Side 1/33

A Y

Product

Folder

Sample &

Buy

Technical

Documents

Tools &

Software

Support &

Community

An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,

intellectual property matters and other important disclaimers. PRODUCTION DATA.

SN74LVC07A

SCAS595W – OCTOBER 1997 – REVISED OCTOBER 2016

SN74LVC07A Hex Buer and Driver With Open-Drain Outputs

1 Features

• Operates From 1.65 V to 5 V

• Inputs and Open-Drain Outputs Accept Voltages

Up to 5.5 V

• Max tpd of 2.6 ns at 5 V

• Latch-Up Performance Exceeds 250 mA

Per JESD 17

• Io Supports Live Insertion, Partial-Power-Down

Mode, and Back-Drive Protection

2 Applications

• AV Receiver

• Audio Dock: Portable

• Blu-ray Player and Home Theater

• MP3 Player or Recorder

• Personal Digital Assistant (PDA)

• Power: Telecom/Server AC/DC Supply: Single

Controller: Analog and Digital

• Solid State Drive (SSD): Client and Enterprise

• TV: LCD, Digital, and High-Denition (HDTV)

• Tablet: Enterprise

• Video Analytics: Server

• Wireless Headset, Keyboard, and Mouse

3 Description

The SN74LVC07A device is a hex buer and driver

that is designed for 1.65-V to 5.5-V V CC operation.

Device Information (1)

PART NUMBER PACKAGE BODY SIZE (NOM)

SN74LVC07AD SOIC (14) 8.65 mm × 3.91 mm

SN74LVC07ADB SSOP (14) 6.20 mm × 5.30 mm

SN74LVC07ADGV TVSOP (14) 3.60 mm × 4.40 mm

SN74LVC07APW TSSOP (14) 5.00 mm × 4.40 mm

SN74LVC07ANS SO (14) 10.30 mm × 5.30 mm

SN74LVC07ARGY VQFN (14) 3.50 mm × 3.50 mm

(1) For all available packages, see the orderable addendum at

the end of the data sheet.

Simplied Schematic

SN74LVC07A

SCAS595W – OCTOBER 1997 – REVISED OCTOBER 2016

www.ti.com

Product Folder Links: SN74LVC07A

Table of Contents

1 Features .................................................................. 1

2 Applications ........................................................... 1

3 Description ............................................................. 1

4 Revision History..................................................... 2

5 Pin Conguration and Functions ......................... 4

6 Specications......................................................... 5

6.1 Absolute Maximum Ratings ..................................... 5

6.2 ESD Ratings.............................................................. 5

6.3 Recommended Operating Conditions ...................... 5

6.4 Thermal Information.................................................. 6

6.5 Electrical Characteristics—DC Limit Changes .......... 6

6.6 Switching Characteristics .......................................... 6

6.7 Operating Characteristics.......................................... 7

6.8 Typical Characteristics.............................................. 7

7 Parameter Measurement Information .................. 8

7.1 VCC = 1.8 V ± 0.15 V................................................. 8

7.2 VCC = 2.5 V ± 0.2 V................................................... 9

7.3 VCC = 2.7 and 3.3 V ± 0.3 V ................................... 10

7.4 VCC = 5 V ± 0.5 V.................................................... 11

8 Detailed Description ............................................ 12

8.1 Overview ................................................................. 12

8.2 Functional Block Diagram ....................................... 12

8.3 Feature Description................................................. 12

8.4 Device Functional Modes........................................ 12

9 Application and Implementation ........................ 13

9.1 Application Information............................................ 13

9.2 Typical Application ................................................. 13

10 Power Supply Recommendations ..................... 14

11 Layout................................................................... 14

11.1 Layout Guidelines ................................................. 14

11.2 Layout Example .................................................... 15

12 Device and Documentation Support ................. 16

12.1 Documentation Support ........................................ 16

12.2 Receiving Notication of Documentation Updates 16

12.3 Community Resources.......................................... 16

12.4 Trademarks ........................................................... 16

12.5 Electrostatic Discharge Caution............................ 16

12.6 Glossary ................................................................ 16

13 Mechanical, Packaging, and Orderable

Information ........................................................... 16

4 Revision History

NOTE: Page numbers for previous revisions may dier from page numbers in the current version.

Changes from Revision V (May 2015) to Revision W Page

• Changed table ................................................................................................................................................Pin Functions 4

• Added Junction temperature to the table ..................................................................................Absolute Maximum Ratings 5

• Reformatted the and the tables ...........................................................Electrical Characteristics Switching Characteristics 6

• Changed ................................................................................................................................Typical Application Diagram 13

• Added section ......................................................................................Receiving Notication of Documentation Updates 16

Changes from Revision U (June 2014) to Revision V Page

• Changed table to table ........................................................................................................Handling Ratings ESD Ratings 5

• Added industry standard terms to package designators in the table ....................................................Thermal Information 6

• Changed from "High" to "High-Z" in the .....................................................................................................Function Table 12

Changes from Revision T (February 2011) to Revision U Page

• Updated document to new TI data sheet format .................................................................................................................... 1

• Removed table .....................................................................................................................................Ordering Information 1

• Added .................................................................................................................................................................Applications 1

• Added Io Features bullet........................................................................................................................................................ 1

• Added table .............................................................................................................................................Device Information 1

• Added table. ...............................................................................................................................................Handling Ratings 5

• Changed MAX operating free-air temperature from 85°C to 125°C....................................................................................... 5

• Updated table. ......................................................................................................................................Thermal Information 6

• Added –40°C TO +125°C temperature range to table...................................................................Electrical Characteristics 6

• Added table for –40°C TO 125°C temperature range...................................................................Switching Characteristics 6

Produkt Specifikationer

Mærke:	Texas Instruments
Kategori:	Ikke kategoriseret
Model:	SN74LVC07ADR
Type:	Logisk kredsløb
Bredde:	8.75 mm
Dybde:	4 mm
Højde:	1.5 mm
Antal pr. pakke:	2500 stk
Pakkedybde:	340.5 mm
Pakkebredde:	336.1 mm
Pakkehøjde:	32 mm
Opbevaringstemperatur (T-T):	-65 - 150 °C
Driftstemperatur (T-T):	-40 - 125 °C
Pakketype:	SOIC
Antal stifter:	14
Bredde (med stifter):	8.75 mm
Højde (med stifter):	1.75 mm
Dybde (med stifter):	6.2 mm
