Wireless Scanner
- MS842P -
User’s Manual
Version 1.6


Preface
About This Manual
This manual explains how to install, operate and maintain the MS842P wireless scanner.
No part of this publication may be reproduced or used in any form, or by any electrical or
mechanical means, such as photocopying, recording, or information storage and retrieval
systems, without permission in writing from the manufacturer. The material in this manual is
subject to change without notice.
© Copyright 2013 Unitech Electronics Co., Ltd. All rights reserved.
Unitech global website address: http://www.ute.com
Bluetooth is a registered trademark of Bluetooth SIG.
i

European Conformity Statement
Declaration of Conformity with regards to the R&TTE 1999/5/EC and EMC 89/336/ EEC
directives.
RoHS Statement
This device conforms to RoHS (Reduction Of
Hazardous Substances) European Union
regulations that set maximum concentration limits
on hazardous materials used in electrical and
electronic equipment.
Taiwan NCC Warning Statement
交通部電信總局低功率電波輻射性電機管理辦法 (930322)
根據交通部低功率管理辦法規定:
第十二條 經型式認證合格之低功率射頻電機,非經許可,公司、商號或使用者均不得擅自變更
頻率、加大功率或變更原設計之特性及功能。
第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時,應
立即停用,並改善至無干擾時方得繼續使用。前項合法通信,指依電信法規定作業之
無線電通信。
低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
減少電磁波影響,請妥適使用
Laser Information
The Unitech MS842P is certified in the U.S. to conform to the requirements of DHHS/CDRH
21CFR Subchapter J and to the requirements of IEC 825-1. Class II and Class 2 products are
not considered to be hazardous. The MS842P contains internally a Visible Laser Diode (VLD)
whose emissions do not exceed the maximum limits as set forth in the above regulations. The
scanner is designed so that there is no human access to harmful laser light during normal
operation, user maintenance or prescribed service operations.
The laser safety warning label required by the DHHS/IEC for the MS842P’s optional laser
scanner module is located on the memory compartment cover, on the back of the unit.
CAUTION! Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous laser light. Use of optical instruments with
the scanner, including binoculars, microscopes, and magnifying glasses, with will
increase eye damage. This does not include eyeglasses worn by the user.
iii

iv
Battery Notices
The MS842P is equipped with a Lithium-Ion battery. The battery will discharge after an
extended period of no use.
When the battery is discharged, recharge the unit for some 4.5 hours in order to fully charge
the battery.
Note: To guarantee optimal performance, it is advised that rechargeable batteries be replaced
every year, or when 500 charge/discharge cycles are achieved. It is normal that the
battery balloons or expands beyond one year or the maximum of 500 cycles. Although it
does not cause harm, it cannot be used again and must be disposed of according to the
location's safe battery disposal procedures.
If the performance, of a Lithium-Ion battery, decrease is greater than 20% in, the battery
is at the end of its life cycle. Do not continue to use, and ensure the battery is disposed
of properly.
The length of time that a battery lasts depends on the battery type and how the device is used.
Conserve the battery life by doing the following:
Avoid frequent full discharges because this places additional strain on the battery. Several
partial discharges with frequent recharges are better than a full discharge. Recharging a
partially charged lithium-Ion battery does not cause harm because there is no memory
effect.
Keep the lithium-Ion battery cool. Avoid a hot car. For prolonged storage, keep the battery
at a 40% charge level.
Do not leave the lithium-Ion battery discharged and unused for an extended period
because the battery will wear out and the longevity of the battery will be at least half of the
one with frequent recharges.
Battery charge notice
It is important to consider the environment temperature when the Lithium-Ion battery pack is
charged. Charging is most efficient at normal room temperature or in a slightly cooler
environment. It is essential that batteries are charged within the stated range of 0°C to 40°C.
Charging batteries outside of the specified range could damage the batteries and shorten their
charging life cycle.
CAUTION! Do not charge batteries at a temperature lower than 0°C. This will increase the
internal resistance to cause heat and make the batteries unstable and unsafe.
Please use a battery temperature detecting device for a charger to ensure a safe
charging temperature range.
Storage and safety notice
Although the charged Lithium-Ion battery may be left unused for several months, their capacity
may be depleted due to build up of internal resistance. If this happens they will require
recharging prior to use. Lithium-Ion battery may be stored at temperatures between -30°C to
70°C, however they may deplete more rapidly at higher temperatures. It is recommended to
store batteries at room temperature.

