EPT-SERIES ELECTRIC PALLET TRUCKS

OPERATION AND MAINTENANCE MANUAL

Receiving instructions:

After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the

packaging and maintains the orientation of the product in the packaging; then inspect the product closely to

determine whether it sustained damage during transport. If damage is discovered during the inspection,

immediately

record a complete description of the damage on the bill of lading. If the product is

undamaged, discard the packaging.

NOTES

1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where

the product is used is exclusively the responsibility of the owner/end-user.

2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either:

a) Instructions in this manual; or b) Information provided on labels affixed to the product.

Neither is Vestil

responsible for any consequential damages sustained as a result of failing to exercise sound judgment

while assembling, installing, using or maintaining this product.

TABLE OF CONTENTS PAGE TABLE OF FIGURES PAGE

Safety Principles 2 Fig. 1A EPT Main Body Components 5

Product Introduction 2 Fig. 1B EPT-30 (optional) Scale Components 6

Safety Guidelines 3 Fig. 2 EPT-30 Hydraulic Cylinder Assembly 7

Removing EPT from Pallet 3 - 4 Fig. 3 EPT-30 Drive Wheel Assembly 8

Use, 1

Inspection, & Functions Tests 20 Fig. 4A EPT-30 Fork & Carriage 9

Operation 20-21 Fig. 4B EPT-30 Fork & Carriage (optional) Scale 10

Lifting & Transporting Loads 21 Fig. 5A Control Yoke & Handle Components 11-12

Batteries & Charger 21-22 Fig. 5B Control Yoke & Handle (optional) Scale 13-14

Fig. 6 Hydraulic Pump & Motor Assemblies 15

Troubleshooting

23-48 Fig. 7 EPT-45 Main Housings & Supporting Structure 16

Changing Cylinder 28-31 Fig. 8 Removable Battery Box & Components 16

Changing Throttle Assy. 32-36 Fig. 9 EPT-45 Cylinder & Fuse Panel 17

Changing Motor Assy. 37-39 Fig. 10 EPT-45 Fork & Carriage Assemblies 18

Replacing Forward/Reverse Contactor 40-42 Fig. 11 Function Controls, Gauges, & Safety Features 19

Changing Battery Charger 43-46 Maintenance & Inspections 49-50

Adding Quencharcs 47-48 Markings 51

VESTIL MANUFACTURING CORP.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868

Fax: (260) 665-1339

www.vestilmfg.com e-mail: sales@vestil.com

Rev. 0213 EPT, Manual.doc

PRODUCT INTRODUCTION

Specifications for each of the 4 models appear in the table below:

Net Wt. Fork Size Service

MODEL (lbs.)

(W x L) in inches Range (in.)

Capacity

(lbs.)

Overall Size

(W X L x H) in inches

EPT-2047-30 660 20in. X 47in. 3.2 to 7.8 3,000 28 x 65 x 49

EPT-2547-30 671 25in. x 47in. 3.2 to 7.8 3,000 28 x 65 x 49

EPT-2048-45 990 20in. x 48in. 3.4 to 8 4,500 30x 78.5 x 49

EPT-2748-45 1012 27in. x 48in. 3.4 to 8 4,500 30x 78.5 x 49

Vestil Manufacturing Corp. created this manual to acquaint owners and users of our electric pallet trucks

with safe operation and maintenance procedures. Employers are responsible for instructing employees to

use the product properly. Employees and any other persons, who might foreseeably use, repair, or

perform maintenance on the EPT must read and understand every instruction BEFORE using the device.

Cart operators should have access to the manual at all times and should review the directions before each

use. Contact Vestil for answers to any question you have after reading the entire manual.

Although Vestil diligently strives to identify foreseeable hazardous situations, this manual cannot address

every conceivable danger. The end-user is ultimately responsible for exercising sound judgment at all times.

SAFETY PRINCIPLES

We offer four types of electric pallet truck (EPT): two 3,000 pound (~1364kg) capacity models, the EPT-2047-

30 and 2547-30, and two 4,500 pound (~2045kg) capacity models, the EPT-2048-45 and 2748-45. Each unit

conforms to the generalized specifications disclosed in this manual and fulfills our demanding standards for

quality, safety and durability.

Vestil Manufacturing Corp. recognizes the critical importance of workplace safety. Each person who might

participate in operation or maintenance of the product must read this manual. Read the entire manual and fully

understand the directions BEFORE using or performing maintenance on the cart. If you do not

understand an instruction, contact Vestil for clarification. Failure to adhere to the directions in this

manual might lead to serious personal injury or even death.

Vestil is not liable for any injury or property damage that occurs as a consequence of failing to apply the safe

operation and maintenance procedures explained in this manual or that appear on labels affixed to the product.

Furthermore, failure to exercise good judgment and common sense may result in property damage, serious

personal injury, or death, and also are not the responsibility of Vestil.

This manual applies the hazard identification methods suggested for instruction manuals by the American

National Standards Institute (ANSI). In accordance with ANSI guidelines for hazard identification language, this

manual classifies personal injury risks and situations that could lead to property damage with SIGNAL WORDS.

These signal words announce an associated safety message. The reader must understand that the signal word

chosen indicates the seriousness of that hazard according to the following convention:

Identifies a hazardous situation which, if not avoided, WILL result in DEATH or SERIOUS

INJURY. Use of this signal word is limited to the most extreme situations.

Identifies a hazardous situation which, if not avoided, COULD result in DEATH or

SERIOUS INJURY.

Indicates a hazardous situation which, if not avoided, COULD result in MINOR or

MODERATE injury.

Identifies practices not related to personal injury, such as operation that could damage the cart.

No safety alert symbol (equilateral triangle enclosing an exclamation point) accompanies this

signal word.

Thank you for purchasing an electric pallet truck (“EPT,” “pallet truck,” “truck,” or

“unit”) offered by Vestil Manufacturing Corporation (“Vestil”). Our EPT’s are durable,

high-quality products that combine safety features and low-maintenance mechanisms.

Despite the product’s relatively simple mechanics, all personnel must familiarize

themselves with the safe operation instructions provided in this manual.
