INSTRUCTION MANUAL
LED WATERPROOF FITTING WITH MICROWAVE SENSOR
STAINLESS
CLIPS
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
MODEL
SKU
LUMENS
WATTS
DIMENSION
BEAM ANGLE
INPUT VOLTAGE
VT-120137S
24013, 24016
4320 lm
36W
1200x78x72mm
120°
AC:200~240V, 50/60Hz
SWITCHING CAPACITY
STAND-BY POWER
DETECTION AREA
HOLD TIME
Max,100W
≤0.5W
50%/100%
5s/1min/3min/10min
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. The light source of this luminaire is not replaceable; when the light source reaches its end of life the
whole luminaire shall be replaced.
4. If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by
the manufacturer or his service agent or a similar qualified person in order to avoid a hazard.
5. Must be connected to waterproof terminal box.
6. For indoor use and outdoor use.
WARNING
INTRODUCTION & WARRRANTY
SENSOR TECHNICAL DATA
TECHNICAL DATA
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installation
and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased
the product. They are trained and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty does not apply
to damage caused by incorrect installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to incorrect
removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the
warranty. This product is warranted for manufacturing defects only.
LIFE SPAN
ON/OFF CYCLE
CRI
DF
P
sb
MATERIAL
MAX. CONNECTABLE UNITS
20,000 Hours
10,000 Times
≥80
≥0.9
≤0.5W
PC+PC
10
DAYLIGHT THRESHOLD
MICROWAVE FREQUENCY
MICROWAVE POWER
MOUNTING HEIGHT
30Lux/Disable
5.8GHz±75MHz
<0.3mW
DETECTION RANGE
OPERATING TEMPERATURE
MOTION DETECTION
-25°C TO +60°C
0.5~1.5M/S
(ceiling mounted)
(ceiling mounted)
2.5-4m/8.2-13.12
ø4-10m/13.12-32.8
Non-replaceable
control gear
Non-replaceable
light source
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
VT-150149S
24015, 24017
5760 lm
48W
1500x78x72mm
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
