74ACT11032

QUADRUPLE 2-INPUT POSITIVE-OR GATES

SCAS008C – JULY 1987 – REVISED APRIL 1996

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Inputs Are TTL-Voltage Compatible

Center-Pin VCC and GND Congurations to

Minimize High-Speed Switching Noise

EPIC

(Enhanced-Performance Implanted

CMOS) 1- m Process

500-mA Typical Latch-Up Immunity at 125°C

Package Options Include Plastic

Small-Outline Packages (D), Plastic Shrink

Small-Outline Packages (DB), Plastic Thin

Shrink Small-Outline Packages (PW), and

Standard Plastic 300-mil DIPs (N)

description

This device contains four independent 2-input OR gates. It performs the Boolean function Y = A + B or

Y A B• in positive logic.

The 74ACT11032 is characterized for operation from –40°C to 85°C.

FUNCTION TABLE

(each gate)

INPUTS OUTPUT

A B Y

H X H

X H H

L L L

logic symbol†

†This symbol is in accordance with ANSI/IEEE Std 91-1984

and IEC Publication 617-12.

1≥

logic diagram (positive logic)

GND

VCC

D, DB, N, OR PW PACKAGE

(TOP VIEW)

PRODUCTION DATA information is current as of publication date.

Products conform to specications per the terms of Texas Instruments

standard warranty. Production processing does not necessarily include

testing of all parameters.

EPIC is a trademark of Texas Instruments Incorporated.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

74ACT11032

QUADRUPLE 2-INPUT POSITIVE-OR GATES

SCAS008C – JULY 1987 – REVISED APRIL 1996

2POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

absolute maximum ratings over operating free-air temperature range (unless otherwise noted) †

Supply voltage range, VCC –0.5 V to 6V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Input voltage range, VI (see Note 1) –0.5 V to VCC + 0.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Output voltage range, VO (see Note 1) –0.5 V to VCC + 0.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Input clamp current, IIK (VI < 0 or VI > VCC) ±20 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Output clamp current, IOK (VO < 0 or VO > VCC) ±50 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Continuous output current, IO (VO = 0 to VCC) ±50 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Continuous current through VCC or GND ±100 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Maximum power dissipation at TA = 55°C (in still air) (see Note 2): D package 1.3 W. . . . . . . . . . . . . . . . . . . .

DB package 0.55 W. . . . . . . . . . . . . . . . . .

N package 1.1 W. . . . . . . . . . . . . . . . . . . .

PW package 0.5 W. . . . . . . . . . . . . . . . . . .

Storage temperature range, Tstg – 65° °C to 150 C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

†Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only and

functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not

implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.

NOTES: 1. The input and output voltage ratings may be exceeded if the input and output current ratings are observed.

2. The maximum package power dissipation is calculated using a junction temperature of 150C and a board trace length of 750 mils,

except for the N package, which has a trace length of zero.

recommended operating conditions

MIN MAX UNIT

VCC Supply voltage 4.5 5.5 V

VIH High-level input voltage 2 V

VIL Low-level input voltage 0.8 V

VIInput voltage 0 VCC V

VOOutput voltage 0 VCC V

IOH High-level output current – 24 mA

IOL Low-level output current 24 mA

t / v 0 10 ns/ VInput transition rise or fall rate

TAOperating free-air temperature –40 85 °C

Produkt Specifikationer

Mærke:	Texas Instruments
Kategori:	Ikke kategoriseret
Model:	74ACT11032N
Type:	Logisk kredsløb
Bredde:	19.69 mm
Dybde:	6.6 mm
Højde:	4.57 mm
Antal pr. pakke:	25 stk
Pakkedybde:	506 mm
Pakkebredde:	13.97 mm
Pakkehøjde:	11.23 mm
Opbevaringstemperatur (T-T):	-65 - 150 °C
Driftstemperatur (T-T):	-40 - 85 °C
Pakketype:	PDIP
Antal stifter:	16
Bredde (med stifter):	19.69 mm
Højde (med stifter):	8.26 mm
Dybde (med stifter):	10.92 mm
