Table of Contents Rev. 9/26/2023 H-Hoppers MANUAL

H-SERIES HOPPERS

Receiving Instructions

After delivery, remove the packaging from the product. Inspect the product closely to

determine whether it sustained damage during transport. If damage is discovered, record a

complete description of it on the bill of lading. If the product is undamaged, discard the

packaging.

NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance

comply with laws, regulations, codes, and mandatory standards applied where the product is

used.

Technical Service & Replacement Parts

For answers to questions not addressed in these instructions and to order replacement parts,

labels, and accessories, call our Technical Service and Parts Department at (260) 665-7586. The

department can also be contacted online at https://www.vestil.com/page-parts-request.php.

Electronic Copies of Instruction Manuals

Additional copies of this manual may be downloaded from https://www.vestil.com/page-

manuals.php.

Table of Contents

Page

Table of Figures

Page

Specifications……………….…...… 2

Replacement Release Handle with Cable Kit………….

Signal Words….………..……….…..

Exploded view & bill of materials: H-25 series hoppers..

Safety Instructions….…....………...

Exploded view & bill of materials: H-33 series hoppers..

National Standards…………......…

Exploded view & bill of materials: H-50 series hoppers..

Loading the Chute…..….….……..

Exploded view & bill of materials: H-75 series hoppers..

Using the Hopper…………...……..

Exploded view & bill of materials: H-100 series hoppers

Stacking Hoppers……...……….....

Exploded view & bill of materials: H-150 series hoppers

Record of Satisfactory Condition

Exploded view & bill of materials: H-200-HD………….....

Inspections & Maintenance…….. =

Labeling Diagram………………….

Limited Warranty…………………..

Vestil Manufacturing Company

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868

Fax: (260) 665-1339

www.vestil.com info@vestil.com

Table of Contents Rev. 9/26/2023 H-Hoppers MANUAL

NOTE: If your model is not included on the webpage or you cannot access the document, contact the

Technical Service Dept. Contact information is provided on the front page of this manual.

REPLACEMENT RELEASE HANDLE WITH CABLE KIT (37-154-044)

SPECIFICATIONS

Documents that provide specifications for H-series hoppers are available online to anyone who visits Vestil’s

website. Specifications include dimensions, net weight, and capacity information. Navigate to

https://www.vestil.com/product.php?FID=445. Scroll to the Product Specifications Table portion of the page.

Find the entry for the hopper you purchased and click the button in the “PDF” column that looks like a pencil

inside a blue-bordered box. A PDF file will open. This file is the specifications document. Print a copy of the

document and keep it with your copy of this manual.

The following is an exemplar specifications document for model H-33-LD.

Item

Part no.

Description

Qty.

37-025-002

HANDLE, CHUTE RELEASE

37-145-001

SPECIALTY HARDWARE CABLE

43383

SWAGE SLEEVE Ø1/8" X 5/8" LONG

43403

1/4" WIRE CLAMP

Produkt Specifikationer

Mærke:	Vestil
Kategori:	Ikke kategoriseret
Model:	H-100-LD
