INSTALLATION MANUAL
SPEAKER RIGGING BRACKETS HY-VM7B
HY-VM7W
Thank you for purchasing TOA’s Speaker Rigging Bracket.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
TABLE OF CONTENTS
1. SAFETY PRECAUTIONS ..................................................................................................................... 1
2. GENERAL DESCRIPTION ................................................................................................................... 2
3. MOUNTING THE SPEAKER ON A WALL (using the optional HY-WM7B or HY-WM7W bracket) ........ 2
4. MOUNTING THE SPEAKER TO A CEILING (using the optional HY-C0801 or HY-C0801W bracket) .. 6
5. SUSPENDING THE SPEAKER FROM A CEILING (only the T-bracket is used) ............................. 8
6. DIRECT SPEAKER CEILING MOUNTING (only the T-bracket is used) ........................................ 10
7. SPECIFICATIONS ............................................................................................................................... 12
1. SAFETY PRECAUTIONS
• Beforeinstallationoruse,besuretocarefullyread
all the instructions in this section for correct and
safe operation.
• Besuretofollowalltheprecautionaryinstructions
in this section, which contain important warnings
and/orcautionsregardingsafety.
• After reading, keep this manual handy for future
reference.
• Referallinstallationworktothedealerfromwhom
the speaker was purchased. Installation for ying
requires extensive technical knowledge and
experience. The speaker may fall off if incorrectly
installed,resultinginpossiblepersonalinjury.
• FlyingPrecautions
Be sure to follow the instructions below. Otherwise,
the suspension wires or belts may be off or snap
and the speaker may fall off, causing personal
injury.
· Check to conrm that the suspension wires and
beltsarestrongenoughtowithstandthespeaker
load.
· Theconnectorsofthesuspensionwiresandbelts
mustbesecurelylinkedwiththoseofthespeaker.
· All parts and components (such as enclosures,
metalpieces,andscrews)mustbefreefromany
deformation,crack,andcorrosion.
· Besuretousescrewssuppliedwiththeoptional
yinghardwarewheninstallingthespeakerusing
suchhardware.
• Install the speaker only in a location that can
structurallysupporttheweightofthespeakerand
the mounting bracket. Doing otherwise may result
in the speaker falling down and causing personal
injuryand/orpropertydamage.
• Sincethebracketisdesignedforindooruse,donot
install it outdoors. If installed outdoors, the aging
of parts causes the speaker to fall off, resulting in
personal injury. Also, when it gets wet with rain,
thereisadangerofelectricshock.
• Owing to the speaker’s size and weight, be sure
that at least two persons are available to install the
speaker. Failure to do so could result in personal
injury.
• Donotuseothermethodsthanspeciedtomount
thebracket.Extremeforceisappliedtothebracket
andthespeakercouldfalloff,possiblyresultingin
personalinjuries.
• Attachthesafetywiretothespeaker.Ifnotattached,
itcouldfalloff,resultinginpersonalinjury.
• Use safety wires when installing speakers. If not
used, personal injury could result if a speaker
shouldaccidentallyfall.
• Use nuts and bolts that are appropriate for the
ceiling’sorwall’sstructureandcomposition.Failure
todosomaycausethespeakertofall,resultingin
Indicatesapotentiallyhazardoussituationwhich,
if mishandled, could result in death or serious
personalinjury.
WARNING