v
Warranty
The following items covered under the Unitech Limited Warranty are free from defects during
normal use:
MS842P – 1-year limited warranty.
Lithium-Ion battery – 6-month limited warranty.
Warranty becomes void if equipment is modified, improperly installed or used, damaged by
accident or neglect, or if any parts are improperly installed or replaced by the user.
Use only the adapter supplied. Using the wrong adapter may damage the unit and will void the
warranty.

Table of Contents
PREFACE
ABOUT THIS MANUAL.............................................................................................................. I
Regulatory Compliance Statements.................................................................................... ii
FCC Warning Statement ......................................................................................................ii
FCC Label Statement...........................................................................................................ii
RF Radiation Exposure Statement .......................................................................................ii
Canadian Compliance Statement.........................................................................................ii
European Conformity Statement .........................................................................................iii
RoHS Statement .................................................................................................................iii
Taiwan NCC Warning Statement.........................................................................................iii
Laser Information ................................................................................................................ iii
Battery Notices .................................................................................................................... iv
Battery charge notice ..........................................................................................................iv
Storage and safety notice....................................................................................................iv
Warranty ................................................................................................................................ v
CHAPTER 1
OVERVIEW................................................................................................................................ 1
Introducing the MS842P....................................................................................................... 1
Report Version .................................................................................................................... 2
Package Contents................................................................................................................. 2
CHAPTER 2
BATTERY CHARGING AND CONNECTION............................................................................. 5
Connecting a USB Interface, Dongle Mode ........................................................................ 5
Dongle Mode (with SCM support) ....................................................................................... 5
Connecting a USB Interface, Cradle Mode ......................................................................... 6
Cradle Mode (without SCM support) ................................................................................... 6
Memory Buffer Setting ......................................................................................................... 8
Batch Mode......................................................................................................................... 8
Inventory Mode ................................................................................................................... 9
vi
Buffer Mode Disable............................................................................................................ 9

viii
CHAPTER 4
BAR CODE SYMBOLOGIES .................................................................................................. 35
Introduction......................................................................................................................... 35
Symbol Code Identifiers..................................................................................................... 36
UPC-A .................................................................................................................................. 37
Enable/Disable UPC-A...................................................................................................... 37
Transmit UPC-A Check Digit ............................................................................................. 37
UPC-A Preamble............................................................................................................... 37
UPC-E .................................................................................................................................. 38
Enable/Disable UPC-E...................................................................................................... 38
Transmit UPC-E Check Digit ............................................................................................. 38
UPC-E Preamble............................................................................................................... 38
Code 39................................................................................................................................ 39
Enable/Disable Code 39 ................................................................................................... 39
Code 39 Check Digit Verification....................................................................................... 39
Transmit Code 39 Check Digit........................................................................................... 39
Code 39 Full ASCII Conversion ........................................................................................ 40
Set Lengths for Code 39 ................................................................................................... 40
Code 93................................................................................................................................ 41
Enable/Disable Code 93 ................................................................................................... 41
Set Lengths for Code 93 ................................................................................................... 41
Code 11................................................................................................................................ 42
Enable/Disable Code 11.................................................................................................... 42
Set Lengths for Code 11 ................................................................................................... 42
UPC-E1 ................................................................................................................................ 43
Enable/Disable UPC-E1.................................................................................................... 43
Transmit UPC-E1 Check Digit ........................................................................................... 44
UPC-E1 Preamble............................................................................................................. 44
EAN-13/JAN-13.................................................................................................................... 44
Enable/Disable EAN-13/JAN-13........................................................................................ 44
Bookland EAN..................................................................................................................... 45
Enable/Disable Bookland EAN.......................................................................................... 45
Bookland ISBN Format....................................................................................................... 45
Decode UPC/EAN/JAN Supplementals ............................................................................. 45

