Side 1/8

VT-8310 VT-8340

23783, 23784

23785

23786

23787

8048, 8049, 23788

LUMENS

BODY TYPE

LIFE SPAN

ON/OFF CYCLE

CRI

BEAM ANGLE

INPUT VOLTAGE

OPERATION TEMPERATURE

OPERATING HUMIDITY

PROTECTION RATING

NET WEIGHT

DIMENSIONS

10 W

20 W

D1 (mm)

D2 (mm)

L1 (mm)

1000/1200 Lm

Plastic

>0.7>0.7 >0.9 >0.9

10W

40W

4300/4800 Lm

25,000 Hours

>15,000 Times

>80

120°

IP20

155±5g

VT-8320

2400 Lm

20W

225±5g

24±1 75±1

300±2

566±2

76±1

24±1

40 W

1166±2

76±1

24±1

50 W

1466±2

76±1

24±1

365±5g

VT-8350

8050

8054

50W

6000 Lm

450±5g

INSTRUCTION MANUAL

TECHNICAL DATA

INTRODUCTION & WARRANTY

MODEL

SKU

WATTS

LED PRISMATIC FITTING

Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully

before starting the installation and keep this manual handy for future reference. If you have any another query, please contact

our dealer or local vendor from whom you have purchased the product. They are trained and ready to serve you at the best.

The warranty is valid for 3 years from the date of purchase. The warranty does not apply to damage caused by incorrect

installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to incorrect

removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24

Hours a day would void the warranty. This product is warranted for manufacturing defects only.

AC:220~240V, 50Hz

-20°C to +40°C

10%~95%

QUICK

CONNECTOR

SUPER BRIGHT

LM/WATT EFFICIENCY

120

IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU

FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.

V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B

WARNING

INSTALLATION INSTRUCTIONS

INSTALLATION DIAGRAM

1. Please make sure to turn o the power before starting the installation.

2. Installation must be performed by a qualiﬁed electrician.

3. The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole

luminaire shall be replaced.

4. For Indoor use only

5. Before installation, you must carefully check the integrity of the product and accessories

6. When installed, products and ﬂammable materials to ensure that at least 0.2m distance, lighting cannot be

installed in the zenith or heat wall, pay attention to low voltage and high voltage electrical wiring separately.

7. To ensure that the power cord has enough length, do not kink cables. Output cables should be laid separately

and at a distance from other cables.

1. Choose the right position, drill two hole and insert the screw (make sure the

distance between the holes is no less than50mm, Less than bracket length)

2. Shrapnel point it at the hole and then install the screws

3. Press the lamp body ﬁrmly into the mounting buckle to ﬁx the lamp body,

Slide the lamp body along the mounting buckle to the desired position as

needed.

4. Connect the wiring, use insulating tape, and waterproof tape for insulation

and waterprooﬁng, turn the power ON and test.

This marking indicates that this

product should not be disposed

of with other household wastes.

Caution, risk of electric shock.
