CART-23 & -24, ALL MODELS
Operation Instructions ……………………….……… 2-3
Routine Maintenance & Safety Checks ……………… 4
Exploded Power Unit Drawing & BOM ………......... 5-6
Electrical & Hydraulic Diagrams …………................ 7-8
Power Unit’s Operation ………………...…..………..... 9
Troubleshooting …………………………....………… 10
Safety Label Identification .............................................11
Warranty …………………………………….……..…. 12
IMPORTANT NOTES, WARNINGS AND SAFETY INSTRUCTIONS
Ensure that all employees understand and follow the following.
* Failure to read and understand this owner’s manual before using or
servicing the cart constitutes a misuse of the product. All persons who
will use or care for this product must be familiar with this material.
o The load
must be removed and the platform fully lowered before any
work is performed on the cart.
o Ensure that all safety and warning labels stay in place and are legi
ble.
o Do not use the cart if any damage or unusual noise is observed.
o Always watch the platform and the load carefully when the cart is in
operation.
o The cart is intended for use only on compacted, improved surfaces.
o Do not use brake fluid or jack oils in the hydraulic system. If oil is
needed, use an anti-wear hydraulic oil with a viscosity grade of
150 SUS at 100°F, (ISO 32 cSt @ 40°C), or Dexron transmission fluid.
o Contact the manufacturer for any needed MSDS information.
♦ Do not perform any modifications to the cart without the manufacturer’s
approval. Failure to receive authorization for changes to the equipment
could void the warranty.
♦ Maintenance and repairs are to be done only by personnel qualified to
perform the required work. Consideration will not be given for warranty
repair charges without prior written authorization by the manufacturer.
WHEN ORDERING
REPLACEMENT PARTS:
We take pride in using quality
parts on the equipment we
manufacture. We are not
responsible for equipment
problems resulting from the use
of unapproved replacement
parts.
To order replacement or
spare parts for this equipment,
contact the factory.
In any communication with
the factory please be prepared
to provide the machine’s serial
number, which is indicated on
the machine dataplate.
RECEIVING INSTRUCTIONS
Every unit is thoroughly
tested and inspected prior to
shipment. However, it is
possible that the unit could
incur damage during transit.
Inspect the unit closely when
it arrives. If you see evidence
of damage or rough handling to
either the packaging or to the
product when it is being
unloaded, immediately
make a
note of it on the Bill Of Lading!
It is important that you
remove the product’s packaging
upon its arrival to ensure that
there is no concealed damage
or to enable a timely claim with
the carrier for freight damage.
Also verify that the product
and its specifications are as
ordered.
OWNER’S
MANUAL
NOTE: Pages 5-6 are views of the modular power unit. These diagrams only apply to units manufactured before
12-01-2018. Units manufactured after 12-01-2018 receive a redes
igned modular power unit (MPU GEN2).
Diagrams and operating instructions for GEN2 power units are provided in separate manuals.