x
Inverse 1D ........................................................................................................................... 56
Postal Code Symbologies.................................................................................................. 56
US Postnet........................................................................................................................ 56
UK Postal .......................................................................................................................... 57
Japan Postal ..................................................................................................................... 57
GS1 (Globe Standard 1) DataBar...................................................................................... 57
GS1 DataBar Limited ........................................................................................................ 57
GS1 DataBar Limited Security Level................................................................................. 57
GS1 DataBar Expanded.................................................................................................... 58
Netherlands KIX Code ...................................................................................................... 58
Australia Post.................................................................................................................... 59
Composite Symbologies.................................................................................................... 59
Composite CC-C............................................................................................................... 59
Composite CC-A/B............................................................................................................ 59
Composite TLC-39 ............................................................................................................ 59
2D Symbologies.................................................................................................................. 60
PDF417............................................................................................................................. 60
MicroPDF417 .................................................................................................................... 60
Code 128 Emulation.......................................................................................................... 60
Data Matrix........................................................................................................................ 60
Data Matrix Inverse........................................................................................................... 61
Decode Mirror Images (Data Matrix Only)......................................................................... 61
Maxicode........................................................................................................................... 62
QR Code ........................................................................................................................... 62
QR Inverse........................................................................................................................ 62
MicroQR............................................................................................................................ 63
Aztec ................................................................................................................................. 63
Aztec Inverse .................................................................................................................... 63
Redundancy Level ............................................................................................................ 63
Security Level.................................................................................................................... 65
Intercharacter Gap Size .................................................................................................... 65
Macro PDF Features......................................................................................................... 66
Macro PDF Transmit / Decode Mode Symbols ................................................................. 66
Transmit Macro PDF Control Header ................................................................................ 67

xi
Escape Characters............................................................................................................ 68
Flush Macro Buffer............................................................................................................ 68
Abort Macro PDF Entry ..................................................................................................... 68
APPENDIX A
SAMPLE BAR CODES............................................................................................................ 69
2D Bar codes....................................................................................................................... 69
Data Matrix........................................................................................................................ 69
Maxicode........................................................................................................................... 69
QR Code ........................................................................................................................... 69
PDF417............................................................................................................................. 69
MicroPDF417 .................................................................................................................... 69
US Postnet........................................................................................................................ 70
UK Postal .......................................................................................................................... 70
1D Bar codes....................................................................................................................... 70
EAN-13 ............................................................................................................................. 70
EAN-8 ............................................................................................................................... 70
UPC-A 70...............................................................................................................................
UPC-E 70...............................................................................................................................
Interleave 2 of 5 ................................................................................................................ 70
Code 39 ............................................................................................................................ 71
Code 128 .......................................................................................................................... 71
EAN 128............................................................................................................................ 71
Codabar ............................................................................................................................ 71
MSI.................................................................................................................................... 71
GS1 Limited ...................................................................................................................... 71
APPENDIX B
NUMERIC BAR CODES .......................................................................................................... 73
APPENDIX C
ASCII CHARACTER SETS...................................................................................................... 75

xii
APPENDIX D
WORLDWIDE SUPPORT ........................................................................................................ 85

Chapter 1
Overview
Introducing the MS842P
MS842P not only benefits all the advantages MS842 has (2D wired scanner) but
also
allows users to move around without being restricted by wireless technology. It
offers a 10 meter operation range with its USB dongle as well as data can be stored
in a buffer mode if it is out of range of the wireless signal and will upload the data
automatically when it gets back in range. This scanner is ideal for various
applications in warehousing, retail and healthcare.
MS842P is built in Motorola’s high-speed decoder and high performance 2D engine
that can support all 1D and 2D barcodes reading. It incorporates rugged design
with an IP42 environmental sealing against moisture and dust, also sustains a 1.8M
drop to concrete. With a long life trigger of 10 million times guarantees a continuous
productivity for best reliability.
MS842P has laser aim is more easier to target barcode to read and it has two
engine options for selection DOF: SR (standard range) and HD (high density) for
varied applications.
Features
Build in high performance 2D engine & decoder
Point-and-shooting scanning. Good aiming line, easy to pick up and use
Decodes all standard 1D and 2D codes - even wrinkled, damaged or poorly
printed - quickly and accurately
Durable, compact and long life trigger design
Rugged design by IP42 and 1.8m drops
Buffer mode for out-of-range reading
Simple plug-and-play without complicated set-up instructions
10M operation range with its USB dongle
Integrated cradle and USB dongle set results in more flexible data
transmission
Applications
Personal Identification
Captive Images for Damaged Goods
Printed Circuit Board / Electronics Component Manufacturing
Warehousing and Distribution
Clinical / Healthcare Applications
Ticket and Gaming Application
1

