Port 80 Connector

LAN1, LAN2 LAN 10G/1G Base-T

(Intel X550 for 10G [-NTF] or I350 for 1G[-F]) Ports

M.2-H_1, M.2-H_2 M.2 M-Key 2280/22110 (supports PCIe 3.0 x4/SATA3) Slot

NVMe0 - NVMe9 PCIe 4.0 p1-x8 Slimline SAS Connectors

(NVMe4~9 for -NTF only)

SLOT6 CPU PCIe 4.0 X16 Slot

SP1 Onboard Buzzer

S-SATA0, S-SATA1 SATA 3.0 Ports with SATA DOM Power

S-SGPIO1 Serial Link General Purpose I/O Connection Header

UID Unit Identier (UID) Switch

USB0/1 Back Panel Universal Serial Bus (USB) 2.0 Ports

USB2/3, USB4/5 Front Access USB 2.0 Headers

USB6/7 Back Panel USB 3.2 Gen 1 Ports

USB8/9 Front Accessible USB 3.2 Gen 1 Header

USB10 USB 3.2 Gen 1 Type-A Header

VGA VGA Port

LED Description Status

BMC_HB_LED BMC Heartbeat LED Blinking Green: BMC Normal

LED2 Unit Identier (UID) LED Solid Blue: Unit Identied

LED_CATERR CATERR LED Solid Orange: System CATERR

POWER_LED Onboard Power LED Solid Green: Power On

= mounting hole

SAN MACBAR CODE

IPMI CODE MAC CODE

BIOS

LICENSE

DESIGNED IN USA

X12SPO-NTF/-F

REV: 2.0

JIPMB1 JSTBY1 JP1

JCPLD1

JVRM1 JWD1 JP2 JD1

USB2/3 USB4/5

USB8/9 (3.0)

S-SATA0

I-SATA0-3I-SATA4-7

JSD1 JSD2

S-SATA1

JL1

JF1

FANB

JLED1 S-SGPIO1 FANA FAN4 FAN3

JRK1

NVMe8/9

JTPM1

M.2-H_1

M.2H_2

USB10 (3.0)

BT1

COM2

JNCSI1

JPL1

UID

VGA

LAN2 LAN1

USB6/7 (3.0)

IPMI_LAN

USB0/1

COM1

FAN5

JSEN1

NVMe4/5 NVMe2/3 NVMe0/1

JPWR1 JPWR2 JPI2C1

NVMe6/7

DIMMG1

DIMMF1

DIMMH1

DIMME1

DIMMA1

DIMMC1

DIMMD1

DIMMB1

CPU SLOT6 PCIe 4.0 X16

FAN2 FAN1

JPWR3

BMC_HB_LED

POWER_LED

MH5

MH6 MH7

MH1

MH11

MH10

MH12

MH13

JNVI2C1

LED_CATERR

MH8

MH4

MH9

MH3

MH2

LED2

CPU

JPME2

SP1

PCH

621A

JBT1

BMC

AST2600

Jumpers

Power Button

UID LED

NIC1 Active LED

Reset Button

HDD LED

PWR LED

Reset

PWR

UID SW

3.3V Stby

Ground

3.3V Stby

1 2

Ground

Power Fail LED

NIC2 Active LED

NMI

3.3V

OH/Fan Fail LED

3.3V Stby

The X12SPO-NTF/-F Supports up to 2048GB of ECC RDIMM/LRDIMM/LRDIMM

(3DS) with speeds of up to 3200MHz in eight slots. See below for additional

memory information.

• It's recommended to use DDR4 memory of the same type, size and speed.

Mixed DIMM speeds can be installed. However, all DIMMs will run at the

speed of the slowest DIMM.

• The motherboard will not support odd-numbered modules except for a single

DIMM module necessary for board operation. For more information, refer to

https://www.supermicro.com/support/resources/memory/X12_memory_con-

g_guide.pdf.

• To achieve the best memory performance, a balanced memory population is

recommended.

• Memory capacity and frequency is CPU dependent.

Front Control Panel (JF1)

CPU and PHM Installation

Assemble the processor carrier assembly by

inserting the CPU into the processor carrier.

To form the processor heatsink module (PHM),

mount the processor carrier assembly onto the

heatsink and snap into place.

After assembling the PHM, mount it onto the

CPU socket of the motherboard. Use a T-30

Torx-bit screwdriver to gradually install four

screws into the mounting holes from #1-4.

Pin 1

Allow carrier to

latch onto C PU

Allow carrier to

latch onto C PU

Allow carrier to

latch onto C PU

Allow carrier to

latch onto C PU

Mounting the Processor

Heatsink Module onto

the CPU socket (on the

motherboard)

Use a torque

of 12 lbf-in

T30 Torx Screwdriver

T e screws in ighten th

the sequence of 1, 2, 3, 4

#3 #4

Prin ted T riang le

1 9876

LED Indicators

# # # #Description Description Description Description

1 4 7COM1 USB1 LAN1 10 UID Switch/BMC Reset

2 5 8IPMI LAN USB6 (3.2 Gen 1) LAN2

3 6 9USB0 USB7 (3.2 Gen 1) VGA

1 CPU, 8-DIMM Slots

Number of DIMMs Memory Population Sequence

1 DIMMA1

2 DIMMA1 / DIMME1

4 DIMMA1 / DIMME1 / DIMMC1 / DIMMG1

6 DIMMA1 / DIMME1 / DIMMC1 / DIMMG1 / DIMMB1 / DIMMF1

8DIMMA1 / DIMME1 / DIMMC1 / DIMMG1 / DIMMB1 / DIMMF1 /

DIMMD1 / DIMMH1
