TABLE OF CONTENTS Rev. 2/22/2024 JIB-FM, MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Co. Page 1 of 12
JIB-FM Series Floor Mounted Jib Cranes
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of it
on the bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance comply
with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels, and
accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can also
be contacted online at https://www.vestil.com/page-parts-request.php.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-
manuals.php.
Table of Contents
Page
Specifications……….…………………..…………………………………………………………………………....…
2
Signal Words……………………………………………………………………………………………………………..
2
Safety Instructions……………………...………………………………………………..………………………….….
3
FIGS. 1-5: Exploded Views and Bills of Materials………..…………..…………………………………………….
3, 4, 5
Assembling the Crane………………………………………………………………………………………………...
6 - 8
Function Tests……………………………………………………………………………………………………….…
8
Using the Crane……………………………………………………………………………………………………….
8 - 9
Record of Satisfactory Condition……………………………………………………………………………………
9
National Standards…………………………………………………………………………………………………….
9
Inspections and Maintenance………………...………………………………………………………………….…
10
Labeling Diagram……………………………………………..…………………………………………………….…
11
Limited Warranty…………………………………………………………………………………………………….…
12
VESTIL MANUFACTURING COMPANY
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestil.com e-mail: HUINFO@vestil.comU
TABLE OF CONTENTS Rev. 2/22/2024 JIB-FM, MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Co. Page 2 of 12
SIGNAL WORDS
SIGNAL WORDS appear in this manual to draw the reader’s attention to important safety-related
messages. The following are signal words used in this manual and their definitions.
SPECIFICATIONS
Dimensions, net weight, and capacity information for each JIB-FM-series crane are provided in the
following diagram and table. However, product design updates could change the specifications of the
updated model, particularly its dimensions and net weight. Vestil encourages you to acquire the latest
specifications for your product. Specifications documents for JIB-FM-series cranes can be accessed
through Vestil’s website. To access the appropriate specifications document, navigate to this webpage:
https://www.vestil.com/product.php?FID=529. Scroll to the Product Specifications Table section of the
webpage. Then, scroll down to the entry for the model you purchased and click the button in the
column titled PDFs that looks like a pencil inside a box. A PDF file will open. This file is the specifications
document. Print a copy of the document and keep it with a hardcopy of this manual.
Model
A
B
C
D
E
F
G
H
J
K
L
Capacity
Net wt.
JIB-FM-3
2
11
/
16
”
4”
80”
8
5
/
8
”
69
3
/
4
”
6
5
/
8
”
103
1
/
4
”
99
1
/
4
”
14
1
/
2
”
14
1
/
2
”
82
1
/
4
”
300 lb.
382 lb.
JIB-FM-6
4”
6”
80”
8
5
/
8
”
69
3
/
4
”
6
5
/
8
”
105
1
/
4
”
99
1
/
4
”
14
1
/
2
”
14
1
/
2
”
82
1
/
4
”
600 lb.
412 lb.
JIB-FM-10
4”
6”
80”
10
3
/
4
”
67
3
/
4
”
8
5
/
8
”
105
1
/
2
”
99
1
/
2
”
17”
17”
82
1
/
4
”
1,000 lb.
563 lb.
JIB-FM-20
4”
10
1
/
8
”
80”
10
3
/
4
”
67
3
/
4
”
8
5
/
8
”
109
5
/
8
”
99
1
/
2
”
17”
17”
82
1
/
4
”
2,000 lb.
596 lb.
JIB-FM-40
6
1
/
2
”
12
1
/
4
”
80
3
/
8
”
12”
66
1
/
8
”
10
3
/
4
”
111
1
/
2
”
99
1
/
2
”
24”
24”
83
7
/
8
”
4,000 lb.
765 lb.
DANGER
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
WARNING
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
NOTICE
Identifies practices likely to result in product/property damage, such as
operation that might damage the product.
!
!
!
