Gebruikshandleiding
Friteuse
VOORWOORD
Over dit document
Deze gebruikshandleiding bevat alle informatie voor een juist, veilig en doelmatig
gebruik van het apparaat.
Lees en begrijp de aanwijzingen in deze gebruiksaanwijzing volledig voordat je het
apparaat gebruikt.
Bewaar deze gebruiksaanwijzing steeds op een veilige plaats in de buurt van het
apparaat voor toekomstige raadpleging.
Deze handleiding is oorspronkelijk geschreven in het Engels. Alle andere talen zijn
vertaalde documenten.
Algemene symbolen
Symbool Beschrijving
6
WAARSCHUWING
Signaalwoord dat gebruikt wordt om een
mogelijk gevaarlijke situatie aan te geven
die, als deze niet vermeden wordt, ernstige
verwondingen of de dood tot gevolg kan
hebben.
6
VOORZICHTIG
Signaalwoord dat gebruikt wordt om een
mogelijk gevaarlijke situatie aan te geven
die, als deze niet vermeden wordt, lichte of
matige verwondingen kan veroorzaken.
OPMERKING
Signaalwoord gebruikt voor het benoemen
van praktijken niet gerelateerd aan fysiek
letsel.
Wijst op aanvullende informatie of het
benadrukken van een instructie.
Dit product voldoet aan de
conformiteitseisen van de toepasselijke
Europese verordeningen of richtlijnen
Dit symbool wordt gebruikt voor het
markeren van materialen die bestemd zijn
om in aanraking te komen met voedsel in
de Europese Unie, zoals gedenieerd in
verordening (EC) nr. 1935/2004
The Green Dot is het geregistreerde
handelsmerk van Der Grüne Punkt -
Duales System Deutschland GmbH
en is een wereldwijd beschermd
handelsmerk. Het logo mag uitsluitend
worden gebruikt door klanten van DSD
GmbH die in het bezit zijn van een geldig
handelsmerkgebruikscontract of door
aangewezen afvalverwerkingsbedrijven
binnen de Bondsrepubliek Duitsland. Dit
geldt ook voor de reproductie van het
logo door derden in een woordenboek,
een encyclopedie of een elektronische
databank meteen naslagwerk.
Het universele recyclingsymbool, -logo
of -pictogram is een internationaal
erkend symbool dat wordt gebruikt om
recyclebare materialen aan te duiden. Het
recyclingsymbool behoort tot het publieke
domein en is geen handelsmerk.
Van toepassing in Frankrijk:
Het product of de verpakking kan worden
gerecycled en de onderdelen moeten apart
worden weggegooid. Volg de plaatselijke
regelgeving.
Van toepassing in Italië:
Het product of de verpakking kan worden
gerecycled en de onderdelen moeten apart
worden weggegooid. Volg de plaatselijke
regelgeving.
Afgedankte elektrische producten mogen
niet samen met huishoudelijk vuil worden
weggegooid. Gelieve te laten recyclen bij
de daartoe aangewezen faciliteiten. Neem
contact op met uw gemeente of plaatselijke
winkel voor advies over recycling.
BESCHRIJVING APPARAAT
Over dit apparaat
De Tristar FR-9327 is een friteuse om voedsel in te frituren.
Beoogd gebruik
Dit apparaat is uitsluitend bedoeld voor gebruik binnenshuis.
Dit apparaat is uitsluitend bedoeld voor huishoudelijk, niet-commercieel gebruik.
Dit apparaat is bedoeld om gebruikt te worden in huishoudelijke en soortgelijke
toepassingen zoals:
- personeelskeukenbereiken in winkels, kantoren en andere werkomgevingen;
- boerderijen;
- door klanten in hotels, motels en andere types residentiële omgevingen;
- omgevingen van het type bed and breakfast
Dit apparaat is niet bedoeld voor gebruik door personen ( waaronder kinderen) met
verminderde lichamelijke, zintuiglijke of geestelijke vermogens, of gebrek aan ervaring
en kennis, tenzij zij onder toezicht staan of instructies hebben gekregen betreffende
het gebruik van het apparaat van een persoon die verantwoordelijk is voor hun
veiligheid.
