Side 1/12

Video Splitter

(2 and 4 Port)

Models: B114-002-R, B114-004-R

Note: Follow these installation and operating procedures to ensure

correct performance and to prevent damage to this unit or to its connected devices.

Introduction 2

Package Contents 2

Product Features 2

Installation 2

Specifications 3

Warranty & Product Registration 3

Español 5

Français 9

Owner's Manual

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

All trademarks are the property of their respective owners.

WARRANTY REGISTRATION

automatically entered to win an ISOBAR®

surge protector in our monthly drawing!

tripplite.com/warranty

Stand-Alone Installation:

1. Connect the PC's video output port to the Video Splitter's “Video In” port using an HDDB15

Male/Female Monitor Extension Cable (such as Tripp Lite’s P500-Series Cables).

2. Connect the Video Splitter's “Video Out” ports to the input of your monitors either by using the

existing cable on the monitor or by using an HDDB15 Male/Male Monitor Cable

(such as Tripp Lite’s P502-Series Cables).

3. Connect the provided power supply to the Video Splitter and turn on the unit. Your Video

Splitter is ready to go.

WARNING!

Use ONLY the 9V DC external power supply included with the unit.

The Video Splitter is a signal booster and splitter that takes video input from a single source

and directs it to multiple video outputs for monitors using analog signals. It extends the distance

a signal is sent up to 210 ft.

• B114-002-R or B114-004-R

• External Power Supply (Input: 100-240V, 50/60Hz, 0.4A Output: 9V 1A)

• Owner’s Manual

Introduction

Package Contents

Product Features

Installation

• One video input to multiple video outputs

• Transmission distance of up to 210 feet

• Suitable for VGA/SVGA/XGA/UXGA and Multisync monitors

• Cascade up to 3 levels of splitters to increase the number of outputs

• Supports 350 MHz bandwidth

IMPORTANT NOTE: This unit is not designed for CGA, EGA or MONOCHROME type

monitors or any monitor using a digital video signal.

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Splitter
Model:	B114-004-R
Bredde:	132.1 mm
Dybde:	94 mm
Højde:	43.2 mm
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	730 g
Pakkedybde:	251.5 mm
Pakkebredde:	144.8 mm
Pakkehøjde:	61 mm
Maksimal opløsning:	2048 x 1536 pixel
Husmateriale:	Metal
Certificering:	RoHS
DC-in-stik:	Ja
AC-adapter inkluderet:	Ja
Harmoniseret systemkode (HS):	8525.50.3040
Hovedkassen højde (udvendigt):	320 mm
Hovedkassens længde (udvendigt):	309.9 mm
Hovedkassens bruttovægt (udvendigt):	7570 g
Hovedkassens bredde (udvendigt):	266.7 mm
Oprindelsesland:	Kina
Stik:	HD15 (MALE), HD15 (FEMALE) (X4)
Produkter pr. hovedkasse (udvendigt):	10 stk
Maksimal driftstilstand:	64 m
Hovedkasse (udvendig) GTIN (EAN/UPC):	20037332014270
Videoudgang:	4x VGA
Video porttype:	VGA
Antal videoporte:	5
Båndbredde:	350 MHz
