SNx4HC259 8-Bit Addressable Latches
1 Features
Wide operating voltage range of 2 V to 6 V
High-current inverting outputs drive up to 10
LSTTL loads
Low power consumption, 80-μA max ICC
Typical tpd = 14 ns
±4-mA output drive at 5 V
Low input current of 1 μA max
8-bit parallel-out storage register performs serial-
to-parallel conversion with storage
Asynchronous parallel clear
Active-high decoder
Enable input simplifies expansion
Expandable for n-bit applications
Four distinct functional modes
2 Description
These 8-bit addressable latches are designed
for general-purpose storage applications in digital
systems. Specific uses include working registers,
serial-holding registers, and active-high decoders
or demultiplexers. They are multifunctional devices
capable of storing single-line data in eight
addressable latches and being a 1-of-8 decoder or
demultiplexer with active-high outputs.
Device Information
PART NUMBER PACKAGE(1) BODY SIZE (NOM)
SN74HC259D SOIC (16) 9.90 mm × 3.90 mm
SN74HC259N PDIP (16) 19.31 mm × 6.35 mm
SN74HC259NS SO (16) 6.20 mm × 5.30 mm
SN74HC259PW TSSOP (16) 5.00 mm × 4.40 mm
SN54HC259J CDIP (16) 24.38 mm × 6.92 mm
SNJ54HC259FK LCCC (20) 8.89 mm × 8.45 mm
(1) For all available packages, see the orderable addendum at
the end of the document.
Pin numbers are for the D, J, N, NS, PW, and W packages.
Functional Block Diagram
SN54HC259, SN74HC259
SCLS134F – DECEMBER 1982 – REVISED MARCH 2022
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
Table of Contents
1 Features............................................................................1
2 Description.......................................................................1
3 Revision History.............................................................. 2
4 Pin Configuration and Functions...................................3
5 Specifications.................................................................. 4
5.1 Absolute Maximum Ratings........................................ 4
5.2 Recommended Operating Conditions(1) .................... 4
5.3 Thermal Information....................................................4
5.4 Electrical Characteristics.............................................5
5.5 Timing Requirements .................................................5
5.6 Switching Characteristics ...........................................6
5.7 Operating Characteristics........................................... 6
6 Parameter Measurement Information............................7
7 Detailed Description........................................................8
7.1 Overview.....................................................................8
7.2 Functional Block Diagram...........................................8
7.3 Device Functional Modes............................................9
8 Power Supply Recommendations................................10
9 Layout.............................................................................10
9.1 Layout Guidelines..................................................... 10
10 Device and Documentation Support..........................11
10.1 Receiving Notification of Documentation Updates.. 11
10.2 Support Resources................................................. 11
10.3 Trademarks............................................................. 11
10.4 Electrostatic Discharge Caution.............................. 11
10.5 Glossary.................................................................. 11
11 Mechanical, Packaging, and Orderable
Information.................................................................... 11
3 Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
Changes from Revision E (September 2003) to Revision F (March 2022) Page
Updated the numbering, formatting, tables, figures, and cross-references thorughout the document to reflect
modern data sheet standards............................................................................................................................. 1
SN54HC259, SN74HC259
SCLS134F – DECEMBER 1982 – REVISED MARCH 2022 www.ti.com
2Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated
Product Folder Links: SN54HC259 SN74HC259


Produkt Specifikationer

Mærke: Texas Instruments
Kategori: Ikke kategoriseret
Model: SN74HC259N
Type: Logisk kredsløb
Bredde: 19.69 mm
Dybde: 6.6 mm
Højde: 5.57 mm
Antal pr. pakke: 25 stk
Pakkedybde: 506 mm
Pakkebredde: 13.97 mm
Pakkehøjde: 11.23 mm
Opbevaringstemperatur (T-T): -65 - 150 °C
Driftstemperatur (T-T): -40 - 85 °C
Pakketype: PDIP
Antal stifter: 16
Bredde (med stifter): 19.69 mm
Højde (med stifter): 8.26 mm
Dybde (med stifter): 10.92 mm
