Quick Installation Guide

Wall Plate Wi-Fi 6 Extender

Note: This guide uses EAP673-Extender for demonstration. Images may

dier from your actual product.

Hardware Overview

1Power On2

LED Indicator

On: Working normally/Initializing.

O: Working abnormally/Power o/LED is turned o.

Flash:

• Flash twice: Initialization is complete.

• Flash once per second: The EAP is upgrading.

• The EAP is resetting or the Omada Quick ash:

Controller is locating the EAP.*

* When the Locate feature is activated in the Omada Controller, the

LED will ash quickly for 10 minutes to help you locate and identify

the device. You can disable this feature manually to stop the device

from ashing.

• The EAP is in isolated state.Sustained ash:

RESET Button

With the EAP powered on, press and hold the button for

about 5 seconds until the LED ashes, then release the

button. The EAP will restore to factory default settings.

LED/Wi-Fi Button

When the EAP is working in Standalone Mode and

enabled with Wi-Fi Control, press the button to turn on/o

both the Wi-Fi and LED. In other cases, press the button

to turn on/o the LED only.

LAN Port

Connect a wired device via an Ethernet cable for network

access.

LED/Wi-Fi Button

RESET Button

LAN Port

LED

Power

Outlet

Plug

Plug the EAP into a power outlet.

Note: For safety, only plug the extender in the direction as shown

below.

Set Up

Choose a method to set up your EAPs:

• Method 1: Controller Mode

To congure and manage EAPs in batches on a

central platform, namely Omada Controller.

• Method 2: Standalone Mesh Mode

To build an Omada Mesh network to congure and

manage EAPs.

Business CommunityDownload CenterSetup Videos

Tip:

You can also set up the EAP in AP Mode to transform your

existing wired network to a wireless one. For details, refer to the

EAP’s user guide at

https://www.tp-link.com/support/download/?type=smb

1. Download and install the TP-Link Omada App from App

Store or Google Play.

2. Add the controller with local access or cloud access.

• Local Access

Note: Local access applies to the Hardware Controller and

Software Controller only.

a. Connect your mobile device to the EAP by using the

default SSIDs printed on the product.

b. Launch the Omada App and go to Controller - Local

Access. Tap the + button on the upper-right corner to

add the controller.

• Cloud Access

a. Launch the Omada App and go to Controller - Cloud

Access.

b. Log in with your TP-Link ID. A list of controllers that

have been bound with your TP-Link ID will appear.

3. Launch the controller, access your site, and go to the

Devices page.

4. Adopt the EAPs and select the uplink AP to build an

Omada Mesh network.

Scan for Omada Omada

Method 1: Controller Mode Method 2: Standalone Mesh Mode

Notes:

• Before you start, be sure to power up and connect your devices

according to the topology gure.

• A DHCP server (typically a gateway/router with the DHCP function

enabled) is required to assign IP addresses to the EAPs and clients

in your local network.

• If you use an Omada Hardware/Software Controller, it must have

network access to your Omada devices (the gateway/router,

switch, and EAPs) in order to nd, adopt, and manage them.

Notes:

• Before you start, be sure to power up and connect your devices

according to the topology gure.

• A DHCP server (typically a gateway/router with the DHCP function

enabled) is required to assign IP addresses to the EAPs and clients

in your local network.

Switch

Gateway/Router

Clients

EAP EAP

Mesh

Omada

Hardware/Software

Controller

Omada

Cloud-Based

Controller

Root AP

Switch

Gateway/Router

Clients

EAP EAP

Mesh

Root AP

1. Get an Omada Controller ready.

•

Option 1: Omada Hardware Controller

Purchase a Hardware Controller and refer to its

Installation Guide to set it up.

•

Option 2: Omada Software Controller

On a PC with Windows or Linux OS, download the

Software Controller from

https://www.tp-link.com/support/download/omada-

software-controller/. Then run the file and follow the

wizard to set up the controller.

Note: To manage your devices, the Software Controller needs to

keep running on your PC.

• Option 3: Omada Cloud-Based Controller

Go to the Omada Portal

(https://omada.tplinkcloud.com) and log in with your

TP-Link ID. Then click + Add Controller to add a

Cloud-Based Controller and set it up.

2. Launch the controller, access your site, and go to the

Devices page.

3. Adopt the EAPs and select the uplink AP to build an

Omada Mesh network.

Tip: For the Omada Hardware/Software Controller, you are

recommended to enable Cloud Access and bind it to your TP-Link ID.

This enables you to remotely access and manage the controller and

Omada devices via Omada Portal (https://omada.tplinkcloud.com).

For detailed configurations, refer to the User Guide of the

controller at our official website:

https://www.tp-link.com/support/download/?type=smb

For technical support, the user guide and

other information, please visit

https://www.tp-link.com/support/?type=smb,

or simply scan the QR code.

Omada Controller integrates Omada gateways/routers,

switches, access points, and more for centralized cloud

management.

Via Web Browser Via Omada App

1. Download and install the TP-Link Omada App from

App Store or Google Play.

2. Connect your mobile device to your root AP.

3. Open the Omada App, go to Standalone Mode >

Switch to Mesh Management > EAPs.

4. Create Click and follow app instructions to add your

root AP and EAPs to form an Omada mesh network.

Scan for Omada Omada

If your network has a root AP that supports Omada Mesh,

you can also add and congure EAPs in Standalone Mesh

mode.

Safety Information

• Keep the device away from water, re, humidity or hot environments.

• Do not attempt to disassemble, repair, or modify the device. If you need

service, please contact us.

• Do not use the device where wireless devices are not allowed.

• The socket-outlet shall be installed near the equipment and shall be

easily accessible.

• (For the 3-pin-plug version) Plug the product into the wall outlets with

earthing connection through the plug.

TP-Link hereby declares that the device is in compliance with the

essential requirements and other relevant provisions of directives

2014/53/EU, 2009/125/EC, 2011 /65/EU and (EU) 2015/863.

The original EU Declaration of Conformity may be found at

https://www.tp-link.com/en/support/ce/

TP-Link hereby declares that the device is in compliance with the

essential requirements and other relevant provisions of the Radio

Equipment Regulations 2017.

The original UK Declaration of Conformity may be found at

https://www.tp-link.com/support/ukca/

AX5400 Wall Plate Wi-Fi 6 Extender EAP673-Extender
