Use
The thermostat is used for controlling the temperature inEIB/KNX RAMSES 713 S
individual rooms of functional and private buildings.
Available as a continuous as well
as a two-point controller.
It is also possible to control 2-step heating (basic and addi-
should be used in dry rooms. The controller is suitable forRAMSES 713 Fan Coil
controlling a fan coil unit with a fan coil actuator.
The temperature controller is suitable for dry rooms only.
Installation of thermostat
2.
Safety
To be able to eliminate all fire hazards and the risk of electric
shock, the device must be connected and installed by a qualified
electrician and in accordance with the national regulations and
valid safety requirements. Tampering with or making modifica-
tions to the device will invalidate the guarantee.
Always carry out
installation works voltage-free.
Installation of thermostat
• Gently pull-off the temperature selector.
• Turn the latch with a small screwdriver to position OPEN.
• Carefully place thermostat on the guiding rails and push to the left until mounting
base is covered. Do not tilt thermostat!
• Turm latch with a small screwdriver to position CLOSE.
• Place temperature selector on the unit.
De-installation of thermostat
• Draw off temperature selector.
• Loosen latch to position OPEN.
• Push thermostat to the right ... and left the unit. Do not tilt thermostat!
De-installation of mounting base
• Press-in spring at cover of the mounting base and lift it off.
• Loosen screws and reverse base unit.
• To pull out wire use an appropriate screwdriver to release spring clamp!
7.
Connection of BUS and external interfaces
Functionality of external interfaces,
potential range, contacts
• E1 - E3: switching, dimming, blinds
• E3: external actual value
• Connect the bus cable to the bus line (red + /
black –). (Note the polarity!)
• Selector for desired temperature with “soft click” notches.
• The desired room temperature is adjustable in 1/4 degree steps.
• Temperature scale in °C.
6.
Temperature
5-6mm
CLOSE
OPEN
1.
2.
4
3
2
5
6
°C
CLOSE
OPEN
1.
2.
2
18
16
4
3
2
5
6
°
C
4
3
2
5
6
°
C
CLOSE
OPEN
1.
2.
2
18
16
CLOSE
OPEN
1.
2.
4
3
2
CLOSE
OPEN
1.
2.
4
3
2
CLOSE
OPEN
1.
2.
2
18
16
4
3
2
5
6
°
C
4
3
2
5
6
°C
MONTAGE
3.
2.
1.
o.k.
OPEN
230V24V 230V24V
230V
24V 2 V
24V
20
18
16
24
22
20
18
16
24
22
20
18
16
24
2
20
18
16
24
2
CL
OPE
max.
min.
8.
Entering the physical address
The inputs with the functionality “switching” can also be used as window contact or
presence indicator.
E1 COM
E2 COM
E3 COM
9.
Service
Set physical address
Programming LED
E3
E2
E1
COM
310 899 03
RAMSES 713 S 713 9 201
RAMSES 713 Fan Coil 713 9 202
Theben AG
Hohenbergstr. 32
72401 Haigerloch
DEUTSCHLAND
Fon +49 (0) 74 74/6 92-0
Fax +49 (0) 74 74/6 92-150
Service
Fon +49 (0) 74 74/6 92-369
Fax +49 (0) 74 74/6 92-207
hotline@theben.de
Adresses, telephone numbers etc. at
www.theben.de
e
4.
Installation
3.
Description
push button for operating modes or presence
comfort mode
standby mode
reduction mode (in the night)
frost protection
RAMSES 713 Fan Coil
red/blue: red= heating, blue = cooling
out = demanding temperature is reached
temperature selector
ca.
150cm
min.
50cm
1 2 3 Fan stages
Auto Automatic mode
OFF Fan is switched off
push button for operating modes
RAMSES 713 S