Report Version
Scan the barcode below to report the version of firmware currently installed in the
decoder.
F/W Version Report
Package Contents
Please make sure the following contents are in the MS842 package box. If
something is missing or damaged, please contact your Unitech representative.
Scanner-and-USB dongle package (MS842P)
Wireless laser scanner Power adapter
(1010-900014G)
USB dongle
(5500-900008G)
USB cable (60cm)
(1550-900058G) User's manual CD
Scanner-and-Cradle package (MS842P)
Wireless laser scanner USB dongle
(5500-900008G)
Cradle
(5000-900008G)
Power adapter
(1010-900014G)
USB Cable (150cm)
(1550-600626G) User's manual CD
2

4

Chapter 2
Battery Charging and Connection
Connecting a USB Interface, Dongle Mode
Dongle Mode (with SCM support)
In order to establish a proper connection between your computer and a scanner
through a dongle, we suggest that you follow these step-by-step instructions:
1. Turn on your computer or laptop PC.
2. Insert a dongle into a USB port of the
computer or laptop PC.
3. Scan the MAC address on the label by
using the MS842P scanner.
4. When being successfully connected to the dongle, the scanner will beep
shortly one time with a high tone.
SPP Setting
To do the SPP setting, scan the SPP
setting bar code.
SPP
HID Setting
To make the scanner return to the HID
mode, scan the HID barcode.
HID
You can also connect the MS842P scanner optionally to another dongle by
following the steps made below.
1. Scan the Disconnection
barcode to disconnect.
Disconnection
5

4. Connect the cradle to the USB port of your computer with a USB cable for
transferring data to your computer by using the MS842P scanner.
5. Insert a USB dongle into the USB port of the cradle.
6. Scan the MAC address on the label by using the MS842P scanner.
7. When being successfully connected to the dongle, the scanner will beep shortly
one time with a high tone.
When being not used, the scanner can be also set on the cradle for battery
charging.
7

Memory Buffer Setting
The collected data can be sent back to a host computer one by one via the WPAN
connection as the scanner is set to the Batch Mode, or can be stored in the flash
memory of the scanner being set to the Inventory Mode.
By default, the Batch Mode is enabled for use when the scanner is out of range.
Upon reading a barcode successfully within range, the scanner responds with one
short beep (high tone) and its LED indicator becomes solid green and goes off
quickly. However, the host computer may not receive the data immediately if
getting out of range. With the 2MB transmit buffer, the scanner can ignore the
transmission status and keep on reading barcodes until the buffer is full.
When the Batch Mode is enabled and the scanner is out of range, the scanner will
respond with two short beeps, high-low tone, upon reading a barcode successfully.
When the memory buffer is full, the scanner will respond with one long beep (low
tone) and its LED indicator will become solid red and go off quickly. You are
advised to get back to range.
MS842 features 2 memory mode settings: Batch Mode and Inventory Mode
Note: The 2MB of memory buffer in the scanner can hold as approximately many
as 1290555 scans based on EAN-13 barcodes. Data will be cleared out once
the scanner is not powered!
Batch Mode
Batch Mode is the default setting. In the Batch Mode, once you scan a barcode by
using a scanner wirelessly connecting to the cradle (Cradle Mode) or a host PC
(Cradle-less Mode) in a specified range, the scanner sends out the data. When the
scanner is out of range of the cradle or the host and keeps trying to re-connect, the
scanner will keep the data in its memory buffer until the buffer is full; when the
scanner is again in range of scanner will sent out the the cradle or the host, the
data that it has in the memory buffer. When the buffer is full and the scanner is out
of range, the scanner will respond with one long beep (low tone) and its LED
indicator will become solid red and go off quickly. You are advised to get back to
range.
Batch Mode
If you do not output the barcode data, the barcode data is always kept in the
memory buffer. When being outputted, the 1D data is erased from the memory
buffer. However, when being outputted, the 2D data is still kept in the memory
buffer, and thus if you want to erase the 2D data from the memory buffer, scan the
following barcodes in the order.
Enter Batch Buffer Erase Erase
When the scanner is out of batch mode, the data will be temporarily stored in the
RAM, which has 4K storage capacities; however, in the inventory mode, the data
will be stored in the flash, which has 2MB storage capacities.
8