Dit apparaat mag niet worden gebruikt door kinderen jonger dan 8 jaar. Dit apparaat
kan worden gebruikt door kinderen vanaf 8 jaar en door personen met verminderde
lichamelijke, zintuiglijke of geestelijke vermogens of gebrek aan de benodigde ervaring
en kennis indien ze onder toezicht staan of instructies krijgen over hoe het apparaat
op een veilige manier kan worden gebruikt alsook de gevaren begrijpen die met het
gebruik samenhangen. Kinderen mogen niet met het apparaat spelen. Houd het
apparaat en het netsnoer buiten bereik van kinderen jonger dan 8 jaar. Laat reiniging
en onderhoud niet door kinderen uitvoeren, tenzij ze ouder zijn dan 8 jaar en onder
toezicht staan.
Het apparaat is niet bedoeld om bediend te worden met behulp van een externe timer
of een afzonderlijk afstandbedieningssysteem.
Elk gebruik van het apparaat anders dan beschreven in deze gebruiksaanwijzing wordt
beschouwd als verkeerd gebruik en kan letsel of schade aan het apparaat veroorzaken
en de garantie ongeldig maken.
Technische specicaties
Naam apparaat Friteuse
Artikelnummer FR-9327
Voeding 230V~ 50-60Hz
Stroomverbuik tijdens gebruik 2000 W
Belangrijkste onderdelen (zie afbeelding A)
1
Aan/uit-lampje (rood)
2
Verwarmingslampje (groen)
3
Deksel
4
Verwarmingselement
5
Frituurvetbak
6
Mand
7
Basisunit
8
Handgreep
9
Filter
q
Kijkvenster
w
Resetknop
VEILIGHEID
Veiligheidssymbolen
Symbool Beschrijving
Aanwijzing voor een heet oppervlak.
Contact kan brandwonden
veroorzaken. Niet aanraken.
Veiligheidsvoorzorgsmaatregelen
6
WAARSCHUWING
Veiligheidsgevaar door onbedoeld gebruik:
• Door de veiligheidsinstructies te negeren, kan de
fabrikant niet verantwoordelijk worden gehouden
voor de schade.
• Als de voedingskabel beschadigd is, moet deze
worden vervangen door de fabrikant, diens
servicedienst of gelijkwaardig gekwalificeerd
personeel om gevaren te voorkomen.
• Til het apparaat nooit op aan de voedingskabel.
Als je het apparaat aan de voedingskabel optilt,
kun je de voedingskabel beschadigen. Til het
apparaat alleen op door de voet vast te houden.
• Het apparaat moet op een stabiele, vlakke
ondergrond worden geplaatst.
• Dit apparaat mag niet worden gebruikt door
kinderen jonger dan 8 jaar. Dit apparaat kan
worden gebruikt door kinderen vanaf 8 jaar en
door personen met verminderde lichamelijke,
zintuiglijke of geestelijke vermogens of gebrek
aan de benodigde ervaring en kennis indien ze
onder toezicht staan of instructies krijgen over
hoe het apparaat op een veilige manier kan
worden gebruikt alsook de gevaren begrijpen die
met het gebruik samenhangen. Kinderen mogen
accessories or approaching parts that move in
use.
6
CAUTION
Burning hazard due to heat:
• Children should be supervised to ensure that
they do not play with the appliance.
• Never touch the hot surfaces during or shortly
after use. The hot surfaces may be subject to
residual heat. Let the appliance cool down
completely before handling the appliance.
Tripping hazard due to loose cables:
• Never leave the power cable hanging out in a
way that someone might trip over it or
accidentally pull it.
NOTICE
Risk of damaging the appliance:
• The appliance must be placed on a stable, level
surface.
• Never use aggressive chemical cleaning agents
that can damage the appliance when cleaning
the appliance.
• Only use the appliance with the provided
accessories or accessories recommended by
Tristar.
• Never fill the pan above the maximum capacity
marking to prevent overflowing.
• Never place the appliance in a dishwasher.
