SUPERMICR R

ContaCt nformatIon I

• Manuals: http://www.supermicro.com/support/manuals

• Drivers & Utilities: https://www.supermicro.com/wdl/driver/

• Safety: http://www.supermicro.com/about/policies/safety_information.cfm

consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.

P CaCkage ontents

X13seeD-f/-sf

Q r g 1.00uICk eferenCe uIDe

• One Supermicro Motherboard

• One Quick Reference Guide

• Website: www.supermicro.com

• General Information: marketing@supermicro.com

• Technical Support: support@supermicro.com

• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008

f or your system to work ProPerly Please DownloaD aPProPrIate,

DrIvers Images user s manual from the lInks below/ / ' :

MNL-2504-QRG-100

WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproductive harm. For more information, go

to www.P65Warnings.ca.gov.

PRESS FIT

JSPD1

JVRM1

JDBG1

JBR1

JB1

JPME2

JPWR1

MH2MH1

FAN4 FAN3

JMD1

MT1_1

MT1_2

MH7

JTPM1

JP2

JIPMB1

JP13

JPFR2

JPT1

JBM1

JP1

JPFR3

JPFR1

JCP1

JL1

MH10

MH11

JKVM1

LED3-1 LED3

JUIDB2

LED2

LED1

MH12

LED7 LED6

JLAN1

SW2

MH9

JSXB1A

MH8

JSXB1B

JSXB2

JSXB1C

MH6 MH5

BT1

JMD2

FAN1

FAN2

MH4MH3

CPU

DIMMA1

DIMMB1

DIMMC1

DIMMD1

DIMMH1

DIMMG1

DIMMF1

DIMME1

JPL1

2280

22110

MT2_1

MT2_2

2280

22110

BIOS

LICENSE

BAR CODE

LED4

X13SEED-F

REV:1.01

DESIGNED IN USA

PCH

BMC

JNCSI1

JBT1

JRK1

DIMM Memory Installation

CPU Installation

Jumpers, LED Indicators and ConnectorsMotherboard Layout and Features

Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this

guide.

Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors,

and LED indicators.

Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/

motherboard installation instructions.

Memory and CPU Support

The X13SEED-F/-SF motherboard supports up to 2TB of ECC DDR5

RDIMM/3DSRDIMM with speeds of up to 4800 MT/s.

Insert the desired number of DIMMs into memory slots based on the recom-

mended memory population sequence below. For the system to function properly,

use memory modules of the same type and speed.

The X13SEED-F/-SF motherboard supports a 4th Generation Intel® Xeon Scal-

able® Processor with up 350W TDP in an LGA4677 socket.

Connector Description

BT1 Onboard Battery

FAN1–FAN4 CPU/System Fan Headers (FAN1: CPU Fan)

JIPMB1 4-Pin External I²C Header for an IPMI Card

JKVM1 KVM Connector (supports USB0/1, COM1, VGA)

JLAN1 RJ45 GbE (X13SEED-F)

1G SFP (X13SEED-SF)

JMD1 M.2 M-Key PCIe 5.0 Slot (2280/22110)

JMD2 M.2 M-Key PCIe 5.0 Slot (2280/22110)

JNCSI1 NC-SI Interface for IPMI Shared LAN Function

JRK1 Intel RAID Key Header

JSXB1A/B/C PCIe 5.0 p1-x32 Right Riser Slot with FH/HL PCIe card support

JSXB2 PCIe 5.0 p1-x16 Left Riser Slot with LP PCIe card support

JTPM1 Trusted Platform Module (TPM)/Port 80

JPWR1 Power Connector (for backplane power connector)

SW2 Power Button

Jumper Description Default

JBT1 CMOS Clear Open (Normal)

JBM1 IPMI Shared LAN Enable/Disable Pins 1-2 (Enabled)

JPL1 LAN1 Enable/Disable Pins 1-2 (Enabled)

JPT1 Onboard TPM 2.0 Enable/Disable Pins 1-2 (Enabled)

LED Description Status

LED1 Onboard Power LED Solid Green: Power On

LED2 Power/Fan Fail LED Solid Red: Power/Fan Failed

LED3 BMC Heartbeat LED Blinking Green: BMC Normal

LED4 Unit Identier LED Solid Blue: Unit Identied

LED6 RJ45 Port Activity

(X13SEED-F) Yellow: Port Activity

LED7 RJ45 Link

(X13SEED-F)

Solid Green: 100 Mb/s

Solid Amber: 1 Gb/s

LED8 SFP LED

(X13SEED-SF)

Yellow (Top): 1 Gb/s Link

Yellow (Bottom): Activity

Rear Panel I/O Connectors (X13SEED-F) Rear Panel I/O Connectors (X13SEED-SF)

LED Indicators

Jumpers

Connectors

# #Description Description

1. 4.UID Switch Power Button

2. KVM Port

3. LAN1 (RJ45)

# #Description Description

1. 4. LED8UID Switch

2. 5.KVM Port Power Button

3. LAN1 (SFP)

Assemble the processor carrier assembly by inserting the CPU into

the processor carrier.

To form the processor heatsink module (PHM), mount the

processor carrier assembly onto the heatsink and snap into place.

After assembling the PHM, mount it onto the CPU socket of the

motherboard. Use a T-30 Torx-bit screwdriver to gradually install

four screws into the mounting holes from #1-4.

T30 Torx Screwdriver

Use a torque

of 12 lbf-in

Printed Triangle

Pin 1

Press the rotating wires outwards to latch

the PHM and then tighten e four screws.th

Airflow direction

Mount the Processor Heatsink Module

onto the CPU socket (on the motherboard).

1 14 4 53 32 2

= mounting hole

Number of DIMMs Memory Population Sequence

1DIMMA1

DIMME1

2DIMMA1 / DIMMG1

DIMME1 / DIMMC1

4 DIMMA1 / DIMMC1 / DIMME1 / DIMMG1

DIMMA1 / DIMMC1 / DIMMD1 / DIMME1 / DIMMF1 / DIMMG1

DIMMA1 / DIMMB1 / DIMMC1 / DIMME1 / DIMMG1 / DIMMH1

DIMMB1 / DIMMC1 / DIMMD1 / DIMME1 / DIMMF1 / DIMMH1

DIMMA1 / DIMMB1 / DIMMD1 / DIMMF1 / DIMMG1 / DIMMH1

8 DIMMA1 / DIMMB1 / DIMMC1 / DIMMD1 / DIMME1 / DIMMF1 / DIMMG1 / DIMMH1
