Side 1/16
Introduction 2
Features 3
Mounting 5
Quick Installation 7
Optional Installation 8
Basic Operation 9
Power Module Replacement 12
Battery Replacement 13
Storage 14
Service 14
Warranty 15
Warranty Registration 15
Owners Manual
SmartPro® Rackmount
Intelligent, Line-Interactive UPS System
Model: SMART3000RMOD2U
110/120/127V Sine Wave Input/Output • 3000VA
1111 W. 35th Street, Chicago, IL 60609 USA • (773) 869-1234 •www.tripplite.com
Copyright © 2008 Tripp Lite. All rights reserved. SmartPro
® is a registered trademark of Tripp Lite.
Not suitable for mobile applications.
Warranty
Registration:
register online today for a
chance to win a FREE Tripp Lite
product—www.tripplite.com/warranty
Español 17
Français 33
2
UPS Location Warnings
The UPS is extremely heavy. Use caution when lifting and installing.•
Install the UPS indoors, away from excess moisture or heat, direct sunlight, dust and conductive contaminants.•
Install the UPS in a structurally sound area. •
Only operate the UPS at indoor temperatures between 32° F and 104° F (between 0° C and 40° C). For best results, keep indoor temperatures •
between 62° F and 84° F (between 17° C and 29° C).
Leave adequate space around all sides of the UPS for proper ventilation. Do not obstruct its ventilation fans or openings.
•
Do not install the UPS near magnetic storage media, as this may result in data corruption.•
If you are installing the UPS in a stack configuration, always stack the power module above the battery module(s) if present.•
Do not mount unit with its front or rear panel facing down (at any angle). Mounting in this manner will seriously inhibit the unit's internal •
cooling, eventually causing product damage not covered under warranty.
UPS Connection Warnings
The power supply for this unit must be rated in accordance with the equipment nameplate. It also must be suitably grounded.
Connect the UPS system only to a NEMA L5-30R receptacle (outlet).
Connect the UPS to a properly grounded AC power source. Do not modify the input connection in a way that would eliminate the connection to
ground.
Do not use adapters that eliminate the connection to ground.
Do not connect the UPS input to its output; this will damage the UPS and void the warranty.
If you are connecting the UPS to a motor-powered AC generator, the generator must provide filtered, frequency-regulated computer-grade output.
Connecting the UPS to a generator will void its Ultimate Lifetime Insurance.
Equipment Connection Warnings
Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support
equipment or to significantly affect its safety or effectiveness is not recommended. Do not use this equipment in the presence of a flammable
anesthetic mixture with air, oxygen or nitrous oxide
The UPS is connected to a DC energy source (battery). The output terminals may be live even when the UPS is not connected to an AC power
source.
Do not connect surge suppressors or extension cords to the output of the UPS. This might overload the UPS and will void the surge suppressor and
UPS warranties.
Maintenance Warnings
The UPS does not require routine maintenance. Do not open the UPS for any reason. There are no user-serviceable parts inside.
Battery Warnings
Connect only Tripp Lite battery packs to the battery connectors. Connect battery packs of the correct voltage and type.
Batteries can present a risk of electrical shock and burn from high short-circuit current. Observe proper precautions. Do not dispose of the batteries
in a fire. Do not open the UPS or batteries. Do not short or bridge the battery terminals with any object. Unplug and turn off the UPS before
performing battery replacement. Use tools with insulated handles. There are no user-serviceable parts inside the UPS. Battery replacement should be
performed only by authorized service personnel using the same number and type of batteries (Sealed Lead-Acid). The batteries are recyclable. Refer
to your local codes for disposal requirements or in the USA only call 1-800-SAV-LEAD or 1-800-8-BATTERY (1-800-822-8837) or visit
www.rbrc.com for recycling information. Tripp Lite offers a complete line of UPS System Replacement Battery Cartridges (R.B.C.).Visit Tripp Lite
on the Web at www.tripplite.com/support/battery/index.cfm to locate the specific replacement battery for your UPS.
Do not open or mutilate the batteries. Released electrolyte is harmful to the skin and eyes, and may be toxic.
Fuses should be replaced only by factory-authorized personnel. Blown fuses should be replaced only with fuses of the same number and type.
Service and repair should be performed only by trained personnel. During any service work to the UPS, it should be turned off.
Do not connect or disconnect external battery pack(s) while the UPS is operating from the battery supply.
During hot-swap battery pack replacement, the UPS will not provide backup power in the event of a blackout or other power interruption.
SAVE THESE INSTRUCTIONS. This manual contains important instructions and warnings that should be followed
during the installation and maintenance of this UPS system.
Introduction


Produkt Specifikationer

Mærke: Tripp Lite
Kategori: Uafbrydelig strømforsyning (UPS)
Model: SMART3000RMOD2U
Bredde: 444 mm
Dybde: 610 mm
Højde: 89 mm
Vægt: 39500 g
Produktfarve: Sort
Pakkevægt: 47200 g
Pakkedybde: 1011 mm
Pakkebredde: 605 mm
Pakkehøjde: 234 mm
Formfaktor: Reolbeslag/tårn
Responstid: 4 ms
Opbevaringstemperatur (T-T): -15 - 50 °C
Relativ luftfugtighed ved drift (H-H): 0 - 95 %
Antal USB 2.0-porte: 1
Driftstemperatur (T-T): 0 - 40 °C
Husmateriale: Stål
Udgangseffekt: 2880 W
Certificering: UL1778, CSA, NOM, FCC
LED-indikatorer: Ja
Kabellængde: 3 m
Opladningstid for batteri: 4 t
Bæredygtighedscertifikater: RoHS,ENERGY STAR
Indgangsfrekvens: 50/60 Hz
Lydalarmer: Ja
Strømbeskyttelsesfunktioner: Over voltage,Under voltage
Effektivitet: 95 %
Antal serielle porte: 1
Strømstik: NEMA L5-30P
Kølingstype: Aktiv
Nominel udgangsspænding: 120 V
Nominel indgangsspænding: 120 V
AC udgange, antal: 7 AC stikkontakt(er)
AC stikkontakt typer: NEMA 5–15R,NEMA L5-30R
Overspænding energivurdering: 800 J
Indgående driftsspænding (maks.): 146 V
Rackkapacitet: 2U
Output strømkapacitet (VA): 3 kVA
Indgående driftsspænding (min.): 90 V
Udgangs driftsspænding (min.): 100 V
Udgangs driftsspænding (maks.): 127 V
UPS topologi: Interaktivt indgangsstik
Strøm (maks.): 30 A
Bølgeform: Sine
Typisk backup tid ved halv styrke: 11 min.
Typisk backup tid ved fuld styrke: 4 min.
Koldstart: Ja
Hot-swap batteri: Ja
Automatisk spændingsregulering (AVR): Ja
Nødstrøm Off (EPO): Ja
EMI/RFI støjfiltrering: Ja
Antal indgående faser: 1