• Never place the appliance near the edge of a
countertop during use. Vibrations may occur
during use which may cause the appliance to
move. Always place the appliance on a stable,
flat, heat, and moisture resistant surface.
• Never use metal utensils to remove food from
the pan. Metal utensils may damage the non-
stick coating.
BEFORE FIRST USE
• Take the appliance and accessories out the box. Remove the stickers, protective
foil or plastic from the device.
• Place the device on a flat stable surface and ensure a minimum of 10 cm. free
space around the device. This device is not suitable for installation in a cabinet or
for outside use.
• Before using the appliance for the first time or after long pauses, wipe off all
removable parts with a damp cloth. Never use abrasive products.
• Connect the power cable to the socket. Note : Make sure the indicated voltage on
the device matches the local voltage before connecting the device.
• This type of fryer is only suitable for use with oil or liquid fat, and not for solid fat
• Using solid fat entails the risk of trapping water in the fat which will cause it to
spatter violently when heated up.
• Ensure that the oil/fat is not contaminated with water, for example from frozen
products, this will cause excessive spattering.
• Never use the fryer without oil or fat as this will damage the appliance.
• Never pour any liquid, such as water, in the pan.
USE
• Wash the basket in warm soapy water and dry it well before use. Clean the inside
of the pan with a damp cloth and wipe it dry thoroughly. Ensure that all electrical
parts remain completely dry.
• Fill the appliance with the required amount of oil or fat. Ensure that the appliance is
filled at least to the minimum level and not higher than the maximum level, as
indicated on the inside of the fryer. For optimal results we advise to avoid mixing
different types of oil.
• Plug in the appliance. The red indicator light will be on, the green indicator light will
be off
• Adjust the temperature control knob to the required temperature, the green indicator
light will be on.
• When the oil reaches the require temperature About 10 minutes late
• Use the handle to lift the basket from the fryer
• Place the food to be fried in the basket. For the best results the food should be dry
before being placed in the basket. Immerse the basket into the oil or fat slowly to
prevent the oil from bubbling up too strongly. To ensure the oil stays at the correct
temperature, the thermostat will switch on and off. The red control light will also go
on and off.
• Lift the basket when the frying time has elapsed and hang it on the hook in the pan
so the oil can drip off.
Food type Temperature (°C) Cooking time
Mushrooms 160°C 4 – 6 minutes
Fish 160°C 4 – 6 minutes
Drumsticks 170°C 9 – 11 minutes
Shrimp 180°C 4 – 5 minutes
Meat 180°C 3 – 5 minutes
Fries 190°C 10 – 12 minutes
Frying Tips
• Use a maximum of 200 grams of chips per litre of oil.
• When using frozen products, use a maximum of 100 grams because the oil cools
off rapidly. Shake frozen products above the sink to remove excess ice.
• When fresh chips are used, dry the chips after washing them to ensure no water
gets into the oil. Fry the chips in two turns. First time (blanch) 1 to 5 minutes at 170
degrees. Second time (finishing) 2 to 4 minutes at 175 degrees. Allow the oil to drip
off.
Changing the oil
• Make sure the fryer and the oil or fat have cooled down before changing the oil or
fat (remove the plug of the device from the socket). Change the oil regularly. This is
particularly necessary when the oil or fat goes dark or the smell changes. Always
change the oil after every 10 frying sessions. Change the oil in one go. Never mix
old and new oil.
• Used oil is harmful to the environment. Do not dispose of it with your normal rubbish
but follow the guidelines issued by the local authorities.
Reset Function
• In the case of overheating, the pan will switch off automatically. This safety
mechanism can be found at the back of the control panel. If it is switched off, you
first need to remove the plug from the socket and wait till the fryer has cooled down.
After this the deepfryer can be reactivated by pressing the RESET button.
CLEANING AND MAINTENANCE
• Always unplug the power cable when the appliance is not in use or unattended, and
before cleaning.
• Wash the basket and the oil compartment with soapy water.
Important: Never wet the electrial part of the unit.
• Refit all parts once they are completely dry.
STORAGE
Store the appliance in a dry and enclosed space.
Make sure all parts are clean and dry.