Note:
If you tend to operate off line for long time, please set the scanner to the inventory
mode. Otherwise, the data stored in the RAM will be lost when the scanner runs out
of battery power.
Inventory Mode
Inventory Mode is the mode I n which the scanner keeps the scanned data in its
memory buffer but not send out the data on the host automatically; you should scan
Read Buffer barcode to order the scanner sent out the memorized data to the Host.
To set the scanner to the Inventory Mode, scan the following barcodes in the order:
Inventory Mode
Bear in mind the fact that the scanner operating in the inventory mode does not
send out the scanned data automatically but keeps the data in its memory buffer. If
you want to make the scanner output the data it scanned before, please scan the
Read Buffer barcode as shown below:
Read Buffer
Note: After scanning the Read Buffer barcode, the data is sent from the memory
buffer.
If you do not output the barcode data, the barcode data is always kept in the
memory buffer. When being outputted, the 1D data is erased from the memory
buffer. However, when being outputted, the 2D data is still kept in the memory
buffer, and thus if you want to erase the 2D data from the memory buffer, scan the
following barcodes in the order.
Enter Inventory Buffer Erase Erase
If you are out of range of the cradle or the host PC when reading out the scanned
data, the scanner will keep the data in its memory buffer until the buffer is full; only
when the scanner is within the specified range of the cradle or the host, and you
scan the Read Buffer barcode the data will be sent.
When the buffer is disabled and the scanner is out of range, the scanner will
respond with one long beep (low tone) and its LED indicator will become solid red
and go off quickly. You are advised to get back to range.
Buffer Mode Disable
To disable the buffer mode, scan the bar code below.
Buffer Mode Disable
9

Emulate Keypad
Enable this to send all characters as ASCII sequences over the numeric keypad.
For example ASCII A transmits as “ALT make” 0 6 5 “ALT Break”.
Dongle HID Keyboard Numeric Keypad
Enable
Disable
Emulate Keypad with Leading Zero
Enable this to send character sequences sent over the numeric keypad as ISO
characters which have a leading zero. For example ASCII A transmits as “ALT
MAKE” 0 0 6 5 “ALT BREAK”.
USB Country Keyboard Types - Country Codes
Scan the bar code corresponding to the keyboard type. This setting applies only to
the USB HID Keyboard Emulation device.
Note: When changing USB country keyboard types the decoder automatically resets and issues the
standard startup beep sequences.
12

Swiss
Swedish
Spanish
Italian
German
French
Danish
Japanese (OADG109)
Partial ALT
ALT Mode
Simulated Caps Lock
Enable this to invert upper and lower case characters on the bar code as if the
on the keyboard. This inversion occurs regardless of
.
Caps Lock state is enabled
the keyboard’s Caps Lock state. Note that this only applies to alpha characters
14

USB CAPS Lock Override
This option applies only to the HID Keyboard Emulation device. Enable this to
preserve the case of the data regardless of the state of the Caps Lock key. This
setting is always enabled for the Japanese, Windows (ASCII) keyboard type and
cannot be disabled.
Note: If both Simulated Caps Lock and Caps Lock Override are enabled, Caps Lock Override
takes precedence.
Dongle HID Keyboard Case
Auto Trace
To Lower
To Upper
Function Key Mapping
ASCII values under 32 are normally sent as a control-key sequences. Enable this
parameter to send the keys in bold in place of the standard key mapping. Table
entries that do not have a bold entry remain the same whether or not you enable
this parameter.
15

