SNx4HC595 8-Bit Shift Registers With 3-State Output Registers

1 Features

• 8-bit serial-in, parallel-out shift

• Wide operating voltage range of 2 V to 6 V

• High-current 3-state outputs can drive up to 15

LSTTL loads

• Low power consumption: 80-μA (maximum) ICC

• tpd = 13 ns (typical)

• ±6-mA output drive at 5 V

• Low input current: 1 μA (maximum)

• Shift register has direct clear

• On products compliant to MIL-PRF-38535,

all parameters are tested unless otherwise noted.

On all other products, production processing does

not necessarily include testing of all parameters.

2 Applications

• Network switches

• Power infrastructure

• LED displays

• Servers

3 Description

The SNx4HC595 devices contain an 8-bit, serial-in,

parallel-out shift register that feeds an 8-bit D-type

storage register. The storage register has parallel 3-

state outputs. Separate clocks are provided for both

the shift and storage register. The shift register has

a direct overriding clear (SRCLR) input, serial (SER)

input, and serial outputs for cascading. When the

output-enable (OE) input is high, the outputs are in

the high-impedance state.

Device Information

PART NUMBER PACKAGE(1) BODY SIZE (NOM)

SN54HC595FK LCCC (20) 8.89 mm × 8.89 mm

SN54HC595J CDIP (16) 21.34 mm × 6.92 mm

SN74HC595N PDIP (16) 19.31 mm × 6.35 mm

SN74HC595D SOIC (16) 9.90 mm × 3.90 mm

SN74HC595DW SOIC (16) 10.30 mm × 7.50 mm

SN74HC595DB SSOP (16) 6.20 mm × 5.30 mm

SN74HC595PW TSSOP (16) 5.00 mm × 4.40 mm

(1) For all available packages, see the orderable addendum at

the end of the data sheet.

QH′

SRCLR

RCLK

SRCLK

SER

Pin numbers shown are for the D, DB, DW, J, N, NS, PW, and W packages.

Functional Block Diagram

SN54HC595, SN74HC595

SCLS041J – DECEMBER 1982 – REVISED OCTOBER 2021

An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,

intellectual property matters and other important disclaimers. PRODUCTION DATA.

Table of Contents

1 Features............................................................................1

2 Applications..................................................................... 1

3 Description.......................................................................1

4 Revision History.............................................................. 2

5 Pin Configuration and Functions...................................3

6 Specifications.................................................................. 4

6.1 Absolute Maximum Ratings........................................ 4

6.2 ESD Ratings............................................................... 4

6.3 Recommended Operating Conditions.........................4

6.4 Thermal Information....................................................5

6.5 Electrical Characteristics.............................................5

6.6 Timing Requirements..................................................6

6.7 Switching Characteristics............................................8

6.8 Operating Characteristics........................................... 8

6.9 Typical Characteristics................................................9

7 Parameter Measurement Information.......................... 10

8 Detailed Description...................................................... 11

8.1 Overview................................................................... 11

8.2 Functional Block Diagram......................................... 11

8.3 Feature Description...................................................12

8.4 Device Functional Modes..........................................12

9 Application and Implementation.................................. 13

9.1 Application Information............................................. 13

9.2 Typical Application.................................................... 13

10 Power Supply Recommendations..............................15

11 Layout........................................................................... 15

11.1 Layout Guidelines................................................... 15

11.2 Layout Example...................................................... 15

12 Device and Documentation Support..........................16

12.1 Documentation Support.......................................... 16

12.2 Support Resources................................................. 16

12.3 Trademarks............................................................. 16

12.4 Electrostatic Discharge Caution..............................16

12.5 Glossary..................................................................16

13 Mechanical, Packaging, and Orderable

Information.................................................................... 16

4 Revision History

NOTE: Page numbers for previous revisions may differ from page numbers in the current version.

Changes from Revision H (November 2009) to Revision I (August 2015) Page

• Added section, table, section, Applications Device Information Pin Configuration and Functions ESD Ratings

table, table, section, , Thermal Information Feature Description Device Functional Modes Application and

Implementation Power Supply Recommendations Layout Device and section, section, section,

Documentation Support Mechanical, Packaging, and Orderable Information section, and section .................. 1

• Deleted table. ...................................................................................................................Ordering Information 1

• Added Military Disclaimer to list...........................................................................................................Features 1

Changes from Revision I (August 2015) to Revision J (October 2021) Page

• Updated the device information table, ESD ratings table, and the device functional modes table to fit modern

data sheet standards.......................................................................................................................................... 1

SN54HC595, SN74HC595

SCLS041J – DECEMBER 1982 – REVISED OCTOBER 2021 www.ti.com

Product Folder Links: SN54HC595 SN74HC595

Produkt Specifikationer

Mærke:	Texas Instruments
Kategori:	Ikke kategoriseret
Model:	SN74HC595DR
Type:	Logisk kredsløb
Bredde:	10 mm
Dybde:	4 mm
Højde:	1.5 mm
Antal pr. pakke:	2500 stk
Pakkedybde:	364 mm
Pakkebredde:	364 mm
Pakkehøjde:	27 mm
Opbevaringstemperatur (T-T):	-65 - 150 °C
Driftstemperatur (T-T):	-40 - 85 °C
Pakketype:	SOIC
Antal stifter:	16
Bredde (med stifter):	10 mm
Højde (med stifter):	1.75 mm
Dybde (med stifter):	6.2 mm
