EXCNV-R-24-24 Telescoping Roller Conveyor Assembly Instructions

1.

Orient

conveyor

sections

with

rollers down. Loosen four (4)

circled screws on both sides.

1

2

3

4

5

6

7

8

2

.

Use

screws

from step 1 to

fa

sten leg brackets to

conveyor

.

3

.

Slide the cross bar onto

side

branches of

legs

.

Cross

bar

Leg

4

.

Insert

legs into l

e

g

brackets

(circled)

.

5

.

Fast

en each

leg

to

bottom bracket

with

M10x50 bolt & M10 nut.

6

.

Fasten

cross bar to

e

ach leg

with

M10x16

bolt

.

Threaded hole for knob

(step 7)

7

.

Wind

knob

in

to

threaded hole

of each leg.

8

.

Install

a caster

(

stem)

into

bottom of each leg.

Insert

caster

stem

into

leg

9

10

11

9

.

Parts

of

Stopper Assembly: 2 rods

with bolts; 2 stopper brackets

10

.

Turn

conveyor upright &

a

ttach

stopper

assembly to end of conveyor.

Remove bolts from

ends of rods; then

align rods with holes

in stopper brackets

and reinstall bolts.

Remove bolt & washers on both sides

of rod. Insert rod through slots in

stopper bracket. Reinstall bolts and

washers. Tighten bolts.

Bolt and

washers

Slot

Stopper bracket

Rod

Leg

brackets

11

.

Press (black) plastic caps into

leg bracket openings.

The capacit

y of this conveyor is

200 lb.

/ft.

(296

kg/m)

. Do not

exceed the capacity. Serious personal injury or death might result.

Do not shock-load the conveyor, i.e. drop loads onto it. Shock loading could damage the conveyor and make it unsafe to use.

WARNING

!

Maintenance: Keep the product clean and dry. Lubricate rollers if they become noisy or do not easily rotate.
