Side 1/24

GND

VCC

1DE

GND

VCC

2DE

SN65C1167

SN75C1167, SN65C1168, SN75C1168

www.ti.com

SLLS159F – MARCH 1993 – REVISED NOVEMBER 2009

DUAL DIFFERENTIAL DRIVERS AND RECEIVERS

Check for Samples: SN65C1167 SN75C1167 SN65C1168 SN75C1168

FEATURES SN65C1167 . . . DB OR NS PACKAGE

• Meet or Exceed Standards TIA/EIA-422-B and SN75C1167 . . . DB, N, OR NS PACKAGE

(TOP VIEW)

ITU Recommendation V.11

• BiCMOS Process Technology

• Low Supply-Current Requirements: 9 mA Max

• Low Pulse Skew

• Receiver Input Impedance . . . 17 k TypΩ

• Receiver Input Sensitivity . . . ±200 mV

• Receiver Common-Mode Input Voltage Range

of 7 V to 7 V−

• Operate From Single 5-V Power Supply

• Glitch-Free Power-Up/Power-Down Protection

SN65C1168 . . . N, NS, OR PW PACKAGE

• Receiver 3-State Outputs Active-Low Enable SN75C1168 . . . DB, N, NS, OR PW PACKAGE

for SN65C1167 and SN75C1167 Only (TOP VIEW)

• Improved Replacements for the MC34050 and

MC34051

DESCRIPTION

The SN65C1167, SN75C1167, SN65C1168, and SN75C1168 dual drivers and receivers are integrated circuits

designed for balanced transmission lines. The devices meet TIA/EIA-422-B and ITU recommendation V.11.

The SN65C1167 and SN75C1167 combine dual 3-state dierential line drivers and 3-state dierential line

receivers, both of which operate from a single 5-V power supply. The driver and receiver have active-high and

active-low enables, respectively, which can be connected together externally to function as direction control. The

SN65C1168 and SN75C1168 drivers have individual active-high enables.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas

Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

Products conform to specications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.

SN65C1167

SN75C1167, SN65C1168, SN75C1168

SLLS159F – MARCH 1993 – REVISED NOVEMBER 2009

www.ti.com

ORDERING INFORMATION

TAPACKAGE(1) (2) ORDERABLE PART NUMBER TOP-SIDE MARKING

SN75C1167N SN75C1167N

PDIP – N Tube SN75C1168N SN75C1168N

SN75C1167NSR 75C1167

SOP – NS Tape and reel SN75C1168NSR 75C1168

0°C to 70°C SN75C1167DBR CA1167

SSOP – DB Tape and reel SN75C1168DBR CA1168

Tube SN75C1168PW

TSSOP – PW CA1168

Tape and reel SN75C1168PWR

PDIP – N Tube SN65C1168N SN65C1168N

SN65C1167NSR 65C1167

SOP – NS Tape and reel SN65C1168NSR 65C1168

–40°C to 85°C SSOP – DB Tape and reel SN65C1167DBR CB1167

Tube SN65C1168PW

TSSOP – PW CB1168

Tape and reel SN65C1168PWR

(1) Package drawings, thermal data, and symbolization are available at .www.ti.com/sc/packaging

(2) For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI

web site at .www.ti.com

Product Folder Link(s): SN65C1167 SN75C1167 SN65C1168 SN75C1168

Produkt Specifikationer

Mærke:	Texas Instruments
Kategori:	Ikke kategoriseret
Model:	SN75C1168NSR
Type:	Logisk kredsløb
Bredde:	10.4 mm
Dybde:	5.4 mm
Højde:	1.7 mm
Antal pr. pakke:	2000 stk
Pakkedybde:	367 mm
Pakkebredde:	367 mm
Pakkehøjde:	38 mm
Opbevaringstemperatur (T-T):	-65 - 150 °C
Driftstemperatur (T-T):	0 - 70 °C
Pakketype:	SOP
Antal stifter:	16
Bredde (med stifter):	10.4 mm
Højde (med stifter):	2 mm
Dybde (med stifter):	8.2 mm