TROUBLESHOOTING
Problem Possible cause Possible solution
The Fryer does not work The power cable is not
properly connected to a
working power outlet.
Plug the power cable into a
working power outlet.
The ingredients fried with
the fryer are not done.
The amount of the
ingredients in the basket is
too much.
Put smaller batches of
ingredients in the basket.
Smaller batches are fried
more evenly.
The preparation time is too
short.
Turn the temperature
control button to the
required temperature setting
(see section 'Settings').
The temperature is set too
low.
Turn the temperature
control knob to the required
preparation time (see
section 'Settings').
The Fryer does not work The device is overheating. Reactivate the fryer by
pressing the reset button
A
w
.
ENVIRONMENT
This appliance should not be put into the domestic garbage at the end
of its durability, but must be oered at a central point for the recycling of
electric and electronic domestic appliances. This symbol on the appliance,
instruction manual and packaging puts your attention to this important
issue. The materials used in this appliance can be recycled. By recycling
of used domestic appliances you contribute an important push to the
protection of our environment. Ask your local authorities for information
regarding the point of recollection.
Support
You can nd all available information and spare parts at www.tristar.eu!
The appliance is not intended to be operated by means of an external timer or a
separate remote-control system.
Any use of the appliance other than described in this user manual is regarded as
misuse and may cause injury or damage to the appliance and void the warranty.
Technical specications
Appliance name Deep fryer
Article number FR-9327
Power supply 230V~ 50-60Hz
Power consumption in use 2000 W
Main parts (see image A)
1
Power light (red)
2
Heating light (green)
3
Lid
4
Heating element
5
Frying grease container
6
Basket
7
Base unit
8
Handle
9
Filter
q
Viewing window
w
Reset knob
SAFETY
Safety symbols
Symbol Description
Indication for a hot surface. Contact
may cause burns. Do not touch.
Safety precautions
6
WARNING
Safety hazard due to unintended use:
• By ignoring the safety instructions the
manufacturer cannot be held responsible for the
damage.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.
• Never lift the appliance by the power cable.
Lifting the appliance by the power cable may
damage the power cable. Only lift the appliance
by holding the base.
• The appliance must be placed on a stable, level
surface.
• This appliance shall not be used by children
aged less than 8 years. This appliance can be
used by children aged from 8 years and above
and persons with reduced physical, sensory or
mental capabilities or lack of experience and
knowledge if they have been given supervision
or instruction concerning use of the appliance in
a safe way and understand the hazards
involved. Children shall not play with the
appliance. Keep the appliance and its cord out
of reach of children aged less than 8 years.
Cleaning and user maintenance shall not be
made by children unless older than 8 and
supervised.
• To protect yourself against an electric shock, do
not immerse the cord, plug or appliance in the
water or any other liquid.
• Never use the appliance if there are visible signs
of damage or defects. Always replace a
damaged or defective appliance immediately.
• Never immerse the fryer in water.
Electric shock hazard due to short-circuiting:
• Never use the appliance if there are visible signs
of damage or defects to the appliance or power
cable. Always replace a damaged or defective
appliance or power cable immediately or contact
customer service.
• Always avoid spillage on the power cable.
• Never open the appliance. The appliance may
only be opened for maintenance by an
authorised technician.
• Never replace the power cable yourself. Always
let the manufacturer, its service agent or a
similarly qualified person replace the power
cable.
• Always unplug the power cable when the
appliance is not in use or unattended, and
before cleaning.
• Always check if the voltage stated on the type
plate of your appliance matches your mains
voltage before use.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.
• Never move the appliance by pulling the cord
and make sure the cord cannot become
entangled.
Fire hazard due to overheating:
• Never leave the appliance unattended when in
use. Only use the appliance under supervision.
Switch off the appliance and remove the power
cable from the power outlet when you leave the
room.
• Never place the appliance directly underneath a
power outlet. The appliance may become hot
during use. Always keep the back of the
appliance clear of any objects.
• In order to prevent disruptions of the airflow do
not put anything on top of the appliance and
make sure there is always 10 centimeter of free
space around the appliance.
