Rev. 4/30/2014 BOL, manual
Copyright 2014 Vestil Manufacturing Corp.
BOL SERIES BOLLARDS
INSTRUCTION MANUAL
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the packaging
and maintains the orientation of the product in the packaging; then inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered during the inspection, immediately
record a complete description of the damage on the bill of lading. If the product is undamaged, discard the
packaging.
NOTES:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where the
product is used is exclusively the responsibility of the owner/end-user.
2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either:
a) Instructions in this manual; or b) Information provided on labels affixed to the product. Neither is Vestil
responsible for any consequential damages sustained as a result of failing to exercise sound judgment while
assembling, installing, using or maintaining this product.
Table of Contents
Hazard identification: explanation of signal words………………………………………………………………….. 2
Safety Guidelines…………………………………………………………………………..…………………………… 2
Product specifications………………………………………………………………………………………………….. 2
Installation instructions…………………………………………………………………………………………………. 3
Inspections & maintenance……………………………………………………………………………………………. 3
Limited warranty…………………………………………………………………………………………………………. 4
VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail: sales@vestil.com
BOL, manual
Copyright 2014 Vestil Manufacturing Co. Page 2 of 4
Hazard Identification: Explanation of SIGNAL WORDS
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the probable
seriousness of those injuries, if the product is misused in the ways described. Other signal words call attention to
uses of the product likely cause property damage.
The signal words used appear below along with the meaning of each word:
Identifies a hazardous situation which, if not avoided, WILL
result in DEATH or SERIOUS INJURY. Use of this signal word is
limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD
result in DEATH or SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD
result in MINOR or MODERATE injury.
Identifies practices likely to result in product/property damage, such
as operation that might damage the product.
Each person who assembles, installs, uses, or maintains this product should read the entire manual in
advance and fully understand the directions. If after reading the manual you do not understand an instruction, ask
your supervisor or employer for clarification, because failure to adhere to the directions in this manual might
result in serious personal injury.
Safety Guidelines
Vestil diligently strives to identify foreseeable hazards associated with the use of its products. However, no
manual can address every conceivable risk. The end-user ultimately is responsible for exercising sound judgment
at all times.
If this product is used improperly or carelessly, the operator and/or bystanders might sustain
serious personal injuries. ALWAYS use the product properly:
Failure to read and understand the entire manual before assembling, installing, using or servicing the product
constitutes misuse. Read the manual to refresh your understanding of proper use and maintenance procedures.
DO NOT modify the bollard. Modifications automatically void the Limited Warranty and might make the bollard
unsafe to use.
Product Specifications
Specifications for each of the three BOL-R series bollards appear in the table below:
Model Height Outside Diameter Base Plate Dimensions Net Weight
BOL-24-2 24in. (61cm) 1
3
/
4
in. (4.4cm) 4in. x 4in. (10.2cm x 10.2cm) 12 lb. (5.5kg)
BOL-36-2 36in. (91cm) 1
3
/
4
in. (4.4cm) 4in. x 4in. (10.2cm x 10.2cm) 15 lb. (6.8kg)
BOL-42-2 42in. (107cm) 1
3
/
4
in. (4.4cm) 4in. x 4in. (10.2cm x 10.2cm) 16 lb. (7.3kg)
BOL-48-2 48in. (122cm) 1
3
/
4
in. (4.4cm) 4in. x 4in. (10.2cm x 10.2cm) 22 lb. (10kg)
BOL-24-4.5 24in. (61cm) 4
1
/
2
in. (11.4cm) 8in. x 8in. (20.3cm x 20.3cm) 34 lb. (15.5kg)
BOL-36-4.5 36in. (91cm) 4
1
/
2
in. (11.4cm) 8in. x 8in. (20.3cm x 20.3cm) 45 lb. (20.5kg)
BOL-42-4.5 42in. (107cm) 4
1
/
2
in. (11.4cm) 8in. x 8in. (20.3cm x 20.3cm) 50 lb. (22.7kg)
BOL-48-4.5 48in. (122cm) 4
1
/
2
in. (11.4cm) 8in. x 8in. (20.3cm x 20.3cm) 56 lb. (25.5kg)
BOL-24-5.5 24in. (61cm) 5
1
/
2
in. (14cm) 8in. x 8in. (20.3cm x 20.3cm) 42 lb. (19.1kg)
BOL-36-5.5 36in. (91cm) 5
1
/
2
in. (14cm) 8in. x 8in. (20.3cm x 20.3cm) 57 lb. (26kg)
BOL-42-5.5 42in. (107cm) 5
1
/
2
in. (14cm) 8in. x 8in. (20.3cm x 20.3cm) 69 lb. (31.4kg)
BOL-48-5.5 48in. (122cm) 5
1
/
2
in. (14cm) 8in. x 8in. (20.3cm x 20.3cm) 78 lb. (35.5kg)
BOL-36-6.5 36in. (91cm) 6
1
/
2
in. (16
1
/
2
cm) 8in. x 8in. (20.3cm x 20.3cm) 69 lb. (31.4kg)
BOL-42-6.5 42in. (107cm) 6
1
/
2
in. (16
1
/
2
cm) 8in. x 8in. (20.3cm x 20.3cm) 83 lb. (37.7kg)
BOL-48-6.5 48in. (122cm) 6
1
/
2
in. (16
1
/
2
cm) 8in. x 8in. (20.3cm x 20.3cm) 94 lb. (42.7kg)
BOL-36-8.5 36in. (91cm) 8
1
/
2
in. (21.6cm) 10in. x 10in. (25.4cm x 20.3cm) 84 lb. (38.2kg)
BOL-42-8.5 42in. (107cm) 8
1
/
2
in. (21.6cm) 10in. x 10in. (25.4cm x 20.3cm) 101 lb. (45.9kg)
BOL-48-8.5 48in. (122cm) 8
1
/
2
in. (21.6cm) 10in. x 10in. (25.4cm x 20.3cm) 115 lb. (52.3kg)
