Video Training
Don't think you need to be a computer genius to use the Low Voltage Pro. It
is remarkably easy to use because all of the tests available on your model
are displayed at the same time on the LCD. Plus, we have short training
videos for each test APP that makes mastering the LVPro a lot quicker
than reading this manual.
View training using your computer:
Go to www.triplett.com/byte-brothers/lvpro-video-wall/
View training using your smartphone or tablet:
Click on the QR code below.
Limited Warranty
The manufacturer warrants to the original consumer that this product is in
good working order for a period of one year from the date of manufacture
or date of purchase. During this period the product will be repaired or
replaced without charge for either parts or labor. The warranty does not
cover damage caused by improper use. Repair or replacement as provided
under this warranty is the exclusive remedy of the purchaser.
Low Voltage Pro User's Guide. Made in the USA.
Feet and Metric selectable. Metric setting also prints reports in metric units (Model 30).
iPad, iPhone and Android are trademarks owned by their respective companies
Low Voltage Pro, LVPro, Test APPs, RLQ, Return Loss Quality, LCD and icon designs and many
terms used in this manual are trademarks of Triplett.
Patents pending.
The next generation of technology and testing
The LVPro employs the latest technology to get you the highest quality
testing for your low voltage projects at the best price. The TIA 586 tests,
PASS/FAIL, wiremap, timing tests (delay, skew) and impedance mea-
surement (ohms) are standard on all Low Voltage Pros. And if you need
more, you can upgrade your tester via the web.
Add to the cable testing powerful device tests; web downloadable test
APPS to expand the capabilities of the LVPro, a connection to your PC for
the easy setting of parameters, upgrading the tester, downloading reports
(Model 30) and you have a tool that will be your job partner for many years.
A note about QR codes: A QR code is a barcode-like system that saves you the
time of having to key in the web address (available on smartphones, iPhones, iPads,
Android, etc only). First, download a QR Reader APP to scan the QR code. Scan-
ning the QR code starts our videos without any web address entry required. If you
don't have a smartphone or tablet, don't worry. You can use your computer's browser
address line to go to
www.triplett.com/byte-brothers/lvpro-video-wall and see the exact same videos.
Triplett.com
Learning the Low Voltage Pro
From the web: Go to
www.triplett.com/byte-brothers/lvpro-video-wall/
or
From you smartphone or tablet :
Scan the QR code