16
ASCII Character Set for USB
USB Prefix/Suffix Values
Prefix/ Suffix Value Full ASCII Code 39
Encode Char.acter Keystroke
1000 %U CTRL 2
1001 $A CTRL A
1002 $B CTRL B
1003 $C CTRL C
1004 $D CTRL D
1005 $E CTRL E
1006 $F CTRL F
1007 $G CTRL G
1008 $H CTRL H/BACKSPACE 1
1009 $I CTRL I/HORIZONTAL TAB1
1010 $J CTRL J
1011 $K CTRL K
1012 $L CTRL L
1013 $M CTRL M/ENTER1
1014 $N CTRL N
1015 $O CTRL O
1016 $P CTRL P
1017 $Q CTRL Q
1018 $R CTRL R
1019 $S CTRL S
1020 $T CTRL T
1021 $U CTRL U
1022 $V CTRL V
1023 $W CTRL W
1024 $X CTRL X
1025 $Y CTRL Y
1026 $Z CTRL Z
1027 %A CTRL [/ESC1
1028 %B CTRL \
1029 %C CTRL ]
1030 %D CTRL 6
1031 %E CTRL -
1032 Space Space

17
Prefix/ Suffix Value Full ASCII Code 39
Encode Char.acter Keystroke
1033 /A !
1034 /B “
1035 /C #
1036 /D $
1037 /E %
1038 /F &
1039 /G ‘
1040 /H (
1041 /I )
1042 /J *
1043 /K +
1044 /L ,
1045 - -
1046 . .
1047 /O /
1048 0 0
1049 1 1
1050 2 2
1051 3 3
1052 4 4
1053 5 5
1054 6 6
1055 7 7
1056 8 8
1057 9 9
1058 /Z :
1059 %F ;
1060 %G <
1061 %H =
1062 %I >
1063 %J ?
1064 %V @
1065 A A
1066 B B
1067 C C

18
Prefix/ Suffix Value Full ASCII Code 39
Encode Char.acter Keystroke
1068 D D
1069 E E
1070 F F
1071 G G
1072 H H
1073 I I
1074 J J
1075 K K
1076 L L
1077 M M
1078 N N
1079 O O
1080 P P
1081 Q Q
1082 R R
1083 S S
1084 T T
1085 U U
1086 V V
1087 W W
1088 X X
1089 Y Y
1090 Z Z
1091 %K [
1092 %L \
1093 %M ]
1094 %N ^
1095 %O _
1096 %W `
1097 +A a
1098 +B b
1099 +C c
1100 +D d
1101 +E e
1102 +F f

19
Prefix/ Suffix Value Full ASCII Code 39
Encode Char.acter Keystroke
1103 +G g
1104 +H h
1105 +I i
1106 +J j
1107 +K k
1108 +L l
1109 +M m
1110 +N n
1111 +O o
1112 +P p
1113 +Q q
1114 +R r
1115 +S s
1116 +T t
1117 +U u
1118 +V v
1119 +W w
1120 +X x
1121 +Y y
1122 +Z z
1123 %P {
1124 %Q |
1125 %R }
1126 %S ~
1The keystroke in bold transmits only if you enable Function Key
Mapping. Otherwise, the unbolded keystroke transmits.

20
USB ALT Key Character Set
ALT Keys Keystroke
2064 ALT 2
2065 ALT A
2066 ALT B
2067 ALT C
2068 ALT D
2069 ALT E
2070 ALT F
2071 ALT G
2072 ALT H
2073 ALT I
2074 ALT J
2075 ALT K
2076 ALT L
2077 ALT M
2078 ALT N
2079 ALT O
2080 ALT P
2081 ALT Q
2082 ALT R
2083 ALT S
2084 ALT T
2085 ALT U
2086 ALT V
2087 ALT W
2088 ALT X
2089 ALT Y
2090 ALT Z