• Never place the appliance near a heat source.
Fire hazard due to short-circuiting:
• Never drop the appliance and avoid bumping.
Excessive vibrations can lead to loosened
connections and can influence proper
functioning of the appliance. Stop using the
appliance if the appliance has been dropped.
• Never use the appliance with an extension
cable.
• Never connect any other appliance with high
power consumption to the same group.
Fire hazard due to burnt food:
• Always clean all parts that come into contact
with food after use.
• Ensure the oil is within the maximum and
minimum marks in the pot when in use.
Burning hazard due to hot liquids:
• Never use the appliance on recreational vehicles
or boats. Hot liquid may spill out of the
appliance.
• Never move the appliance during use. Hot liquid
may spill out of the appliance.
• Always allow the oil to cool before moving the
fryer, as hot oil can cause serious burns.
Choking hazard due to plastic packaging:
• Never let children play with the packaging
material. Always keep the packaging material
out of the reach of children.
Snagging hazard due to moving parts:
• Always switch off and disconnect the appliance
from the power source before changing
a
User manual
Deep fryer
FOREWORD
About this document
This user manual contains all the information for correct, safe, and efficient use of the
appliance.
Ensure you have fully read and understood the instructions in this user manual before
you use the appliance.
Always store this user manual in a safe place near the appliance for future reference.
This manual is originally written in English. All other languages are translated
documents.
General symbols
Symbol Description
6
WARNING
Signal word used to indicate a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
6
CAUTION
Signal word used to indicate a potentially hazardous
situation which, if not avoided, could result in minor or
moderate injury.
NOTICE
Signal word used to address practices not related to
physical injury.
Indicates additional information or emphasis on an
instruction.
This product complies with conformity requirements of
the applicable European regulations or directives.
This symbol is used for marking materials intended to
come into contact with food in the European Union as
dened in regulation (EC) No 1935/2004.
The Green Dot is the registered trademark of Der
Grüne Punkt – Duales System Deutschland GmbH and
is protected as a trademark worldwide. The logo may
only be used by customers of DSD GmbH holding a
valid trademark usage contract or by engaged waste
management companies within the Federal Republic of
Germany. This also applies to reproduction of the logo
by third parties in a dictionary, an encyclopaedia or an
electronic database containing a reference manual.
The universal recycling symbol, logo, or icon is an
internationally recognized symbol used to designate
recyclable materials. The recycling symbol is in the
public domain and is not a trademark.
Applicable in France:
The product or packaging can be recycled and
components must be disposed of separately. Follow the
local regulations.
Applicable in Italy:
The product or packaging can be recycled and
components must be disposed of separately. Follow the
local regulations.
Waste electrical products should not be disposed of
with household waste. Please recycle where facilities
exist. Check with your local authority or local store for
recycling advice.
APPLIANCE DESCRIPTION
About this appliance
The Tristar FR-9327 is an deep fryer for frying food.
Intended use
This appliance is intended for indoor use only.
This appliance is intended exclusively for domestic, non-commercial use.
This appliance is intended to be used in household and similar applications such as:
- staff kitchen areas in shops, offices and other working environments;
- farm houses;
- by clients in hotels, motels, and other residential type environments;
- bed and breakfast type environments.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
This appliance shall not be used by children aged less than 8 years. This appliance
can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Keep the appliance and its cord out of reach of children aged less than 8 years.
Cleaning and user maintenance shall not be made by children unless older than 8 and
supervised.
a
User manual
d
Gebruiksaanwijzing
b
Manuel de l'utilisateur
c
Benutzerhandbuch
h
Manual del usuario
j
Manuale dell'utente
i
Manual do utilizador
n
Instrukcja obsługi
e
Bruksanvisning
l
Uživatelská příručka
1
Uživatelská příručka
2
9
3
10
8
1
11
6
5
4
7
A
WWW.TRISTAR.EU
Tristar Europe B.V. | Swaardvenstraat 65
5048 AV Tilburg | The Netherlands
Deep fryer FR-9327
Slide up until
locked in position
INSTALLING HANDLES*
*Only install handles without oil in container and when device is turned o.
