Side 1/10
0813 Rev. 5/20/2014 BTT, manual.doc
Copyright 2014 Vestil Manufacturing Co. Page 1 of 10
BTT-SERIES BENCHTOP TILTERS
I
NSTRUCTION MANUAL
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the packaging and
maintains the orientation of the product in the packaging; then inspect the product closely to determine whether it
sustained damage during transport. If damage is discovered during the inspection, immediately record a
complete description of the damage on the bill of lading. If the product is undamaged, discard the packaging.
NOTES:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where the product
is used is exclusively the responsibility of the owner/end-user.
2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either: a)
the instructions in this manual; or b) information provided on labels affixed to the product. Neither is VESTIL
responsible for any consequential damages sustained as a result of failing to exercise sound judgment while
assembling, installing, using or maintaining this product.
Table of Contents
Hazard identification: explanation of signal words……………………………………………………………………. 2
Safety Guidelines…………………………………………………………………………..…………………….………. 2
Exploded parts diagrams and bills of materials……………………………………………………………………….. 3 – 7
Product specifications……………………………………………………………………………………………………. 8
Installation instructions…………………………………………………………………………………………………… 8
Use instructions…………………………………………………………………………………………………………… 8 – 9
Inspections & Maintenance Recommendations………………………………………………………………………. 9
Label placement diagram …………..
…………………………………………………………................................. 9
Limited warranty………………………………………………………………………………………………………….. 10
VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail: sales@vestil.com
0813 Rev. 5/20/2014 BTT, manual.doc
Copyright 2014 Vestil Manufacturing Co. Page 2 of 10
HAZARD IDENTIFICATION: explanation of signal words
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the probable
seriousness of those injuries, if the product is misused in the ways described. Other signal words call attention to
uses of the product likely cause property damage.
The signal words used appear below along with the meaning of each word:
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme
situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that
might damage the product.
Safety Guidelines
VESTIL strives to identify foreseeable hazards associated with the use of its products. However, material handling
is inherently dangerous and no manual can address every conceivable risk. The end-user ultimately is responsible
for exercising sound judgment at all times.
If this product is used improperly or carelessly, the operator and/or bystanders might sustain serious
personal injuries or even be killed. Each operator should read and understand the entire manual before installing,
using or servicing the product for the first time. Failure to do so is a misuse of the product. If you do not
understand an instruction, ask your supervisor for clarification because failure to adhere to the directions in
this manual might result in serious personal injury. To reduce the likelihood of injury:
Read the manual to refresh your understanding of proper use and maintenance procedures.
DO NOT attempt to resolve any problem with the product unless you are both authorized to do so and certain that it
will be safe to use afterwards.
DO NOT modify the product in any way UNLESS you first obtain written approval from VESTIL. Unauthorized
modifications automatically void the Limited Warranty and might make the product unsafe to use.
Inspect the product regularly (also see “Maintenance recommendations” on p. 10) to confirm normal condition.
A. DO NOT use this product if the inspection reveals structural damage. Examples of structural damage include,
but are not limited to, the following: 1) Cracked, broken or significantly deformed load-bearing members; 2)
cracked welds; 3) corrosion, severe wear, or other condition that affects the ability of the product to support
weight or itself. Replace each part that fails to pass an inspection, and DO NOT use the product until it is fully
restored to normal condition.
B. DO NOT use the product if any unusual noise or movement is observed. If a malfunction occurs, remove the unit
from service and notify your supervisor & maintenance personnel about the issue.
DO NOT exceed the capacity of the tilter (see “Product specifications” table on p. ## and “Label placement diagram”
on p. 10).
DO NOT stand, or allow other persons to stand, reach, or crawl beneath any elevated part of the tilter.
DO NOT modify the drum carrier or any component of the lifter in any way UNLESS you first obtain written approval
from Vestil. Unauthorized modifications automatically void the Limited Warranty (p. 11) and might make the device
unsafe to use.
DO NOT use the carrier UNLESS all product labels (see “Label placement diagram” on p. 10) are readable and
undamaged.
Proper use, maintenance, and storage are essential for this product to function properly.
o Always use this product in accordance with the instructions in this manual and consistent with any training relevant
to machines, devices, etc. used in conjunction with this product.
o Keep the product clean & dry. Periodically lubricate moving parts.