21
USB GUI Key Character Set
GUI Key Keystroke
3000 Right Control Key
3048 GUI 0
3049 GUI 1
3050 GUI 2
3051 GUI 3
3052 GUI 4
3053 GUI 5
3054 GUI 6
3055 GUI 7
3056 GUI 8
3057 GUI 9
3065 GUI A
3066 GUI B
3067 GUI C
3068 GUI D
3069 GUI E
3070 GUI F
3071 GUI G
3072 GUI H
3073 GUI I
3074 GUI J
3075 GUI K
3076 GUI L
3077 GUI M
3078 GUI N
3079 GUI O
3080 GUI P
3081 GUI Q
3082 GUI R
3083 GUI S
3084 GUI T
3085 GUI U
3086 GUI V
3087 GUI W
3088 GUI X

22
GUI Key Keystroke
3089 GUI Y
3090 GUI Z
Note: GUI Shift Keys - The Apple™ iMac
keyboard has an apple key on either
side of the space bar.
Windows-based systems have a GUI key to the
left of the left ALT key, and to the right of the
right ALT key.
USB F Key Character Set
F Keys Keystroke
5001 F1
5002 F2
5003 F3
5004 F4
5005 F5
5006 F6
5007 F7
5008 F8
5009 F9
5010 F10
5011 F11
5012 F12
5013 F13
5014 F14
5015 F15
5016 F16
5017 F17
5018 F18
5019 F19
5020 F20
5021 F21
5022 F22
5023 F23
5024 F24

23
USB Numeric Keypad Character Set
Numeric Keypad Keystroke
6042 *
6043 +
6044 undefined
6045 -
6046 .
6047 /
6048 0
6049 1
6050 2
6051 3
6052 4
6053 5
6054 6
6055 7
6056 8
6057 9
6058 Enter
6059 Num Lock
USB Extended Keypad Character Set
Extended Keypad Keystroke
7001 Break
7002 Delete
7003 PgUp
7004 End
7005 Pg Dn
7006 Pause
7007 Scroll Lock
7008 Backspace
7009 Tab
7010 Print Screen
7011 Insert
7012 Home
7013 Enter
7014 Escape

24
Extended Keypad Keystroke
7015 Up Arrow
7016 Down Arrow
7017 Left Arrow
7018 Right Arrow
Dongle HID Keyboard Character Delay
1 ms
5 ms
10 ms
20 ms
50 ms
100 ms
6-unused
7-unused
Dongle HID Keyboard Block Delay
10 ms
50 ms
100 ms
500 ms
1 s
3 s

Chapter 3
Output Data Editing
Transmit Code ID Character
A Code ID character identifies the code type of a scanned bar code. This is useful
when decoding more than one code type. In addition to any single character prefix
already selected, the Code ID character is inserted between the prefix and the
decoded symbol.
Select no Code ID character, a Symbol Code ID character, or an AIM Code ID
character.
Note: If you enable Symbol Code ID Character or AIM Code ID Character, and enable Transmit “No
Read” Messag, the digital scanner appends the code ID for Code 39 to the NR message.
Prefix/Suffix Values
You can append a prefix and/or one or two suffixes to scan data for use in data
editing. To set a value for a prefix or suffix, scan a four-digit number (i.e., four bar
codes) that corresponds to that value.
When using host commands to set the prefix or suffix, set the key category
parameter to 1, then set the 3-digit decimal value.
To correct an error or change a selection, scan Cancel.
Note: To use Prefix/Suffix values, first set the Scan Data Transmission Format as shown below.
25
Copyright 2013 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

Scan Data Transmission Format
To change the scan data format, scan one of the following eight bar codes
corresponding to the desired format.
Note: If using this parameter, do not use ADF rules to set the prefix/suffix.
To set values for the prefix and/or suffix, see Prefix/Suffix Values.
26
Copyright 2013 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

FN1 Substitution Values
The wedge and USB HID keyboard hosts support a FN1 Substitution feature.
Enabling this substitutes any FN1 character (0x1b) in an EAN128 bar code with a
value. This value defaults to 7013 (Enter key).
When using host commands to set the FN1 substitution value, set the key category
parameter to 1, and then set the 3-digit keystroke value. See the ASCII character
set table for the current host interface for the desired value.
To select a FN1 substitution value via bar code menus:
1. Scan the bar code below.
2. Locate the keystroke desired for FN1 substitution in the ASCII character set
table in the appropriate host interface chapter. Enter the 4-digit ASCII value by
scanning each digit.
To correct an error or change the selection, scan Cancel.
27
Copyright 2013 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

