Side 1/3
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code to
access the manual in multiple languages.
INSTRUCTION MANUAL
MICROWAVE SENSOR CEILING MOUNT
TECHNICAL DATA
MODEL VT-81001
SKU 23163
INPUT POWER AC: 220-240V, 50/60 Hz
RATED LOAD Max. 2000W
1000W +LED
TIME DELAY Min. 10sec ±3sec
Max. 12min ±1min
DETECTION
RANGE 360°
DETECTION
DISTANCE 1-8m(Radius), Adjustable
DETECTION
MOVING SPEED 0.6-1.5m/s
WORKING
TEMPERATURE -20°C to +40°C
POWER
CONSUMPTION Approx, 0.9W
AMBIENT LIGHT <3-2000 LUX (Adjustable)
INSTALLATION
HEIGHT 2-6m
POWER
CONSUMPTION Approx 0.9w
DETECTION
MOTION SPEED 0.6-1.5 m/s
HF SYSTEM 5.8 Ghz CW Radar,
ISM Band
IP RATING IP20
DIMENSION Ø115x24.3 mm
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product.
V-TAC LED
RANGE (UPTO 1000W)
COMPATIBLE WITH
This marking indicates that this prod-
uct should not be disposed of with
other household wastes.
Caution, risk of electric shock.
FUNCTION
WARNING
1. Can identify day and night: It can work in the daytime and at night when it is adjusted on the
“sun” position (max). It can work in the ambient light less than 3LUX when it is adjusted on the
“3” position (min). As for the adjustment pattern, please refer to the testing pattern.
2. SENS adjustable: It can be adjusted according to using location. The detection distance of low
sensitivity could be only 2m and high sensitivity could be 16m which fits for large room.
3. Time-Delay is added continually: When it receives the second induction signals within the first
induction, it will restart to time from the moment.
4. Time–Delay is adjustable. It can be set according to the consumer’s desire. The minimum time
is 10sec±3sec. The maximum is 12min±1min.
NOTE: the high-frequency output of the HF sensor is
<0.2Mw- that is just one 5000th of the transmission
power of a mobile phone or the output of a microwave
oven, the baby can’t touch it.
The wires come in and
out from the bottom
The wires come in and
out from the side
INSTALLATION
CONNECTION-WIRE DIAGRAM
• Please move the upper cover with anti-clockwise
whirl as per the diagram on the right.
• Connect the power and the load according to
the connection-wire diagram.
• Fix the bottom on the selected position with the
inflated screw.
• Install back the upper cover on the sensor, then
you could switch on the power and test it.
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. For Indoor use only
