VT-61003

104771, 104781

104791

78551, 78561

78571

MODEL SKU WATTS

LUMENS

BODY

TYPE

TOTAL

CURRENT

INPUT

VOLTAGE

CRI

LIFE

SPAN

ON/OFF

CYCLE

SHAPE

DIMENSION

(LxWxH)

BEAM

ANGLE

RATING

Sphere

360°

Sphere

360°

Sphere

360°

Sphere

360°

Sphere

360°

PLASTIC

IP20

>80

IP20

AC:220-240

50/60Hz

AC:220-240

50/60Hz

AC:220-240

50/60Hz

AC:220-240

50/60Hz

AC:220-240

50/60Hz

26mA 20000H >15000

20000H >15000

φ90.5x28mm

90.2x90.2x28.2mm

120.5x120.5x28.4mm

170.8x170.8x28.4mm

220.4x220.4x28.8mm

295x295x28.6mm

φ294x29.1mm

φ120.5x28.4mm

φ170.8x28.4mm

φ220.8x28.9mm

ROUND

SQUARE

ROUND

36mA

71mA

103mA

160mA

PLASTIC

660LM

330LM

1200LM

1850LM

1980LM

2500LM

2640LM

12W

18W

24W

VT-61006

VT-61012

VT-61018

VT-61024

ROUND PANEL

φ80

(7 7-82mm)

φ110

(107-112mm)

φ155

(150-155mm)

φ205

(200-205mm)

φ280

(275-280mm)

6W 12W 18W 24W

INSTALLATION

HOLE SIZE

1.Cut a hole using an appropriate tool according to the cut-out size.

4. Check whether the lamp is ﬂat and electriﬁed.

5. Clean the lamp with clean cloth.

6. Switch on the power and test the light.

3. Hold the two clips back against the panel light and push it

into the hole. Allow the springs to pull the light up to the ceiling.

2.Switch OFF the power & Connect

AC: 220-240V voltage with terminals.`

RECESSED PANEL INSTALLATION DIAGRAM

LED BACKLIT RECESSED PANEL

TECHNICAL DATA

INTRODUCTION & WARRANTY

WARNING

ATTENTION!

USAGE GUIDELINES/MAINTENANCE

MOUNTING

INSTRUCTION MANUAL

'This product contains a light source of energy eciency class <F/E>', where <F/E> shall be replaced by

the energy eciency class of the contained light source.

Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instruc-

tions carefully before starting the installation and keep this manual handy for future reference. If you have any

another query, please contact our dealer or local vendor from whom you have purchased the product. They

are trained and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The

warranty does not apply to damage caused by incorrect installation or abnormal wear and tear. The company

gives no warranty against damage to any surface due to incorrect removal and installation of the product. The

products are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the

warranty. This product is warranted for manufacturing defects only.

Do not look directly at LED light beam. Product can only be supplied by rated voltage or voltage within

the range provided. It's forbidden to use the product with damaged protective cover. Product must not be

used in unfavorable conditions, e.g. dust, water, moisture, vibrations, explosive air atmosphere, fumes, or

chemical fumes, etc. In the area of strong electromagnetic interference, the functioning of the product

may be disrupted.

Any maintenance work must be performed when the power supply is cut o and the product has cooled

down. Clean only with so and dry cloths. Do not use chemical detergents. Do not cover the product.

Ensure free air access. Product may heat up to a higher temperature.

Read the manual before mounting. Mounting should be performed by a qualiﬁed electrician. Exercise

caution. Product has a protective contact /terminal. Failure to connect the protective lead may lead to

electric shock. Mounting diagram: see pictures. Check for proper mechanical fastening and connection to

electrical power prior to ﬁrst use.

• Please make sure to turn o the power before starting the installation.

• Installation must be performed by a certiﬁed person.

• For Indoor use only

• The light source contained in this luminaire shall only be replaced by the

manufacturer or his service agent or a similar qualiﬁed person.

• If the external ﬂexible cable or cord of this luminaire is damaged, it shall be

exclusively replaced by the manufacturer or his service agent or a similar

qualiﬁed person in order to avoid a hazard.

• Method of attachment of the cable or cord such that any replacement can

only be made by the manufacturer, his service agent or similar qualifed

person.

This marking indicates that this

product should not be disposed

of with other household wastes.

Replaceable (LED only)

light source by a professional

Caution, risk of electric shock.

MULTI-LANGUAGE

MANUAL QR CODE

Please scan the QR code

to access the manual in

multiple languages.

SPHERE

STAYS BRIGHT

360°

104801,104811

104821

78581,78591

78601

104831,104841

104851

78611, 78621

78631

104861, 104871

104881

78641, 78651

78661

104891,104901

104911

78671, 78681

78691

SQUARE PANEL

80*80

(75-80mm)

110*110

(105-110mm)

155*155

(150-155mm)

205*205

(200-205mm)

280*280

(275-280mm)

6W 12W 18W 24W

INSTALLATION

HOLE SIZE

1.Cut a hole using an appropriate tool

according to the cut-out size.

4. Check whether the lamp is ﬂat and electriﬁed.

5. Clean the lamp with clean cloth.

6. Switch on the power and test the light.

3. Hold the two clips back against the panel light and push it

into the hole. Allow the springs to pull the light up to the ceiling.

2.Switch OFF the power & Connect

AC: 220-240V voltage with terminals.`

4.Press the buckle outwards,

remove the aluminum substrate

pressing strip from the bayonet,

and remove the pressing strip.

This step is only required for

24W panel light, other items are

not required.

5.Press the buckle outwards,

remove the aluminum substrate

from the buckle, and remove

the light source board.

6.Take out two-cord cable (wire diameter

18-22AWG) and insert it into the plug-in

terminal. Connect the external power

supply for testing.

1.Power o, tap the central area of the

diusion plate with a pointed tool, and

take out the cracked diusion plate

2.Remove the power wire from the

plug terminal

3.If there is no hot melt column in the

lamp body or the hot melt column is

not hot melt,this step will be adjusted

without treatment.If the hot-melt column

has been fused to ﬁx the aluminum

substrate,cut the hot-melt part of the

hot-melt point with diagonal pliers.

DISASSEMBLY DIAGRAM

(For Market surveillance team only)

IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU

FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC

EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
