Rev. 9/26/2016 BAR-R & BAR-A, manual
Copyright 2016 Vestil Manufacturing Corp. Page 1 of 10
BAR Series Warehouse Racks
Assembly, Installation, and Maintenance Manual
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product. Then inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, immediately record a complete
description of the damage on the bill of lading. If the product is undamaged, discard the packaging.
NOTES:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where
the product is used is exclusively the responsibility of the owner/end-user.
2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either: a)
the instructions in this manual; or b) information provided on labels affixed to the product.
Vestil is not responsible for any consequential damages sustained while assembling, installing, using or maintaining
this product.
VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail: sales@vestil.com
Table of Contents
Signal words…………………………………………………………………………...………………………………………...2
Safe use recommendations…………………………………………………………………..………………………….……. 2
FIG. 1A: BAR-R-84-D exploded parts diagram and bill of materials………..………………………………………....... 3
FIG. 1B: BAR-R-84-D dimensions and capacity……………………………………………………………………………. 3
FIG. 2A: BAR-A-84-D exploded parts diagram and bill of materials……………………………………………………… 4
FIG. 2B: BAR-A-84 S dimensions and capacity……………………………………………………………………………. 4
FIG. 3A: BAR-R-84-S exploded parts diagram and bill of materials……………………………………………………… 5
FIG. 3B: BAR-R-84-S dimensions and capacity……………………………………………………………………………. 5
FIG. 4A: BAR-A-84-S exploded parts diagram and bill of materials……………………………………………………… 6
FIG. 4B: BAR-A-84-S dimensions and capacity……………………………………………………………………………. 6
Assembly………………………………………………………………………………………………………………………… 7-8
Installation………………………………………………………………………………………………………………………. 8
Maintenance…………………………………………………………………………………………………………………….. 9
Labeling diagram …………..
………………………………………………………….….................................................... 9
Limited warranty……………………………………………………………………………………………………………….. 10
BAR-A-84-S
(Add-on unit)
BAR-A-84-D
(Add-on unit)
