1. SAFETY PRECAUTIONS

• Beforeinstallationoruse,besuretocarefullyreadalltheinstructionsinthissectionforcorrectandsafeoperation.

• Be suretofollow alltheprecautionary instructions inthissection, which contain important warnings and/orcautions

regardingsafety.

• Afterreading,keepthismanualhandyforfuturereference.

• Installtheunitonlyinalocationthatcanstructurallysupporttheweightoftheunitandthemountingbracket.

 Doingotherwisemayresultintheunitfallingdownandcausingpersonalinjuryand/orpropertydamage.

• Neveruseothermethodsthanspeciedtomountthebracket.

 Extremeforceisappliedtotheunitandtheunitcouldfalloff,possiblyresultinginpersonalinjuries.

• Attachthesafetywiretotheunit.Ifnotattached,theunitcouldfalloff,resultinginpersonalinjury.

• Toavoidelectricshocks,besuretoswitchofftheamplier’spowerwhenconnectingspeakers.

• Donotoperatetheunitforanextendedperiodoftimewiththesounddistorting.Thisisanindicationofamalfunction,whichin

turncancauseheattogenerateandresultinare.

• Donothangdownfromtheunitasthismaycauseittofalldownordrop,resultinginpersonalinjuryand/orpropertydamage.

• Avoidtouchingtheunit’ssharpmetaledge,andthecutendsofthehangingandsafetywirestopreventinjury.

• Firmlyholdthespeakerbodywhenusingthereleasekey.

 Failuretodosomaycausethespeakertofall,resultinginpossiblypersonalinjury.

2. GENERAL DESCRIPTION

ThePE-304BU,PE-304WU,PE-604BU,andPE-604WUarependantspeakersdesignedfortheinstallationssuspendedfromaceiling.

Adirectly-attached5m(16.4ft)hangingwireallowsthespeakertobesuspendedfromhighceilings.

These speakers can be driven on both high-impedance (100 V, 70 V and 25 V) and low-impedance (8

Ω) lines. The input power

(impedance)canbeeasilychangedattherearsideofthespeaker.

ThesespeakersarecertiedtoUL1480UUMWandULC-S541standards.Usingthesupplied

hangerswillfacilitatethe

speakermountingheightadjustment.

isaregisteredtrademarkofGrippleLimited,England.

INSTRUCTIONS MANUAL

PENDANT SPEAKERS PE-304BU, PE-304WU

PE-604BU, PE-604WU

Indicates apotentially hazardous situation which, if mishandled, could result in

deathorseriouspersonalinjury.

WARNING

Indicates apotentially hazardous situation which, if mishandled, could result in

moderateorminorpersonalinjury,and/orpropertydamage.

CAUTION

4. INSTALLATION AND CONNECTION

Note

Localcodesmayrequireotherinstallationmethods.Checkwith

authority having jurisdiction to determine acceptability of the

mountingmethodsshownhere.

Step 1. ConrmthatGRIPPLE

No.1(smallone)isinstalledon

asafetywire(thinone)andGRIPLLE

No.2(bigone)on

ahangingwire(thickone).

Step 2. Passthehangingwireovertheceilinganchorpointsuch

asbeamorpurlin,thenpassitthroughtheotherholein

theGRIPPLE

No.2.

Step 3. Adjust the length of the hanging wire for the optimum

speakermountingheight.

Step 4. Installthesafetywirefollowingthesameprocedureas

inSteps2and3.Besuretopassthesafetywireovera

differentceilinganchorpointfromtheonethehanging

wirewaspassedoverinStep2.

GRIPPLE

No. 1 or No. 2

(accessory, preinstalled)

Safety wire or hanging wire

(accessory, preinstalled)

GRIPPLE

No. 2

Followtheinstructionsbelow.

Doing otherwise may cause the speaker fall, resulting in

personalinjury.

• Neverhangthespeakerwiththesafetywire.

• The surplus length of the safety wire must be within

30 cm (11.81") from the state that the safety wire is

tight.

• Install the hanging wire rst, then the safety wire.

(Neverreversethisorder.)

CAUTION

3. INPUT POWER (IMPEDANCE) CHANGE

Turntherotaryswitch(ontherearsideofthespeaker)tosetitto

thedesiredinputimpedanceusingaslottedscrewdriver.

Note: Settherotaryswitchwithoutremovingthehangingbracket.

• Switch off the amplier’s power when changing the

inputpower.

• Neversettherotaryswitchtothe"170Ω"(PE-304BU,

PE-304WU)or"83Ω"(PE-604BU,PE-604WU)position

whenoperatingthespeakeron100Vline.

 Failuretofollowthisinstructioncouldresultindamage

tothespeakeroramplier.

• Never set this switch to the "8 Ω" position when

connectingtotheamplier’shigh-impedancespeaker

line(25V,70Vor100V),asdoingsomaydamagethe

speakeroramplier.

 Besuretosetthisswitchtothe“8Ω”positionwhen

connectingtotheamplier’slow-impedanceline.

CAUTION

Speaker

The label showing Impedance vs. Input power table is affixed

to the hanging bracket.

"100 V," "70 V," and "25 V" indications in the leftmost column

are "100 V line," "70 V line," "25 V line," respectively.

[PE-604BU, PE-604WU]

[PE-304BU, PE-304WU]

• Rotary switch

[PE-604BU, PE-604WU]

The switch is factory-preset

to 330 Ω.

The switch is factory-preset

to 170 Ω.

[Rear view]

Hanging bracket

Label

Rotary switch

Produkt Specifikationer

Mærke:	TOA
Kategori:	Højttaler
Model:	PE-604BU
Bredde:	- mm
Dybde:	- mm
Højde:	275 mm
Vægt:	2900 g
Produktfarve:	Sort
Udgangseffekt (RMS):	60 W
Husmateriale:	Resin, Steel
Anbefalet brug:	Universel
Frekvensområde:	110 - 20000 Hz
Forbindelsesteknologi:	Ledningsført
Lyd-output kanaler:	- kanaler
Højttaler, placering:	Kan monteres i loftet
Diameter:	186 mm
Antal drivere:	1
Driver diameter:	120 mm
Diskanthøjttaler:	Ja
Antal drivere til diskant:	1
Sensitivitet:	90 dB
Basrefleks:	Ja
