Side 1/15

Content

F.C.C STATEMENT

IMPORTANT SAFEGUARDS

1.Introduction .............................................................................................. 1

1.1 Features ........................................................................................... 1

1.2 Checking List .................................................................................... 1

2. Installation ............................................................................................... 2

2.1 Install the pedestal ........................................................................... 2

2.2 Connect your monitor to computer ................................................... 2

3. Front Panel overview ............................................................................. 3

4. Access Features ..................................................................................... 4

4.1 tSwitching he Monitor On/Off ........................................................... 4

4.2 Power Indicator ................................................................................ 4

4.3 Menu Features ................................................................................. 4

4.4 OSD Functional Control Description ................................................ 5

4.5 Preset Modes Timing Chart .............................................................. 7

4.6 Plug and Play ................................................................................... 8

5.Technical Information ............................................................................. 9

5.1 D SUB Signal connector pin assignment- ......................................... 9

5.2 Visual Inspection ............................................................................ 10

5.3 Trouble shooting ............................................................................. 11

www.V7-world.com

F.C.C STATEMENT

FEDERAL COMMUNICATIONS COMMISSION

This equipment has been tested and found to comply with the limits of a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

1. Reorient/Relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

4. Consult the dealer of an experienced radio/TV technician for help.

CAUTION: Changes or modifications not expressly approved by the

manufacturer responsible for compliance could void the authority to user's

operate the equipment.

NOTE: The use of a non-shielded interface cable with this equipment is prohibited

Produkt Specifikationer

Mærke:	V7
Kategori:	Skærm
Model:	LED236W3
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Produktfarve:	Sort
Pakkevægt:	6000 g
Pakkedybde:	88 mm
Pakkebredde:	636 mm
Pakkehøjde:	466 mm
Skærm diagonal:	23.5 "
Skærmopløsning:	1920 x 1080 pixel
Berøringsskærm:	Ingen
HD-type:	Fuld HD
Naturligt aspektforhold:	16:9
Responstid:	5 ms
Synsvinkel, horisontal:	170 °
Synsvinkel, vertikal:	160 °
3D:	Ingen
Indbyggede højttaler(e):	Ingen
Antal HDMI-porte:	1
HDCP:	Ingen
Skærmvisning (OSD):	Ja
VESA montering:	Ja
Panel montering grænseflade:	75 x 75 mm
Strømforbrug (typisk):	32 W
Bredde (uden stativ):	559 mm
Dybde (uden stativ):	33 mm
Højde (uden stativ):	333 mm
Vægt (uden stativ):	4220 g
Bredde (med stativ):	559 mm
Dybde (med stativ):	171 mm
Højde (med stativ):	384 mm
Vægt (med stativ):	4700 g
Skærm:	LED
Understøttede grafikopløsninger:	1920 x 1080 (HD 1080)
Certificering:	FCC/CE/CTUVus
Pakkens dimensioner (BxDxH):	636 x 88 x 466 mm
Indbygget kamera:	Ingen
Slot til kabellås:	Ingen
Billedformat:	16:9
Vis antal farver:	16,78 millioner farver
Skærmens lysstyrke (typisk):	250 cd/m²
Kontrastforhold (typisk):	1000:1
Pixel pitch:	0.2715 x 0.2715 mm
Synlig størrelse, horisontal:	521 mm
Synlig størrelse, vertikal:	293 mm
Antal VGA-porte (D-sub):	1
TV-tuner, integreret:	Ingen
Digital vertikal frekvens:	56 - 75 Hz
Digital horisontal frekvens:	30 - 70 kHz
Tynd klient installeret:	Ingen
