Side 1/3
INSTRUCTION MANUAL
LED FLOOD LIGHT
TECHNICAL DATA
MODEL VT-44035 VT-44055 VT-44204
SKU 23599 23600 23601
23602, 23603
POWER 30W 50W 200W
LUMENS 2505Lm 17540Lm4270Lm
COLOUR
TEMPERATURE 3000K 6500K
4000K
4000K
6500K
INPUT VOLTAGE AC: 220-240V, 50Hz
DF >0.9
CRI 70
LIFE SPAN 25,000 Hours
`
ON/OFF CYCLE 15,000 Times
BEAM ANGLE 115°
OPERATION
TEMPERATURE -20°C to +40°C
BODY TYPE Aluminium
MAX. MOUNT-
ING HEIGHT <5M
NET WEIGHT 0.35Kg 0.48Kg 2.5Kg
PROJECTED
AREA (mm2)25168.5 31011.5 140673.75
DIMENSION 164.5x34x-
153mm
183.5x34x-
169mm
402.5x349x5x-
44mm
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
toaccess the manual in
multiple languages.
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the
best. Please read these instructions carefully before starting the installation
and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have pur-
chased the product. They are trained and ready to serve you at the best. The
warranty is valid for 5 years from the date of purchase. The warranty does
not apply to damage caused by incorrect installation or abnormal wear and
tear. The company gives no warranty against damage to any surface due to
incorrect removal and installation of the product. The products are suitable
for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would
void the warranty. This product is warranted for manufacturing defects only.
*This product contains a light source of energy ef-
ficiency class<F>,where <F> shall be replaced by
the energy class of the contained light source.
This marking indicates that this product
should not be disposed of with other
household wastes.
Caution, risk of electric shock.
Replaceable (LED Only) light
source by a professional
INSTALLATION DIAGRAM
INSTALLATION INSTRUCTION
• DO NOT USE IN AREAS WITH LIMITED VENTILATION OR OUTSIDE THE RATED AMBIENT TEM-
PERATURE RANGE. *CON- NECT WITH WATERPROOF CABLE HOUSE ONLY. *ENSURE ELEC-
TRICITY IS SWITCH OFF BEFORE INSTALLATION.
• Please do not mount to a surface that is prone to vibrations .*
Remove the screw and the bracket aerward. (Figure 1)Before drilling, mark the hole position for
fixing the bracket onto the wall (Screw not supplied). (Figure 2)
• Screw the retaining bracket to the wall with a suitable quantity of screws. (Figure 4)
• Mount the bracket back to the fixture. Adjust the floodlight according to the desired position.
Tighten the screw. (Figure 5) Connect your main cable (HO5RN-F3G1.0mm2 Recommended)
with the input lead of our product through the waterproof junction box. Note, the line (-) of the
lead. (Need to use the junction box of IP65 or above, ensure to tighten the waterproof screw)
Switch on the power to make sure if the product is working.
WARNING
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. If the external flexible cable or cord of this luminaire is damaged, it shall be
exclusively replaced by the manufacturer or his service agent or a similar
qualified person in order to avoid a hazard.
4. Replace any cracked protective shield.
5. Terminal block not included.
6. Proper grounding should be ensured throughout the installation.
7. Minimum distance from lighted objects 1m.
8. Limitation of use indoors and outdoor.
NOTE: To reduce the risk of strangulation the flexible wiring connected to this luminaire shall be eectively
fixed to the wall if the wiring is within arm’s reach.
