Rev. 9/26/2016 BAR-R & BAR-A, manual

BAR Series Warehouse Racks

Assembly, Installation, and Maintenance Manual

Receiving instructions:

After delivery, IMMEDIATELY remove the packaging from the product. Then inspect the product closely to determine

whether it sustained damage during transport. If damage is discovered, immediately record a complete

description of the damage on the bill of lading. If the product is undamaged, discard the packaging.

NOTES:

1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where

the product is used is exclusively the responsibility of the owner/end-user.

2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either: a)

the instructions in this manual; or b) information provided on labels affixed to the product.

Vestil is not responsible for any consequential damages sustained while assembling, installing, using or maintaining

this product.

VESTIL MANUFACTURING CORP.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868

Fax: (260) 665-1339

www.vestilmfg.com e-mail: sales@vestil.com

Table of Contents

Signal words…………………………………………………………………………...………………………………………...2

Safe use recommendations…………………………………………………………………..………………………….……. 2

FIG. 1A: BAR-R-84-D exploded parts diagram and bill of materials………..………………………………………....... 3

FIG. 1B: BAR-R-84-D dimensions and capacity……………………………………………………………………………. 3

FIG. 2A: BAR-A-84-D exploded parts diagram and bill of materials……………………………………………………… 4

FIG. 2B: BAR-A-84 S dimensions and capacity……………………………………………………………………………. 4

FIG. 3A: BAR-R-84-S exploded parts diagram and bill of materials……………………………………………………… 5

FIG. 3B: BAR-R-84-S dimensions and capacity……………………………………………………………………………. 5

FIG. 4A: BAR-A-84-S exploded parts diagram and bill of materials……………………………………………………… 6

FIG. 4B: BAR-A-84-S dimensions and capacity……………………………………………………………………………. 6

Assembly………………………………………………………………………………………………………………………… 7-8

Installation………………………………………………………………………………………………………………………. 8

Maintenance…………………………………………………………………………………………………………………….. 9

Labeling diagram …………..

………………………………………………………….….................................................... 9

Limited warranty……………………………………………………………………………………………………………….. 10

BAR

BAR-A-84-S

(Add-on unit)

BAR-A-84-D

(Add-on unit)

Rev. 9/26/2016 BAR-R & BAR-A, manual

Signal words:

This manual uses “Signal words” to indicate the likelihood of personal injuries, as well as the probable

seriousness of those injuries, if the product is misused in the ways described. call attention to uses of the product

likely cause property damage. The signal words used appear below along with the meaning of each word:

Identifies a hazardous situation which, if not avoided, WILL result in DEATH or

SERIOUS INJURY. Use of this signal word is limited to the most extreme

situations.

Identifies a hazardous situation which, if not avoided, COULD result in DEATH or

SERIOUS INJURY.

Indicates a hazardous situation which, if not avoided, COULD result in MINOR or

MODERATE injury.

Identifies practices likely to result in product/property damage, such as operation that

might damage the product.

Safe use recommendations:

Vestil strives to identify all of the hazards associated with the use of its products. However, material handling is

dangerous and no manual can address every risk. Ultimately, the most effective means for avoiding injury is for the end-

user to exercising sound judgment during the assembly, installation, and use of this rack.

If this product is used improperly or carelessly, personal injury might result.

 Failure to read and understand the entire manual before assembling, installing, loading or servicing the

product constitutes misuse. Read the manual to refresh your understanding of proper use and maintenance

procedures as necessary.

 DO NOT exceed the maximum rated load.

 Inspect the rack periodically (AT LEAST once per month). DO NOT continue to use the rack if the inspection

reveals structural damage. Examples of structural damage include: 1) warped, deformed, or damaged dividers or

base frame; 2) cracked welds; 3) enlargement of bolt holes; 4) corrosion, severe wear, or other condition that

affects the ability of the product to support weight; 6) damaged, deformed or cracked channels (for machined nuts).

Immediately tag out the rack, unload it completely, and replace each part that fails to pass an inspection. DO NOT

use the product until it is fully restored to normal condition. ONLY use manufacturer-approved replacement parts.

 DO NOT use the product if any unusual noise or movement is observed. If a malfunction occurs, remove the unit

from service and notify your supervisor or maintenance personnel about the issue.

 All loads stored on the rack must fit within the dimensions of the rack. DO NOT store any load that hangs over

the rack.

 DO NOT use the rack UNLESS it is securely anchored to the ground.

 ALWAYS evenly distribute and center loads applied to the rack.

 ONLY install this rack on even, level surfaces.

 DO NOT remove or obscure any label. All product labels must be readable and undamaged.

 DO NOT climb on the rack.

 DO NOT modify the rack in any way. Unauthorized modifications automatically void the limited warranty (see p.

6) and might make the rack unsafe to use.

Proper maintenance is essential for this product to function properly and to last as long as possible.

o Always use this product in accordance with the instructions in this manual and consistent with any training

relevant to the storage of materials on racks.

o Keep the rack clean & dry.
