INSTRUCTION MANUAL

CCD COLOR CAMERA

IK-VR01A

Please read this manual thoroughly before use, and keep it handy

for future reference.

TABLE OF CONTENTS

Important safeguards

1. Features & Description ................................................. 3

2. Cautions........................................................................ 3

3. Components ................................................................. 3

4. Part Names & Functions ............................................... 4

5. Connections and Operations ........................................ 5

6. Installations ................................................................... 7

7. Line Lock Phase ........................................................... 12

8. Note on use and Installation ......................................... 12

9. In Case of Problems ..................................................... 13

10. Specifications ................................................................ 14

11. Exterior View................................................................. 15

Record in space provided below the Model No. and

the Serial No. as found on the label on the bottom

of this unit.

Model. No. IK-VR01A Serial No.

Retain this information for future reference.

- 1 -

IMPORTANT SAFEGUARDS

1. Read Instructions

All the safety and operating instructions should

be read before the product is operated.

2. Retain Instructions

The safety instructions and instruction manual

should be retained for future reference.

3. Heed Warnings

All warnings on the product and in the instruction

manual should be adhered to.

4. Follow Instructions

All operating and use instructions should be

followed.

5. Cleaning

Disconnect this video product from the power

supply before cleaning.

6. Attachments

Do not use attachments not recommended by the

video product manufacturer as they may cause

hazards.

7. Water and Moisture

Do not use this video product near water-for

example, near a bath tub, wash bowl, kitchen sink,

or laundry tub, in a wet basement, or near a

swimming pool and the like.

8. Accessories

Do not place this video product on an unstable

cart, stand, tripod, bracket or table. The video

product may fall, causing serious injury to a child

or adult, and serious damage to the product. Use

only with stand, tripod, bracket, or table

recommended by the manufacturer, or sold with

the video product. Any mounting of the product

should follow the manufacturer’s instructions, and

should use a mounting accessory recommended

by the manufacturer.

9. Ventilation

This video product should never be placed near

or over a radiator or heat register. This video

product should not be placed in a built-in

installation such as a bookcase or rack unless

proper ventilation is provided or the manufacturer’s

instructions have been adhered to.

10.Power Sources

This video product should be operated only from

the type of power source indicated on the marking

label. If you are not sure of the type of power

supply to your location, consult your product

dealer.

11.Power-Cord Protection

Power-Supply cords should be routed so that they

are not likely to be walked on or pinched by items

placed upon or against them, paying particular

attention to cords at plugs, screws and the point

where they exit from the product.

12.Installation

This video product should be installed on a ﬁrm

and solid part of the ceiling or wall. If installed on

a soft and weak place, the camera unit may fall.

A person under it may be injured and things under

it may be damaged.

13.Lightning

For added protection for this video product during

a lightning storm, or when it is left unattended and

unused for long periods of time, unplug it from

the wall outlet and disconnect the power supply

and cable system. This will prevent damage to

the video product due to lightning and power-line

surges. However, if there is thunder or lightning

now, do not touch the unit and any connected

cable. This will for you not to receive the electric

shock by the serge of thunder.

14.Overloading

Do not overload power supply and extension cords

as this can result in a risk of ﬁre or electric shock.

15.Object and Liquid Entry

Never push objects of any kind into this video

product through openings as they may touch

dangerous voltage points or short-out parts that

could result in a fire or electrical shock. Never spill

liquid of kind on the video product.

16.Servicing

Do not attempt to service this video product

yourself as opening or removing covers may

expose you to dangerous voltage or other hazards.

Refer all servicing to qualiﬁed service personnel.

17.Damage Requiring service

Disconnect this video product from the power

supply and refer servicing to qualified service

personnel under the following conditions.

a. When the power-supply cord or plug is

damaged.

b. If liquid has been spilled, or objects have fallen

into the video product.

c. If the video product has been exposed to rain

or water.

d. If the video product does not operate normally

by following the operating instructions in the

instruction manual. Adjust only those controls that

are covered by the instruction manual as an

improper adjustment of other controls may result

in damage and will often require extensive work

by a qualified technician to restore the video

product to its normal operation.

e. If the video product has been dropped or the

cabinet has been damaged.

f. When the video product exhibits a distinct

change in performance-this indicates a need for

service.

18.Replacement Parts

When replacement parts are required, be sure

the service technician has used replacement parts

specified by the manufacturer with the same

characteristics as the original part. Unauthorized

substitutions may result in ﬁre, electric shock or

other hazards.

19.Safety Check

Upon completion of any service or repairs to this

video product, ask the service technician to

perform safety checks to determine that the video

product is in proper operating condition.

Produkt Specifikationer

Mærke:	Toshiba
Kategori:	Overvågningskamera
Model:	IK-VR01A
Kode for international beskyttelse (IP):	IP66
Vekselstrømsindgangsfrekvens:	60 Hz
Bredde:	170.18 mm
Dybde:	170.18 mm
Højde:	147.32 mm
Vægt:	1315.41 g
Produktfarve:	Hvid
Wi-Fi:	Ingen
Formfaktor:	Kuppel
Format til analogt signal:	NTSC
Ethernet LAN:	Ingen
Strømforbrug (typisk):	4 W
Driftstemperatur (T-T):	-10 - 50 °C
Maksimal opløsning:	771 x 492 pixel
Forbindelsesteknologi:	Ledningsført
Certificering:	UL2044/cUL, FCC Class A
Indbygget kortlæser:	Ingen
Indbygget HDD:	Ingen
Effektkrav:	24V AC, 12V DC
Sensortype:	CCD
Optisk zoom:	- x
Grænseflade:	BNC
Strøm over Ethernet (PoE):	Ingen
Dag/nat funktion:	Ja
Minimumsbelysning:	0.2 Lux
Optisk sensorstørrelse:	1/3 "
Nattesyn:	Ja
Brændviddeområde:	3 - 8 mm
Kameraets lukkerhastighed:	1/60 - 1/100000 sek./side
Signal/støjforhold:	50 dB
F-number (relativ aperture):	1
Kamera lukker type:	Elektronisk
Antal TV-linier:	480
