Side 1/4
12/23/05
10/22/05 23-126-120.doc
V
ESTIL MFG. CO. 1
VESTIL MANUFACTURING CORP.
2999 N. Wayne St., Angola, IN 46703
Ph: 260-665-7586 · Fax: 260-665-1339
E-mail: sales@vestil.com · Website: www.vestil.com
MODEL HPRO-48-42-4 / LPRO-48-16-4
Serial number ____________
Assembly / Installation Instructions ………………..… 2
Masonry Instillation Guidelines ……………………….3
Warranty …………………………………….……..…. 4
Routine Maintenance and Safety Checks………………2
Safety Label Identification .............................................4
IMPORTANT NOTES, WARNINGS AND SAFETY INSTRUCTIONS
Ensure that all employees understand and follow the following.
* Failure to read and understand this owner’s manual before using or
servicing the high / low profile guards constitutes a misuse of the
product. All persons who will install or care for this product must be
familiar with this material.
o Ensure that all safety labels stay in place and are legible.
o Do not use the high / low profile guard if any damage is observed.
o The high / low profile guard is intended for use only on concrete surfaces of
sufficient strength and condition to be adequate for anchoring.
o Contact the manufacturer for any needed MSDS information.
o Do not perform any modifications to the high / low profile guard without
the manufacturer’s approval. Failure to receive authorization for
changes to the equipment could void the warranty.
o Maintenance and repairs are to be done only by personnel qualified to
perform the required work. Consideration will not be given for warranty
repair charges without prior written authorization by the manufacturer.
WHEN ORDERING
REPLACEMENT PARTS:
We take pride in using quality
parts on the equipment we
manufacture. We are not
responsible for equipment
problems resulting from the use
of unapproved replacement
parts.
To order replacement or
spare parts for this equipment,
contact the factory.
In any communication with
the factory please be prepared
to provide the machine’s serial
number, which is indicated on
the machine dataplate.
RECEIVING INSTRUCTIONS
It is possible that the unit
could incur damage during
transit.
Inspect the unit closely when
it arrives. If you see evidence
of damage or rough handling to
either the packaging or to the
product when it is being
unloaded, immediately
make a
note of it on the Bill Of Lading!
It is important that you
remove the product’s packaging
upon its arrival to ensure that
there is no concealed damage
or to enable a timely claim with
the carrier for freight damage.
Also verify that the product
and its specifications are as
ordered.
O
WNER
’
S
MANUAL
concrete anchors, installation, 1005.doc
2 of 4 Vestil Mfg Co / T&S Eqpt Co
INSTALLATION (AND/OR ASSEMBLY) INSTRUCTIONS
Review this entire page before installing the high / low profile guard.
Consult the factory in the event there are any questions or problems at the time of installation, or for information
regarding optional features not covered by the owner’s manual.
The high / low profile guard must be removed from the shipping wood and securely anchored to the floor before use!
• Modifications or additions to the high / low profile guard without prior manufacturer’s authorization may void the high /
low profile guard’s warranty. The addition of ancillary equipment to the high / low profile guard may necessitate that
its load capacity be reduced.
• The installation must be made so that it complies with all the regulations applicable to the machine and its location.
The end-user must verify that the supplied equipment is installed so it will be suited to the environment in which it will
be used.
• Suitably trained personnel that have access to the appropriate equipment must perform installation.
---------------------------------------------------------------------------------------
For a typical installation of a standard high / low profile guard you will need the following:
1. A fork truck or hoisting means to unload the high / low profile guard from the freight truck and set it into place.
2. A smooth, level, and adequately strong concrete surface on which to mount the high / low profile guard.
3. Concrete anchors, a masonry drill, a masonry bit, hand tools, grout, and steel shims. Consult the building’s architect or
facility engineer to determine the best size and type of hardware with which to anchor the machine to the floor.
To install a standard high / low profile guard:
1. Move the high / low profile guard into place with straps or forks placed around it.
2. Anchor the frame to the floor through the 1” holes located on the bottom plate.
3. Clean up any debris, and verify that all of the safety labels are in good condition.
Note: See Installing Masonry Anchors section for instillation Guidelines.
ROUTINE MAINTENANCE & SAFETY CHECKS
(A) Inspect weekly for:
1.) The integrity of the frame anchor bolts, and for cracks in the concrete around them.
2.) Damage or structural deformation to the guard.
3.) All the safety labels being in place and in good condition.
