Intel Installation

LGA 1156/1155/1151/1150

LGA 1366

LGA 1366/1156/1155/1151/1150 LGA 2066/2011

Intel (Socket LGA 1366/1156/1155/1151/1150) Installation

CPU F an Port

K M

Parts List

AMD Installation

Compatibility may vary based on chassis design.

For installation, skip step 1, 2 and continue with step 3LGA2066/2011

LGA 2066/201

LGA 2066/2011/1366

1/1366

1/1366LGA 2066/2011/1366

LGA 1

LGA 1156/1

156/1

156/1155/1151/1

155/1151/1

155/1151/1150

150

150LGA 1156/1155/1151/1150

LGA 1366/1156/1155/1151/1150 LGA 2066/2011

CPU F an Port

240

Floe DX RGB

TT Premium Edition

Patented

16.8 Million Color

Connect the plug into the port in numerical order,

start with plug one.

Set the DIP switch on the back side of the

controller to assign the number of the controller

NO.1

1 2 3 4

NO.3

1 2 3 4

NO.2

1 2 3 4

NO.4

1 2 3 4

NO.9

1 2 3 4

NO.11

1 2 3 4

NO.10

1 2 3 4

NO.12

1 2 3 4

NO.5

1 2 3 4

NO.7

1 2 3 4

NO.6

1 2 3 4

NO.8

1 2 3 4

NO.13

1 2 3 4

NO.15

1 2 3 4

NO.14

1 2 3 4

NO.16

1 2 3 4

Connect the controller cable onto the mainboard

(USB 2.0, 9 pin) and the controller.

Connect the power cable to the 4pin Molex

connecter and the controller.

Q Q

InstallationController

TT RGB Plus Software control interface

Please download software from Thermaltake Official website.

www.thermaltake.com/home.aspx

and search " " on the official website.TT RGB Plus

OS compatibility: Windows 7 / 8 / 8.1 / 10

1. Software User Interface

A. TT RGB Plus software Profile Setting

A-1 Set up a profile: Choose a Profile and set up the LED Lighting Mode,

then click the SAVE icon(A-3) to store your settings to the software.

A-2 Save a profile to controller: Select a profile and a controller,

then click the Save icon to assign the profile to the controller.

B. Follow the Installation Guide step 3, you can set up the number of the controller

C. LED Lighting Mode

C 1 LED Selection: set up the LEDs lighting, color, and speed-.

Light Mode: Choose a lighting mode

Color Mode: Choose the LEDs color

Light Speed: Set up the speed of the LEDs light

LED Spot & Color Palette: Choose the color of each of the individual LEDs by clicking the color palette

Done: Save your setting

Default: Reset the LED setting back to the default

Brightness: Drag the mouse to adjust LED light brightness.

LED On/Off: Click the LED Light icon to turn on or off the LED light

RGB Color Code: Enter the Decimal Code of Red Green and Blue to set the LEDs color, ,

C-2 Performance Mode: 500~1500RPM(Duty cycle0%~100%)

Silent Mode: 500~900RPM(Duty cycle0%~50%)

PWM Mode: The PWM function can be turned off and set the fan speed manually

C-3 LED On/Off: User can switch off the LED control function in the software if the fan is not plug into the controller.

C-4 Product Selection: click the product name to choice another you want.

C-5 Fan LED Ring Selection: Choose different fan ring to setting the lighting modes.

D-1 & D-2. Product Selection: click the control panel to rotate it to the front

Full Lighted / Wave / Pulse / Ripple / Microphone / Sound effect / RGB Spectrum / Flow/etc..

2. Mobile APP Connection Password

To connect the TT RGB Plus APP, please connect the PC to your

wireless first, and click the Password setting under the software

setting menu, set up your connection password. The TT RGB Plus APP

will ask for your password every time when starting the APP.

For more information please visit www.thermaltake.com

A-

-1

1A-1

A-

-2

2A-2

A-

-3

3A-3

D-

-1

1D-1

D-

-2

2D-2

C-

-1

1C-1

C-

-1

1C-1

C-

-2

2C-2

C-

-3

3C-3

C-

-4

4C-4

C-

-4

4C-4

When you open the software, choose the "Floe Riing RGB" in the drop-down list(C-4) first.

正體中文

Eng lish

正體中文

簡體中文

Deu tsch

Fra nçais

日本語

ไทย

Auto Update O n

Pas sword On

Pas sword:8 888

software interface may vary with feature update,

please download the latest user manual from our

www.thermaltake.com

Ri in g Pl us

RL 36 0 Pl us

PR 22 -D 5 Plus

W4 P lu s

VG A Plus

Lu mi P lu s

Pu re P lu s

Fl oe R ii ng RGB

C-

-5

5C-5

1 2 3 4

123

240

Floe DX RGB

TT Premium Edition

Patented

16.8 Million Color

Produkt Specifikationer

Mærke:	Thermaltake
Kategori:	Hardwarekoeling
Model:	Floe DX RGB 240 TT Premium Edition
Type:	Alt-i-en væskekøler
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Certificering:	Tt LCS
Rørmateriale:	Gummi
Pumpemotor hastighed:	3600 rpm
Monteringssæt:	Ja
Belysningsfarve:	Blue, Green, Red
Antal blæsere:	2 blæser(e)
Passende til rumtype:	Processor
Skruer inkluderet:	Ja
Maksimal luftstrøm:	42.45 kubikfod/min.
Ventilatorens støjniveau (min.):	19 dB
Ventilatorens støjniveau (maks.):	23.8 dB
Ventilatorstik:	9-polet
Pumpespænding:	5/12 V
Blæser, spænding:	12 V
Blæser, hastighed (min.):	500 rpm
Blæser, hastighed (maks.):	1500 rpm
Understøttede procesorsokler:	LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1366 (Socket B), LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket FM1, Socket FM2
Understøttelse af puls-bredde modulering (PWM):	Ja
Køler bredde:	270 mm
Køler dybde:	120 mm
Køler højde:	27 mm
Rørlængde:	326 mm
Vandblokerende materiale:	Kobber
Pumpestrøm:	325 mA
Ventilator dimensioner (BxDxH):	120 x 120 x 25 mm
Belysning LED:	Ja
Ventilator statisk tryk:	1.45 mmH2O
CPU-beslag:	Ja
RGB-controller inkluderet:	Ja
