SAFETY PRECAUTIONS

Read owner's manual completely before operating unit!

• Never exceed the maximum loading capacity of 880

pounds.

• Stand clear of load while loading and unloading.

• Load must be evenly distributed on deck to insure

stability.

• Use caution in moving a loaded unit; avoid obstructions

and floor defects.

• Always apply wheel brakes when unit is not in motion.

• Never go under deck if there is weight on unit.

• Do not continue to pump on the foot lever if the deck is

not raising.

• Remove weight before working on unit.

• Do not use brake fluid or jack oils. Use AW-32 hydraulic

oil or equivalent.

• Use only replacement parts supplied or approved by the

manufacturer.

• Consult factory before performing any modification to the

original equipment.

• Make sure all operator safety labels are in place (p.11).

RECEIVING INSTRUCTIONS

Every unit is thoroughly tested and inspected prior

to shipment. However, it is possible that the unit may incur

damage during transit. If damage is noticed when unloading,

make a note of it on the BILL OF LADING. Remove all

packing and strapping material, then inspect the unit again

for damage. IF DAMAGE IS EVIDENT, FILE A CLAIM

WITH THE CARRIER IMMEDIATELY!

WARRANTY

This product is warranted for 90 DAYS from date of

purchase to be free of manufacturing defects in material and

workmanship. The manufacturer's obligation hereunder is

limited to repairing such products during the warranty period,

provided the product is sent prepaid back to the factory.

This warranty does not cover normal wear of parts

or damage resulting from any of the following: negligent use

or misuse of the product, use or application contrary to

installation instructions, or disassembly, repair or alteration

by any person prior to authorization from a factory represen-

tative.

HEFTI-LIFT • MODEL HYD-5 & HYD-10

OWNER'S

MANUAL

Revised 1009 33-126-101

A company dedicated to solving ergonomic and material

handling problems since 1955.

HEFTI-LIFT

MODEL HYD 5 & HYD-10

Ergonomic Solutions

Contents

Safety Precautions .......................................... 1

Receiving Instructions ..................................... 1

Warranty .......................................................... 1

Parts List for HYD-5 & HYD-10 ..................... 2-3

Troubleshooting Guide for HYD-5 & HYD-10... 4

Warning Label Identification ............................. 5

PARTS LIST

HEFTI-LIFT • HYD-5 & HYD-10

PARTS IDENTIFICATION HEFTI-LIFT

MODEL HYD-5 & HYD-10

ITEM

NO.

DESCRIPTION

Chain Cover

Chain Assembly

Brake Assembly

Mast

Guide Wheel and Axle

Front Wheel and Axle

Rear Wheel and Axle

Forks Assembly

Top Deck

Front Metal Shield

Back Plastic Shield

QTY.

HYD-5

ENGINEER NO.

33-154-004

33-154-005

33-154-006

33-154-032

33-154-007

33-154-008

33-154-009

33-528-004

33-013-001

33-024-011

33-024-010

HYD-10

ENGINEER NO.

33-154-016

33-154-017

33-154-006

33-514-018

33-154-007

33-154-008

33-154-009

33-528-004

33-013-001

33-024-013

33-024-012

QTY.
