Side 1/30

To Seven Other Channels

1DIR

1A1

1B1

1OE

To Seven Other Channels

2DIR

2A1

2B1

2OE

Product

Folder

Sample &

Buy

Technical

Documents

Tools &

Software

Support &

Community

SN74AVC16T245

SCES551E – FEBRUARY 2004 – REVISED NOVEMBER 2015

SN74AVC16T245 16-Bit Dual-Su pply Bus Transceiver

with Congurab le Level-Shifting / Voltage Translation and Tri-State Outputs

1 Features 3 Description

This 16-bit noninverting bus transceiver uses two

1 • Control Inputs VIH/VIL Levels Are Referenced to separate congurable power-supply rails. The

VCCA Voltage SN74AVC16T245 device is optimized to operate with

• VCC Isolation Feature – If Either VCC Input Is at VCCA/VCCB set at 1.4 V to 3.6 V. The device is

GND, Both Ports Are in the High-Impedance State operational with VCCA/VCCB as low as 1.2 V. The A

port is designed to track VCCA . VCCA accepts any

• Overvoltage-Tolerant Inputs and Outputs Allow

supply voltage from 1.2 V to 3.6 V. The B port is

Mixed-Voltage-Mode Data Communications designed to track VCCB . VCCB accepts any supply

• Fully Congurable Dual-Rail Design Allows Each voltage from 1.2 V to 3.6 V. This allows for universal

Port to Operate Over the Full 1.2 V to 3.6 V low-voltage bidirectional translation between any of

Power-Supply Range the 1.2-V, 1.5-V, 1.8-V, 2.5-V, and 3.3-V voltage

• Io Supports Partial-Power-Down Mode Operation nodes.

• I/Os Are 4.6 V Tolerant The SN74AVC16T245 device is designed for

• Maximum Data Rates asynchronous communication between data buses.

The device transmits data from the A bus to the B

– 380 Mbps (1.8 V to 3.3 V Level-Shifting) bus or from the B bus to the A bus, depending on the

– 200 Mbps (<1.8 V to 3.3 V Level-Shifting) logic level at the direction-control (DIR) input. The

– 200 Mbps (Level-Shifting to 2.5 V or 1.8 V) output-enable (OE) input can be used to disable the

outputs so the buses eectively are isolated.

– 150 Mbps (Level-Shifting to 1.5 V)

– 100 Mbps (Level-Shifting to 1.2 V) The SN74AVC16T245 control pins (1DIR, 2DIR,

1OE, and 2OE) are supplied by VCCA.

• Latch-Up Performance Exceeds 100 mA Per

JESD 78, Class II Device Information(1)

• ESD Protection Exceeds JESD 22 PART NUMBER PACKAGE BODY SIZE (NOM)

– 8000-V Human-Body Model (A114-A) TSSOP (48) 12.50 mm × 6.1 0 mm

– 200-V Machine Model (A115-A) TVSOP (48) 9.70 mm × 4.40 mm

SN74AVC16T245

– 1000-V Charged-Device Model (C101) BGA MICROSTAR 7.00 mm × 4.50 mm

JUNIOR (56)

2 Applications (1) For all availab le packages, see the orderable add endum at

the end of the data sh eet.

• Personal Electronics

• Industrial

• Enterprise

• Telecom

Logic Diagram (Positive Logic)

An IMPORTANT NOTICE at the end of this data sheet addre sse s av aila bility, warranty, changes, use in safety-critical applications,

inte llectual property matters and other important disclai mers. PRODUCTION DATA.

SN74AVC16T245

SCES551E –FEBRUARY 2004 –REVISED NOVEMBER 2015

www.ti.com

Table of Contents

1 Features 9 Detailed Description.................................................................. 1............................................ 13

9.1 Overview ................................................................. 13

2 Applications ........................................................... 1

9.2 Functiona l Bloc k Diagram ....................................... 13

3 Description ............................................................. 1

9.3 Feature Desc ripti on................................................. 13

4 Revision History..................................................... 2

9.4 Device Functi on al Modes........................................ 14

5 Description (continued)......................................... 3 10 Application and Implementation........................ 15

6 Pin Conguration and Functions ......................... 4 10.1 App lic a tio n Information.......................................... 15

7 Specications......................................................... 5 10 .2 Ty p ic a l Appli c atio n ............................................... 16

7.1 Abs ol ute Maximum Ratings ...................................... 5 11 Power Supply Recommendations ..................... 18

7.2 ESD Ratings ............................................................ 5 12 Layout................................................................... 18

7.3 Recommended Operating Conditions.......... ...... ...... . 6

12.1 Layout Guideline s ................................................. 18

7.4 Thermal Information .................................................. 6

12.2 L ay ou t Example .................................................... 19

7.5 Electric a l Characteris tics........................................... 7

13 Device and Documentation Support ................. 20

7.6 Switching Characteristics: V

CCA = 1.2 V ................... 8

13.1 Documentation Support ........................................ 20

7.7 Switching Characteristics: V

CCA = 1.5 V ± 0.1 V....... 8

13.2 Community Resources.......................................... 20

7.8 Switching Characteristics: V

CCA = 1.8 V ± 0.15 V .... 8

13.3 Trademarks ........................................................... 20

7.9 Switching Characteristics: V

CCA = 2.5 V ± 0.2 V....... 9

13.4 Electrostatic Di sch arge Caution .. ...... ...... ............ .. 20

7.10 Switching Characteristics : V

CCA = 3.3 V ± 0.3 V..... 9

13.5 Glossary ................................................................ 20

7.11 Operating Characteris ti c s ........................................ 9

14 Mechanical, Packa ging, and Orderable

7.12 Typical Characteristic s .......................................... 10

Information ........................................................... 20

8 Parameter Measurement Information ................ 12

4 Revision History

NOTE: Page numbers fo r previous revision s may dier from page numbers in t he curren t version.

Changes from Revision D (February 2015) to Revision E Page

• Updated Pin Functions Table. ............................................................................................................................................... 4

Changes from Revision C (August 2005) to Revision D Page

• Added table, section, ,ESD Ratings Feature Description Device Functional Modes Application and Implementation

section, section, section, section, andPower Supply Recommendations Layout Device and Documentation Support

Mechanical, Packaging, and Orderable Information section ................................................................................................. 1

Product Fold er Links: SN74AVC16T245

Produkt Specifikationer

Mærke:	Texas Instruments
Kategori:	Ikke kategoriseret
Model:	SN74AVC16T245DGVR
Type:	Logisk kredsløb
Antal pr. pakke:	2000 stk
Pakkedybde:	853 mm
Pakkebredde:	449 mm
Pakkehøjde:	35 mm
Opbevaringstemperatur (T-T):	-65 - 150 °C
Driftstemperatur (T-T):	-40 - 85 °C
Pakketype:	TVSOP
Antal stifter:	48
