Table of Contents Rev. 5/15/2019 CARPET- 45 MANUAL

CARPET- C T 45 ARPET RUCK

NSTRUCTION MANUAL

Receiving instructions

A fter delivery, remove the packaging from the product. Inspect the product closely to determine whether it

sustained damage during transport. If damage is discovered, record a complete description of it on the bill of

lading. If the product is undamaged, discard the packaging.

Replacement Parts and Technical Service

For answers to questions not addressed in these instructions and to order replacement parts, labels, and

accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can also be

contacted online at http://www.vestilmfg.com/parts_info.htm

NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance comply with

laws, regulations, codes, and mandatory standards applied where the product is used.

Vestil Manufacturing Corp.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665 7586 - - -or Toll Free (800) 348-0868

Fax: (260) 665-1339

Web: www.vestilmfg.com e- mail: sales@vestil.com

Table of Contents

S Wignal ords……………………………………………………………………………………………………………………………….…………………………………………. 2

Specifications………………….............................................…………………………………………………………………………………………………………… 2

Hazards……………………….………………………………………………………………………………………………………...................................................... 2

Exploded View and Bill of Materials…………………………………….……………………..………………………………………………………………………….. 3

Assembly……………………………………………………………………………………………………………………………………………………………………………….. 3

Using the Carpet Truck…………………………………………………………………………………………………………………………………………………………… 4

Record of Satisfactory Condition……………………………………………………………………………………………………………………………………………. 4

Inspections & Maintenance…………………………………………………………………………………………………………………………………………………… 4

Labeling Diagram…………………………………………………………………………………………………………………………………………………………………… 4

Limited Warranty……………………………………………………………………………………………………………………………………………………………………. 5

Table of Contents Rev. 5/15/2019 CARPET- 45 MANUAL

SIGNAL WORDS

This manual classifies personal injury risks and situations that might cause property damage with signal words. Signal

words indicate the seriousness of injuries that might result if a particular act does, or does not, occur.

Identifies a hazardous situation which, if not avoided, result in DEATH or SERIOUS INJURY. WILL

Use of this signal word is limited to the most extreme situations.

Identifies a hazardous situation which, if not avoided, COULD result in DEATH or SERIOUS

INJURY.

Indicates a hazardous situation which, if not avoided, COULD result in MINOR or MODERATE

injury.

Identifies practices likely to result in product/property damage, such as operation that might

damage the product.

SPECIFICATIONS

Dimensions, net weight, and capacity figures are provided in the following diagrams and table.

Model

Net Weight

Capacity

CARPET- 45

34 lb. (15.5kg)

500 lb. (227.3kg)

CARPET- - 45 FF

44 lb. (20kg)

500 lb. (227.3kg)

HAZARDS

Vestil strives to identify all foreseeable hazards associated with the use of its products. However, no manual can address

every possible risk. The most effective means for avoiding injury is to read all of the instructions prior to putting the dumper

into service and to apply sound judgment whenever using this device.

Read and understand the entire manual before assembling, using or servicing the carpet truck.

Improper or careless use of this product could result in death or serious personal injury.

• DO NOT modify the product in any way UNLESS you first obtain written approval from Vestil. Unapproved

modifications automatically void the Limited Warranty . and might make the product unsafe to use

• DO NOT apply loads to the truck that exceed its capacity. C enter carpet rolls on the truck, i.e. above the axle.

• DO NOT stand, sit or ride on the truck, .

• Do not traverse uneven ground when the truck is loaded unless you can easily control it. Control the truck from

the uphill side while moving up or down slopes.

• Ask someone to help you if you cannot easily control the cart when it is loaded.

Proper use, maintenance, and storage are essential for this product to function properly.

o Inspect and maintain the unit as directed in Inspections & Maintenance.

o Units equipped with pneumatic tires: Check tire inflation. Air pressure should equal the recommended inflation

pressure that appears on the sidewalls of the tires.
