TOA SR-S4LWP Manual

TOA Højttaler SR-S4LWP

Læs gratis den danske manual til TOA SR-S4LWP (16 sider) i kategorien Højttaler. Denne vejledning er vurderet som hjælpsom af 3 personer og har en gennemsnitlig bedømmelse på 4.6 stjerner ud af 2 anmeldelser. Har du et spørgsmål om TOA SR-S4LWP, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/16

OPERATING INSTRUCTIONS

LINE ARRAY SPEAKERS

EXTENSION PLATE

(optional)

PROTECTION PAD (optional)

SR-S4LWP

SR-S4SWP

SR-EP4WP

SR-PP4

SR-S4LWP

SR-S4SWP

Thank you for purchasing TOA's Line Array Speakers and their associated products.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS ............................................................................................ 3

2. GENERAL DESCRIPTION .......................................................................................... 5

3. FEATURES ...................................................................................................................... 5

4. INSTALLATION PRECAUTION ................................................................................. 6

5. COVERAGE AREA ....................................................................................................... 7

6. DIMENSIONAL DIAGRAM

6.1. Line Array Speaker SR-S4LWP ................................................................................... 8

6.2. Line Array Speaker SR-S4SWP ................................................................................... 8

7. SINGLE-AMPLIFIER DRIVE AND BI-AMPLIFIER DRIVE ............................... 9

8. INTERNAL WIRING DIAGRAM ................................................................................ 9

9. CHANGING TO HIGH IMPEDANCE ...................................................................... 10

10. JOINING SPEAKERS ................................................................................................. 11

11. ATTACHING THE PROTECTION PAD TO THE SPEAKER EDGE ............. 12

12. CHANGING SINGLE-AMPLIFIER DRIVE

TO BI-AMPLIFIER DRIVE SYSTEM

...................................................................... 13

13. INTERNAL WIRING DIAGRAM

FOR THE BI-AMPLIFIER DRIVE SYSTEM

......................................................... 14

14. DIGITAL PROCESSOR FILTERING

14.1. Single-Amplifier Drive (Factory-Setting) .................................................................... 14

14.2. Bi-Amplifier Drive ...................................................................................................... 14

15. SPECIFICATIONS

15.1. Line Array Speaker SR-S4LWP, SR-S4SWP .......................................................... 15

15.2. Extension Plate SR-EP4WP (optional) .................................................................... 16

15.3. Protection Pad SR-PP4 (optional) ............................................................................ 16

Produkt Specifikationer

Mærke:	TOA
Kategori:	Højttaler
Model:	SR-S4LWP
Bredde:	160 mm
Dybde:	255 mm
Højde:	895 mm
Vægt:	16000 g
Antal pr. pakke:	1 stk
Produktfarve:	Hvid
Bluetooth:	Ingen
Udgangseffekt (RMS):	600 W
Driftstemperatur (T-T):	-10 - 50 °C
Husmateriale:	Plywood, Stainless steel
Anbefalet brug:	Universel
Frekvensområde:	70 - 20000 Hz
Impedens:	8 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Højttaler, type:	2-vejs
Lyd-output kanaler:	- kanaler
Højttaler, placering:	Gulv
Certificering:	IPX4
Diskanthøjttaler:	Ja
Antal drivere til diskant:	24
Sensitivitet:	94 dB
Delefrekvens:	3500 Hz
Diskant diameter:	25 mm
Bashøjttaler:	Ja
Antal bashøjttalerdrev:	8
Woofer diameter:	100 mm
