Tripp Lite B127U-002-PDPH2 Manual

Tripp Lite AV forlænger B127U-002-PDPH2

Læs gratis den danske manual til Tripp Lite B127U-002-PDPH2 (8 sider) i kategorien AV forlænger. Denne vejledning er vurderet som hjælpsom af 4 personer og har en gennemsnitlig bedømmelse på 4.9 stjerner ud af 2.5 anmeldelser. Har du et spørgsmål om Tripp Lite B127U-002-PDPH2, eller vil du spørge andre brugere om produktet?

Side 1/8
2-Port DisplayPort to HDMI
Over Cat6 Pigtail Splitter/
Extender Kit, 4K/60 Hz
Model: B127U-002-PDPH2
1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support
Copyright © 2023 Tripp Lite. All rights reserved.
Owner's Manual
Este manual está disponible en español en la página de Tripp Lite: tripplite.com
Русскоязычная версия настоящего руководства представлена на
веб-сайте компании Tripp Lite по адресу: tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar:
tripplite.com
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
2
Extends a 4K x 2K (3840 x 2160) @ 60 Hz A/V signal from a
DisplayPort source to two HDMI displays up to 230 ft. (70 m)
from the source over 24 AWG Cat6 cabling
Transmitter and receiver units can be powered by the built-
display or to a USB power adapter, or by the Micro-USB
ports on each unit
Multi-resolution technology allows the receivers to connect
to any 1080p, 4K/30 Hz or 4K/60 Hz display without a󰀨ecting
the resolution of the other displays connected to the splitter
1 ft. HDMI connectors on transmitter and receiver units
connect to the source and display
Supports passthrough audio formats up to 7.1-channel
surround sound
Real-time video compression and decompression technology
Compatible with HDCP 2.2 and 1.4 and High Dynamic
Range (HDR)
Compatible with any B127U-Series transmitter or splitter to
create exible DisplayPort and HDMI video installations
Compatible with DisplayPort (B127U-110-PD) and HDMI
(B127U-110-PH) receivers to create exible daisychain
installations with multiple video outputs. Each port on the
splitter can extend up to four connected receivers, for a
total of eight receivers and 920 feet per daisychain (sold
separately).
Product Features


Produkt Specifikationer

Mærke: Tripp Lite
Kategori: AV forlænger
Model: B127U-002-PDPH2
Type: AV -sender og transceiver
Antal pr. pakke: 1 stk
Brugervejledning: Ja
Produktfarve: Black, Grey
Pakkevægt: 640 g
Pakkedybde: 164.1 mm
Pakkebredde: 260.1 mm
Pakkehøjde: 55.1 mm
Understøttede videotilstande: 720p, 1080p, 2160p
3D: Ja
Opbevaringstemperatur (T-T): -15 - 50 °C
Relativ luftfugtighed ved drift (H-H): 0 - 85 %
Relativ luftfugtighed ved opbevaring (H-H): 0 - 85 %
HDCP: Ja
Understøttede lydformater: LPCM
Driftstemperatur (T-T): 0 - 40 °C
Maksimal opløsning: 3840 x 2160 pixel
Pakketype: Kasse
Understøttede grafikopløsninger: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA), 3840 x 2160
High Dynamic Range (HDR) understøttet: Ja
Materiale: Plast
Forbindelsesteknologi: Ledningsført
LED-indikatorer: Ja
Kabellængde: 0.3 m
Antal USB-porte: 3
Bæredygtighedscertifikater: CE, Federal Communications Commission (FCC), REACH, RoHS, Trade Agreements Act (TAA), UKCA, WEEE
Farvedybde: 36 Bit
Modtager vægt: 250 g
Maksimal overførselsafstand: 70 m
USB-drevet: Ja
Overholdelse af bæredygtighed: Ja
RJ-45 indgangs-porte: 2
Antal HDMI-udgange: 2
Stativ-montering: Ingen
Modtager dimensioner (BxDxH): 47 x 75 x 18.6 mm
Opløsning: 3840 x 2160 pixel
HDCP-version: 1.4/2.2
Senderdimensioner (BxDxH): 47 x 75 x 18.6 mm
Transmitter vægt: 250 g
RJ-45 udgangs-porte: 4
DisplayPorts indgang: 1
Udvidet display identifikationsdata (EDID): Ja
Daisy kæde: Ja
