Side 1/32

DIR 5

A1 2

VCCA VCCB

A2 3

VCCA VCCB

GND4

VCCA VCCB

Product

Folder

Order

Now

Technical

Documents

Tools &

Software

Support &

Community

Reference

Design

An IMPORTANT NOTICE at the end o f this data sheet addresses avail ability, warr anty, changes, use in safet y-critic al applications,

inte llectual property matters and other important disclaimers. P RODUCTI ON DATA.

SN74AVC2T45

SCES531L –DECEMBER 2003 – REVISED MAY 2017

SN74AVC2T45 2-Bit, Dual Sup ply, Bus Transceiver

With Congurable Level-S hifting and T ran slation

1 Features

1 • Available in the Texas Instruments NanoFree™

Package

• VCC Isolation Feature: If Either VCC Input Is at

GND, Both Ports Are in the High-Impedance State

• Dual Supply Rail Design

• I/Os Are 4.6-V Over Voltage Tolerant

• Io Supports Partial-Power-Down Mode Operation

• Max Data Rates

– 500 Mbps (1.8 V to 3.3 V)

– 320 Mbps (<1.8 V to 3.3 V )

– 320 Mbps (Level-Shifting to 2.5 V or 1.8 V)

– 280 Mbps (Level-Shifting to 1.5 V)

– 240 Mbps (Level-Shifting to 1.2 V)

• Latch-Up Performance Exceeds 100 mA Per

JESD 78, Class II

• ESD Protection Exceeds JESD 22

2 Applications

• Smartphones

• Servers

• Desktop PCs and Notebooks

• Other Portable Devices

3 Description

This 2-bit non-inverting bus transceiver uses two

separate congurable power-supply rails. The A ports

are designed to t rack VCCA and accepts any supply

voltage from 1.2 V to 3.6 V. The B ports are designed

to track VCCB and accepts any supply voltage from

1.2 V to 3.6 V. This allows for universal low-voltage

bidirectional translation and level-shifting between

any of the 1.2-V, 1.5-V, 1.8-V, 2.5-V, and 3.3-V

voltage nodes.

The SN74AVC2T45 is designed for asynchronous

communication between two data buses. The logic

levels of the direction-control (DIR pin) i nput activate

either the B-port outputs or the A-port outputs. The

device transmits data f rom the A bus to the B bus

when the B-port outputs are acti vated and from the B

bus to the A bus when the A-port outputs are

activated. The input circuitry on both A and B ports

always is activ e and must have a logic HIGH or LOW

level applied to prevent excess leakage current on

the internal CMOS str ucture.

Device Information(1)

PART NUMBER PACKAGE BODY SIZE (NOM)

SN74AVC2T45DCT SM8 (8) 2.95 mm × 2.80 mm

SN74AVC2T45DCU VSSOP (8) 2.30 mm × 2.00 mm

SN74AVC2T45YZP DSBGA ( 8) 1.89 mm × 0.89 mm

(1) For all avail able packages, see th e orderabl e adde ndum at

the end of the data shee t.

Logic Diagram (Positive Logic)

(1) Pin numbers are f or the DCT and DCU package s only.

SN74AVC2T45

SCES531L –DECEMBER 2003 –REVISED MAY 2017

www.ti.com

Product Folder Li nks: SN74AVC2T45

Table of Contents

1 Features .................................................................. 1

2 Applications ........................................................... 1

3 Description ............................................................. 1

4 Revision History..................................................... 2

5 Pin Conguration and Functions ......................... 3

6 Specications......................................................... 4

6.1 Absolute Maximum Ratin gs ..................................... 4

6.2 ESD Ratings.............................................................. 4

6.3 Recommended Operating Conditions .......... ...... ....... 5

6 .4 The rmal Information.................................................. 6

6.5 Electrical Characteristi c s........................................... 6

6.6 Switching Characteristics: V

CCA = 1.2 V ................... 7

6.7 Switching Characteristics: V

CCA = 1.5 V ±0.1 V........ 7

6.8 Switching Characteristics: V

CCA = 1. 8 V ±0.15 V...... 8

6.9 Switching Characteristics: V

CCA = 2.5 V ±0.2 V........ 8

6.10 Switching Characteristics: V

CCA = 3.3 V ±0.3 V...... 9

6.11 Operating Characteristics........................................ 9

6.12 Typical Characte risti c s .......................................... 10

7 Parameter Measurement Information ................ 12

8 Detailed Description ............................................ 13

8.1 Overview ................................................................. 13

8.2 Func tio nal Bloc k Diag ram ....................................... 13

8.3 Feature Description................................................. 14

8.4 Device Functional Modes........................................ 14

9 Application and Implementation ........................ 15

9.1 Applicatio n Information............................................ 15

9.2 Typical Applic a tio ns ................................................ 15

10 Power Supply Recommendations ..................... 18

11 Layout................................................................... 18

11.1 Layo ut Guidelin es ................................................. 18

11.2 Layout Example .................................................... 18

12 Device and Documentation Support ................. 19

12.1 Docu mentation Support ........................................ 19

12.2 Recei ving Notication of Documentation Updates 19

12.3 Community Resources.......................................... 19

12.4 Trademarks ........................................................... 19

12.5 El ectrosta tic Discharge Caution .... ...... ................. . 19

12.6 Glossary ................................................................ 19

13 Mechanical, Packaging, and Or derable

Information ........................................................... 19

4 Revision History

NOTE: Page numbers for previous revisions may dier from page numbers in the current version .

Changes from Revi sion K (April 2015) to Revision L Page

• Changed data sheet title......................................................................................................................................................... 1

• Changed YZP package pinout diagram to bottom view ......................................................................................................... 3

• Added Type column to table ...........................................................................................................................Pin Functions 3

• Add ed Junction temperature, TJ ............................................................................................................................................. 4

• Added and ......................................................Receiving Notication of Documentation Updates Community Resources 19

Changes from Revision J (June 2007) to Revi sion K Page

• Added section, table, section,Pin Conguration and Functions ESD Ratings Feature Description Device Functional

Modes Application and Implementation Power Supply Recommendations Layout Device, section, section, section,

and Documentation Support Mechanical, Packaging, and Orderable Informationsection, and section .............................. 1

Produkt Specifikationer

Mærke:	Texas Instruments
Kategori:	Ikke kategoriseret
Model:	SN74AVC2T45DCTT
Type:	Logisk kredsløb
Bredde:	3.15 mm
Dybde:	2.9 mm
Højde:	1.2 mm
Antal pr. pakke:	250 stk
Pakkedybde:	182 mm
Pakkebredde:	182 mm
Pakkehøjde:	20 mm
Opbevaringstemperatur (T-T):	-65 - 150 °C
Driftstemperatur (T-T):	-40 - 85 °C
Pakketype:	SOP
Antal stifter:	8
Bredde (med stifter):	3.15 mm
Højde (med stifter):	1.3 mm
Dybde (med stifter):	4.25 mm
