Operator’s Manual 10/23/2023 EHLT-TL MANUAL
Table of Contents Copyright 2023 Vestil Manufacturing Co. Page 2 of 22
Signal Words … … … … … … … … … … …
Safety Instructions … … … … … … … … … …
Model Number and Capacity … … … … … … … … …
Exploded Part Views and Bills of Materials … … … … … … …
Electrical and Hydraulic Systems Diagrams … … … … … … …
Installation Instructions … … … … … … … … … …
Record of Satisfactory Condition … … … … … … … …
Operation Instructions … … … … … … … … … …
Inspection and Maintenance … … … … … … … … …
Troubleshooting Guide … … … … … … … … … …
Labeling Diagram … … … … … … … … … …
Limited Warranty … … … … … … … … … …
SIGNAL WORDS
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the probable seriousness of those
injuries, if the product is misused in the ways described. Other signal words call attention to uses of the product likely cause
property damage.
SAFETY INSTRUCTIONS
Vestil Manufacturing strives to identify all foreseeable hazards associated with the use of its products.
However, material handling is dangerous and no manual can address every risk. The end user is ultimately
responsible for exercising sound judgment at all times in the use of this product.
WARNING
Improper or careless operation of this device might result in serious personal injuries.
Read and understand this entire manual before installing, assembling, using or servicing this lift table.
Keep this manual in a location known to persons who use the lift table. Read the manual whenever
necessary to refresh your understanding of proper use, inspection, and maintenance procedures. Failure to
read and understand this owner’s manual before using or servicing the lift table constitutes a misuse of
the product.
This lift table presents pinch point and hydraulic pressure hazards to the user and bystanders. ALWAYS
follow these instructions to avoid injury.
The lift table is intended for use on a level concrete surface. DO NOT use a lift table that has not been
anchored to a level concrete surface. See installation instructions starting on pages 12 - 14.
The lift table shall be installed only by trained and qualified personnel with access to appropriate
equipment. Electrical connections shall be performed by a qualified electrician.
DO NOT load the table beyond its lift rated capacity. Handle only stable and safely arranged loads within
the maximum capacity of the lift. The lift capacity can be found on the nameplate on the hinged end of the
platform.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or SERIOUS
INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that
might damage the product.