28
Copyright 2013 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

Chapter 4
Bar code Setup Menu
User Preferences
Set Default Parameter
You can reset the digital scanner to factory defaults. Scan the bar code below to
reset the digital scanner to its default settings.
Set Defaults (Factory Default)
Scan this bar code to reset all default parameters.
(Factory Defaults)
Parameter Scanning
To disable decoding of parameter bar codes, scan the Scanning bar code below.
Note that the parameter bar code can still be decoded. To enable decoding of
parameter bar codes, either scan Enable Parameter Scanning or Set All Defaults.
Beeper Volume
To select a beeper volume, scan the Low Volume, Medium Volume, or High Volume
bar code.
29
Copyright 2013 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

Auto Aim
Low Power Mode
This parameter determines whether or not the digital scanner enters low power
mode after a decode attempt. If disabled, power remains on after each decode
attempt.
Time Delay to Low Power Mode
This parameter sets the time the decoder remains active after decoding. After a
scan session, the decoder waits this amount of time before entering Low Power
Mode.
Note: This parameter only applies when Power Mode is set to Low.
31
Copyright 2013 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

Video Mode
In this mode the decoder behaves as a video camera as long as the trigger is
active. Upon trigger release, the decoder returns to Decode Mode. Scan the Video
Mode bar code to temporarily enter Video Capture Mode.
Image File Format Selector
Select an image format appropriate for the system (BMP, TIFF, or JPEG). The
decoder stores captured images in the selected format.
32
Copyright 2013 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

Video View Finder
Select Enable Video View Finder to project the video view finder while in Image
Mode, or Disable Video View Finder to turn the video view finder off.
Mirrored Image
Enable this to scan images in reverse, or mirrored, as if seen through a mirror. This
mode is useful in applications requiring scanning through a mirror and using
symbologies that do not decode in reverse.
Enabling this mode when using snapshot, video, or video viewfinder mode
transmits images as mirrored images.
Beep After Good Decode
Scan a bar code below to select whether or not the decoder issues a beep signal
after a good decode. If selecting Do Not Beep After Good Decode, beeper signals
still occur during parameter menu scanning and to indicate error conditions.
33
Copyright 2013 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
Produkt Specifikationer
Mærke: | Unitech |
Kategori: | Stregkodelæser |
Model: | MS842P |
Kode for international beskyttelse (IP): | IP54 |
Type: | Håndholdt stregkodelæser |
Bredde: | 89 mm |
Dybde: | 74 mm |
Højde: | 176 mm |
Vægt: | 200 g |
Produktfarve: | Black, Grey, Yellow |
Opladningstid: | 4 t |
Batterikapacitet: | 1620 mAh |
Batteriteknologi: | Lithium-Ion (Li-Ion) |
Opbevaringstemperatur (T-T): | -30 - 70 °C |
Relativ luftfugtighed ved drift (H-H): | 5 - 95 % |
Driftstemperatur (T-T): | 0 - 50 °C |
Scanner type: | 1D/2D |
Forbindelsesteknologi: | Kabel & trådløs |
Certificering: | CE, FCC, BSMI, VCCI |
Strømkilde type: | DC |
USB version: | 2.0 |
Basisdimensioner: | 73 x 95 x 200 mm |
Indgangsspænding: | 5 V |
Trådløs rækkevidde: | 10 m |
Sensortype: | CMOS |
Standard grænseflader: | Bluetooth, USB |
Batteriets levetid: | 10 t |
Strømforbrug: | 400 mA |
Driftsfrekvens: | 2400 MHz |
Tilt læsningsvinkel: | -60 - 60 ° |
Pitch læsningsvinkel: | -60 - 60 ° |
Understøtter lineær (1D) stregkoder: | Codabar, Code 11, Code 128, Code 25 (IR 2 of 5), Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), JAN, MSI, Telepen, Trioptic, U.P.C. |
Understøtter matrix (2D) stregkoder: | Aztec Code, Composite Codes, Data Matrix, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39 |
Arbejdsafstand: | 791 mm |
