Side 1/14

Operator’s Manual 12/3/20 AWR-G MANUAL.DOCX

Vestil Manufacturing Corp.

A company dedicated to solving loading dock and material handling

problems since 1955.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or- Toll Free: (800) 348-0868

Fax: (260) 665-1339

http://www.vestil.com/ email: info@vestil.com

AWR and AWR-G-Series Aluminum Walk Ramp

Instruction Manual

Models AWR-28-6A, AWR-G-28-6A-HR

Model AWG-G-18-ESR-12A

Receiving instructions:

After delivery, remove the packaging from the product. Inspect the product to determine whether it sustained

damage during transport. If damage is discovered, record a complete description of it on the bill of lading and file a claim

with the carrier immediately! If the product is undamaged, discard the packaging.

NOTE:

The end user is solely responsible for confirming that product design, use, and maintenance comply with laws,

regulations, codes, and mandatory standards applied where the product is used.

Replacement Parts and Technical Assistance:

If you have questions that are not addressed in these instructions, or to order replacement parts, labels, and

accessories, call (260) 665-7586 and ask for the Service and Parts Department. You can also reach Service and Parts

online at http://www.vestilmfg.com/parts_info.htm.

Electronic Copies of Instruction Manuals:

Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-manuals.php.

Operator’s Manual 12/3/20 AWR-G MANUAL.DOCX

Table of Contents

Signal words … … … … … … … … … … … … 2

Hazards … … … … … … … … … … … … 2

Model number and capacity … … … … … … … … … … 4

Specifications … … … … … … … … … … … … 4

Major components … … … … … … … … … … … 7

Installation instructions … … … … … … … … … … 7

Record of satisfactory condition … … … … … … … … … 9

Operation instructions … … … … … … … … … … … 9

Inspection and maintenance … … … … … … … … … … 11

Owner Responsibility … … … … … … … … … … … 12

Labeling diagram … … … … … … … … … … … 13

Limited warranty … … … … … … … … … … … 14

SIGNAL WORDS

This manual uses SIGNAL WORDS to direct the reader’s attention to important safety-related messages. These

messages describe uses of the product that could result in personal injury or property damage. Each signal word

corresponds to a specific hazard level. The following are definitions of signal words that might appear in this manual.

Identifies a hazardous situation which, if not avoided, WILL result in DEATH or SERIOUS INJURY.

Use of this signal word is limited to the most extreme situations.

Identifies a hazardous situation which, if not avoided, COULD result in DEATH or SERIOUS INJURY.

Indicates a hazardous situation which, if not avoided, COULD result in MINOR or MODERATE injury.

Identifies practices likely to result in product/property damage, such as operation that might

damage the product.

HAZARDS

Vestil Manufacturing strives to identify all foreseeable hazards associated with the use of its products. However,

material handling is dangerous and no manual can address every risk. The end user is ultimately responsible for

exercising sound judgment at all times in the use of this product.

Improper or careless operation of this device might result in serious personal injuries.

• Read and understand this entire manual before installing, assembling, using, or servicing this walk ramp. Keep

this manual in a location known to persons who use the walk ramp. Read the manual whenever necessary to

refresh your understanding of proper use, inspection, and maintenance procedures. Failure to read and

understand this owner’s manual before using or servicing the walk ramp constitutes a misuse of the product.

• When used in occupational settings, i.e. by employees, use must conform to occupational health and safety

(OSH) rules applied in the location where the ramp is used. Before putting the ramp into service, it is the user’s

responsibility to contact local OSH and building department authorities to determine how laws, regulations,

codes, etc. affect your use of the ramp.

• The Aluminum Walk Ramp presents pinch point and falling hazards to the user and bystanders. ALWAYS follow
