LM8261
SNOS469J APRIL 2000 REVISED JANUARY 2015
LM8261 Single RRIO High Output Current & Unl imited Cap Load Op Amp
1 Features 3 Description
The LM8261 is a Rail-to-Rail input and output Op
1 (VS = 5 V, TA = 25°C, Typical Values Unless Amp which can operate with a wide supply voltage
Specied) range. This device has high output current drive,
GBWP 21 MHz greater than Rail-to-Rail input common mode voltage
Wide Supply Voltage Range 2.5 V to 30 V range, unlimited capacitive load drive capability, and
provides tested and guaranteed high speed and slew
Slew Rate 12 V/µs rate while requiring only 0.97 mA supply current. It is
Supply Current 0.97 mA specically designed to handle the requirements of
Cap Load Limit Unlimited at panel TFT panel VCOM driver applications as well
as being suitable for other low power, and medium
Output Short Circuit Current 53 mA/ 75 mA
speed applications which require ease of use and
±5% Settling Time 400 ns (500 pF, 100 mVPP enhanced performance over existing devices.
Step)
Greater than Rail-to-Rail input common mode v oltage
Input Common Mode Voltage 0.3 V Beyond Rails range with 50 dB of Common Mode Rejection allows
Input Voltage Noise 15nV/ Hz high side and low side sensing, among many
Input Current Noise 1pA/ Hz applications, without concern over exceeding the
range and with no compromise in accuracy.
THD+N < 0.05% Exceptionally wide operating supply voltage range of
2.5 V to 30 V alleviates any concerns over
2 Applications functionality under extreme conditions and oers
TFT-LCD Flat Panel VCOM Driver exibility for use in multitude of applications. In
addition, most device parameters are insensitiv e to
A/D Converter Buer
power supply variations; this design enhancement is
High Side/low Side Sensing yet another step in simplifying its usage. The output
Headphone Amplier stage has low distortion (0.05% THD+N) and can
supply a respectable amount of current (15 mA) with
minimal headroom from either rail (300 mV).
The LM8261 is oered in the space-saving SOT-23-5
package.
Device Information(1)
PART NUMBER PACKAGE BODY SIZE (NOM)
LM8261 SOT-23 (5) 2.9 mm × 1.6 mm
(1) For all available packages, see the orderab le addendum at
the end of the data sheet.
Output Response with Heavy Capacitive Load
1
An IMPORTANT NOTICE at t he end of this d ata sheet addr esses availability, warran ty, changes, use in safety-critic al applications,
inte llectual property matters and other importa nt disclaimers. PRODUCTION DATA.
LM8261
SNOS469J APRIL 2000 REVISED JANUARY 2015
www.ti.com
Table of Contents
7.2 Driving Capac i tiv e Loa ds ........................................ 20
1 Features .................................................................. 1
7.3 Estimating the Output Voltage Swing .............. ...... . 22
2 Applications ........................................................... 1
7.4 TFT Application s ..................................................... 23
3 Description ............................................................. 1
7.5 Output Short Circuit Curr ent and Dissipation
4 Revision History..................................................... 2 Issues....................................................................... 23
5 Pin Conguration and Functions ......................... 3 7.6 Other Application Hints ........................................... 24
6 Specications......................................................... 4 8 Power Supply Recommendations ...................... 25
6.1 Abs ol ute Maximum Ratings ...................................... 4 9 Layout ................................................................... 25
6.2 ESD Ratings.............................................................. 4 9.1 Layout Guidelin es ................................................... 25
6.3 Recommended Operating Conditions............... ........ 4 9.2 Layout Example ...................................................... 26
6.4 The rmal Information.................................................. 4 10 Device and Documentation Support ................. 27
6.5 Elec tric al Charac teris tic s 2.7 V ................................. 5 10.1 Documentation Support ........................................ 27
6.6 Elec tric al Charac teris tic s 5 V .................................... 7 10.2 Trad emarks ........................................................... 27
6.7 Electrical Chara cteristi cs ±15 V ............................ .... 9 10.3 Electrostatic Discharge Caution.............. ...... ........ 27
6.8 Ty pi c al Characte ris tic s ............................................ 11 10.4 Glossary ................................................................ 27
7 Application and Implementation ........................ 19 11 Mec hanica l, Packaging, and Orde r able
7.1 Block Diagram and Operational Description . ...... .... 19 Information ........................................................... 27
4 Revision History
Changes from Revision I (March 2013) to Revision J Page
Added, updated, or revised the following sections: , ,Pin Conguration and Functions Specications Detailed
Description Applicatio n and Implementation Power Supply Recommendations Layout Device an d, , , ,
Documentation Support Mechanical, Packaging, and Orderable Information, and section ................................................. 1
Changed from -1.0 V to -0.8 V in ...................................................................................................................Specications 4
Changes from Revision H (March 2013) to Revision I Page
Changed layout of National Data Sheet to TI format ............................................................................................................. 1
2Submit Documentation Feedback Copyright © 2000–2015, Texas Instruments Incorporated
Product Folder Links: LM8261


Produkt Specifikationer

Mærke: Texas Instruments
Kategori: Ikke kategoriseret
Model: LM8261M5X/NOPB
Type: Driftsforstærker
Bredde: 1.75 mm
Dybde: 3.05 mm
Højde: 1.1 mm
Antal pr. pakke: 3000 stk
Pakkedybde: 208 mm
Pakkebredde: 191 mm
Pakkehøjde: 35 mm
Opbevaringstemperatur (T-T): -65 - 150 °C
Driftstemperatur (T-T): -40 - 85 °C
Pakketype: SOT-23
klirfaktor (THD): 0.05 %
Antal kanaler: 1 kanaler
Antal stifter: 5
Båndbredde: 21 Mhz
Bredde (med stifter): 3 mm
Højde (med stifter): 1.45 mm
Dybde (med stifter): 3.05 mm
Afvisningsforhold for strømforsyning (PSRR): 104 dB
